SINK HOLE SAVER™
Pat: www.omnicubed.com/patents
en
fr
es

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SINK HOLE SAVER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omni cubed SINK HOLE SAVER

Summary of Contents for Omni cubed SINK HOLE SAVER

  • Page 1 SINK HOLE SAVER™ Pat: www.omnicubed.com/patents...
  • Page 2 4’ Sink Hole Saver™ Auto 4’ Sink Hole Manual SHS-4A-20 SHS-4M-20 7’ Sink Hole Saver™ Auto 7’ Sink Hole Manual SHS-7A-20 SHS-7M-20 Sink Hole Saver™ Slider Auto Sink Hole Saver™ Slider Manual SHS-SA-20 SHS-SM-20 Sink Hole Saver™ User Guide: 191220...
  • Page 3 48” Rail 84” Rail 51–90” Adjustable Rail 6” Vacuum Cup Assembly VMP750 Vacuum Pump Smart Charger Coiled Vacuum Tubing omnicubed.com...
  • Page 4 a. Adjustable Rail b. Lock Knob c. Vacuum Cup Assembly d. Fixed-length Rail e. VMP750 Vacuum Pump f. Vacuum Tubing Slim Slab Saver™...
  • Page 5 l. m. n. a. Lock Knob h. Felt Filter o. Mounting Tab b. Shutoff Valve i. Sealing Rings p. Tubing Connector c. Valve Filter j. VMP750 Vacuum Pump q. Vacuum Tubing d. Vacuum Cup k. Mounting Knob r. Check valve e.
  • Page 6 Caution • Note the total weight includes both slab and mortar. • Be mindful of material porosity: all vacuum cups function better on less porous material. For highly porous material, apply plastic film to the surface. Sink Hole Saver™...

  • Page 7: Maintenance

    Occasionally inspect the plungers to ensure they are clean and the rubber piston seals are moderately lubricated with petroleum jelly. • Occasionally test vacuum cup functionality. (See page 9) • Contact Omni Cubed Customer Service for troubleshooting and replacement parts. omnicubed.com...
  • Page 8 Place the pump at the center of one of the rails with the tabs in the slot. Push and turn each knob ¼ turn. Remove the vacuum plugs from the vacuum cup assemblies. Push the ends of the tubing into the vacuum connectors. Sink Hole Saver™...
  • Page 9 Attaching to Material (Manual Models) Close all shutoff valves and ensure all vacuum plugs are in place. For each pair of connected cups, pump the plungers while pressing the frame against the surface. Pump the plungers until the red collars remain hidden. Monitor all plungers during use and re-pump when a red collar appears.
  • Page 10 Keep all pumps running while in use. Optionally, press in the plungers to help monitor vacuum pressure. Releasing from Material Turn off all pumps (auto models). Open all shutoff valves. Sink Hole Saver™...
  • Page 11 Pump Recharging Plug the smart charger into a wall outlet. Use only the included smart charger. Connect the smart charger to the pump. Observe the LED on the smart charger. Red indicates charging; green indicates fully charged. Recharging requires up to 3 hours. Vacuum Cup Testing Follow these steps to determine if maintenance or replacement parts are...
  • Page 12 Noter que le poids total inclut la dalle et le mortier. • Considérer la porosité du matériau: toutes les ventouses fonctionnent mieux sur une surface moins poreuse. Appliquer une pellicule de plastique sur la surface d’un matériau très poreux. Sink Hole Saver™...

  • Page 13: Entretien

    • Tester occasionnellement le bon fonctionnement de la ventouse. (voir p. 15) • Contacter le service à la clientèle d’Omni Cubed pour résoudre des problèmes ou pour remplacer des pièces. omnicubed.com...
  • Page 14 Placer la pompe au centre d’un des rails en insérant les languettes dans la fente. Pousser et tourner chaque bouton ¼ de tour. Enlever les bouchons à vide des ventouses. Pousser le bout des tubes dans les ports à vide. Sink Hole Saver™...
  • Page 15 S’attacher au matériau (Modes manuels) Fermer toutes les soupapes et s’assurer que tous les bouchons sont en place. Pour chaque paire de ventouses, pousser plusieurs fois sur la pompe manuelle activée par un doigt en pressant le châssis contre la surface. Actionner les pompes manuelles activées par un doigt jusqu’à...
  • Page 16 Garder toutes les pompes en marche pendant l’utilisation. En option, appuyer sur les pompes pour aider à surveiller la pression du vide. Se détacher du matériau Éteindre toutes les pompes (modèles automatiques). Ouvrir toutes les soupapes. Sink Hole Saver™...
  • Page 17 Rechargement de la pompe Brancher le chargeur intelligent dans une prise murale. Utiliser uniquement le chargeur intelligent fourni. Connecter le chargeur intelligent à la pompe. Regarder la lumière DEL sur le chargeur. La lumière rouge indique c’est en train de charger. La lumière verte indique que c’est complètement chargée.
  • Page 18 Tenga en cuenta que el peso total incluye tanto la losa como el mortero. • Tenga en cuenta la porosidad del material: todas las ventosas funcionan mejor con un material menos poroso. Para materiales altamente porosos, aplique un film plástico a la sperficie. Sink Hole Saver™...

  • Page 19: Mantenimiento

    • Pruebe ocasionalmente la funcionalidad de la ventosa. (Ver página 21) • Póngase en contacto con el servicio de atención al cliente de Omni Cubed para solucionar problemas y obtener piezas de repuesto. omnicubed.com...
  • Page 20 Presione y gire cada una de las perillas girando al ¼. Retire los tapones de vacío de los conjuntos de ventosas de vacío. Empuje los extremos del tubo en los conectores de vacío. Sink Hole Saver™...
  • Page 21 Acoplarse al Material (Modelos Manuales) Cierre todas las válvulas de cierre y asegúrese de que todos los tapones de vacío estén en su lugar. Para cada par de vasos conectados, bombee los émbolos mientras presiona el marco contra la superficie. Bombee los émbolos hasta que los collares rojos permanezcan ocultos.
  • Page 22 Mantenga todas las bombas en funcionamiento durante su uso. Opcionalmente, presione los émbolos para ayudar a controlar la presión del vacío. Liberación de Material Apague todas las bombas (modelos automáticos). Abra todas las válvulas de cierre. Sink Hole Saver™...
  • Page 23 Recarga de la Bomba Enchufe el cargador inteligente en un tomacorriente de pared. Utilice sólo el cargador inteligente incluido. Conecte el cargador inteligente a la bomba. Observe la luz LED del cargador inteligente. El rojo indica que está cargando; el verde indica que está completamente cargado.

  • Page 24: Related Products

    Part #: VMP750-19 The L6 Rigid Cross-Brace Kit includes two 60” rails and six clamps. Use the kit in combination with two or three Sink Hole Saver™ or Slim Slab Saver™ rails to create a frame. Part #: RCB-156-19 Sink Hole Saver™...
  • Page 25 The S3 Slim Slab Saver™ is a versatile, completely customizable rigid frame and reinforcement system that reduces strain and risk of injury while handling large format slabs and other fragile materials. Part #: S3-3A-19 omnicubed.com...

  • Page 26: Customer Service

    INFORMATION Customer Service We’re here to help you! If you have any questions, concerns, or parts and service needs, please contact us directly. USA: 877-311-1976 omnicubed.com/help Europe: +0044 (0)1482 935 570 omnicubedeurope.com All Other Regions: +1-530-748-3120 customerservice@omnicubed.com Sink Hole Saver™...

  • Page 27: Warranty

    ® omnicubed.com. Liability Omni Cubed, Inc., its affiliates, authorized distributors, officers, directors, agents, employees, or manufacturers shall not be liable for any direct, indirect, punitive, incidental, or special consequential damages, to property or life, whatsoever arising out of or connected with the use or misuse of our products.
  • Page 28 © 2019 Omni Cubed, Inc. All rights reserved. Omni Cubed, Inc. 3870 Dividend Drive Shingle Springs, CA 95682, USA Tel: 877.311.1976 omnicubed.com...
