ASM
Medicare
SUNDOWN MkII MATTRESS ELEVATOR
USER INSRUCTIONS
CODE 09760A
Picow Farm Road
Runcorn, Cheshire
Sundown MkII
Tel: 01928 574301
Mattress Elevator
Fax: 01925 575130
User Instructions
Email:-
sales@asmmedicare.com
www.asmmedicare.com
With Emergency Backup Battery
& Safety Anti Trap Actuator.
Better By Design.
March-03
Advertisement
Summary of Contents for ASM SUNDOWN MkII
- Page 1 Medicare SUNDOWN MkII MATTRESS ELEVATOR USER INSRUCTIONS CODE 09760A Picow Farm Road Runcorn, Cheshire Sundown MkII Tel: 01928 574301 Mattress Elevator Fax: 01925 575130 User Instructions Email:- sales@asmmedicare.com www.asmmedicare.com With Emergency Backup Battery & Safety Anti Trap Actuator. Better By Design.
- Page 2 Medicare Medicare 1} Introduction. 2} Limitations Of Use. 3} Installation. 4} Electrical Fittings. 5} Care & Maintenance. Blue Walker Trolley 02138 Corner Shower Stool 02010 6} Trouble Shooting. 7} Spare Parts List. 8} Guarantee. 9} Technical Data. Solent Overbed Table 6020 Wren Perching Stool 02303HB...
- Page 3 Medicare Medicare Other Products In The ASM Range. 1} Introduction. This mattress elevator has been manufactured using high quality electrical components, mild steel tube and plate & is Multi System 2000E designed to give you many years of continued service.
- Page 4 Medicare Medicare 2} Limitations Of Use. 9} Technical Data. Product Weight - 16.05kg / 35.3lb Your new Adjustable Mattress Elevator has been tested to a MUW (Maximum User Weight) of 190kg / 30st. MUW - 190kg / 30st It is not recommended to exceed this limit for safety. Overall Dimensions Closed - This product must not be used in conjunction with any Width = 941mm / Depth = 710mm / Height = 163mm.
- Page 5 Medicare 8} Guarantee. 3} Installation. ASM Medicare Ltd garantees this product for 12 months from a} First remove the mattress & position the base so that access the purchase date against faulty materials & workmanship. can be readily gained around each side.
- Page 6 Medicare Medicare 3} Installation. 7} Trouble Shooting. Fig 1. PROBLEM POSSIBLE CAUSE ACTION Backrest stops MUW exceeded. Follow MUW limit sparodically. 190kg / 30st. Actuator, control box or Contact your engineer or handset may be faulty. supplier. Mains cable loose. Check connection.
- Page 7 Medicare Medicare 6} Spare Parts List. 3} Installation. Fig 2 LAC 1 - Actuator with integural Control Box. After Rotating The Triangular Brackets Pass Fitting Straps Through And Fit LA 2 - Actuator Only. A Retaining Buckle & B Locking Buckle LHF 4 - Handset.
- Page 8 Medicare Medicare 4} Electrical Fittings & Operation. 5} Care & Maintenance. Fig 5. Your new Adjustable Mattress Elevator should only be serviced by a trained competent engineer. Always change the backup battery every six months or after use. The fitting straps & fixings should be checked regularly & be free from water. Use a mild proprietary soap and warm water to clean the elevator or a disinfectant that complies to BS 6424.
