- Page 1 Original User Manual – A S Cable Hoist REBO Cable Hoist Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
Original User Manual – A S Cable Hoist REBO List of contents 1. Important instructions .............. 3 2. Explanations of the symbols ............3 3. Safety instructions ..............4 4. Construction ................6 5. Technical specifications ............. 7 6. Area of application ..............8 7. -
Page 3: Important Instructions
Original User Manual – A S Cable Hoist REBO Thank you for purchasing our product. Please read the operating instructions carefully before using the product for the first time. If you give the product to a third party, this manual must be handed over with it. -
Page 4: Safety Instructions
Original User Manual – A S Cable Hoist REBO 3. Safety instructions • The electric hoist should best be operated by experts. The user must follow the following points. • Read the instructions carefully before use. • The user must strictly follow the instructions for use. •... - Page 5 Original User Manual – A S Cable Hoist REBO • Down: The rope presses against the metal pin (1) in the unwound state and actuates the button (2) to interrupt the power. whether there are strange noises during operation. If the steel cable is damaged or after 20 operating hours, the steel cable must be replaced.
-
Page 6: Construction
Original User Manual – A S Cable Hoist REBO 4. Construction 1. Installation brackets 2. Up limit bracket for limit stop 3. Load hook 4. Additional load hook with deviating shaft 5. Limit weight 6. Power cord 7. Mounting casing 8. -
Page 7: Technical Specifications
Original User Manual – A S Cable Hoist REBO • The load hoisting motor: This motor is a magnetic single-phase capacitor motor and is isolated in accordance with Class B. The magnetic mechanism is constructed as a break and serves as a reliable safety. •... -
Page 8: Area Of Application
Original User Manual – A S Cable Hoist REBO *Measurement methods and detailed operating conditions during noise emission measurements must be specified. (EN 14492-2 7.2 b)) • This value means only the greatest noise that the device can generate. It cannot be decided whether the operator should wear a hearing protection. -
Page 9: Problem Solving
Original User Manual – A S Cable Hoist REBO • The electric hoist has an overheating protection. If the device stops from overheating, you have to wait for it to cool down before operating again. Therefore, one should avoid the too frequent jog mode when the device is running under load. -
Page 10: Electric Principle Drawing
Original User Manual – A S Cable Hoist REBO 9. Electric principle drawing AR-HE-SW100, AR-HE-SW200, AR-HE-SW300 AR-HE-SW400, AR-HE-SW500... -
Page 11: Mounting Plan
Original User Manual – A S Cable Hoist REBO 10. Mounting plan Correct steel cable winding method 11. Maintenance and cleaning • Disconnect the power plug prior to performing any work on the device. • Clean the device using damp cloth some liquid... -
Page 12: Environmentally Friendly Disposal
You can obtain the addresses from your city or local government. You can find out about other return options created by us on our website www.arebos.de. The separate collection of Waste electrical or electronic equipment is intended... -
Page 13: Eu Declaration Of Conformity
Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
