Operations Manual
for the ASEA Power Systems
Models AC36VHES-1, AC36VHES-3, AC45VHES-1,
AC45VHES-3, AC54HES-1, and AC54VHES-3
Single and Three Phase, Water-Cooled
Shore Power Converters
P/N 604056
Issued 12/13/2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC36VHES-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ASEA AC36VHES-1

  • Page 1 Operations Manual for the ASEA Power Systems Models AC36VHES-1, AC36VHES-3, AC45VHES-1, AC45VHES-3, AC54HES-1, and AC54VHES-3 Single and Three Phase, Water-Cooled Shore Power Converters P/N 604056 Issued 12/13/2013...

  • Page 2: Certification

    LIFE SUPPORT POLICY ASEA Power Systems does not authorize the use of any of its products or systems for use an AC voltage supply (source) for life support systems. Life support systems are devices which support or sustain life, and whose failure to perform, when properly used in accordance with this Operations Manual, can be reasonably expected to result in significant injury to the user.

  • Page 3: Using This Manual

    A thorough understanding of the information covered in this manual is required for proper installation and operation. If any questions arise while reading this manual, the user is encouraged to call ASEA Power Systems. ASEA Power Systems is located at: ASEA Power Systems 15602 Commerce Lane Huntington Beach, CA.

  • Page 4: Table Of Contents

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..TABLE OF CONTENTS CERTIFICATION ...........................2 WARRANTY ..........................2 USING THIS MANUAL .....................3 SAFETY NOTICES......................6 INTRODUCTION TO THE AC36/45/54VHES ..............8 SPECIFICATIONS ......................10 ELECTRICAL SPECIFICATIONS ..............10 4.1.1 Input Service ....................10 4.1.2 Output Service ...................10 4.1.3 Control, Metering, and Status ..............12...
  • Page 5 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..SOFTWARE FEATURES ....................41 GENERAL ......................41 LOAD MANAGEMENT..................41 LOAD MANAGEMENT OPERATION ...............43 7.3.1 Shore Cord Alarm, Single, Master, and Slave converters ......43 7.3.2 Shore Cord Setup, Single, Master, or Slave Converters ......44 7.3.3 Load Sharing, Slave converters with Shore Cord Management Option ..45...

  • Page 6: Safety Notices

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..SAFETY NOTICES Each shore power converter is capable of transferring large amounts of electrical energy very quickly. This quality is fundamental to a high performance power converter. International symbols are used throughout this manual to stress important information. Read the text below each symbol carefully and use professional skills and prudent care when performing the actions described by the text.
  • Page 7 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual.. THIS EQUIPMENT CONTAINS HIGH ENERGY, LOW IMPEDANCE CIRCUITS! LETHAL POTENTIALS ARE CONTAINED WITHIN THE SYSTEM EVEN WHEN IT APPEARS NON-OPERATIONAL.  CARE MUST BE EXERCISED WHEN SERVICING THIS EQUIPMENT IN ORDER TO PREVENT SERIOUS OPERATOR INJURY OR EQUIPMENT DAMAGE.

  • Page 8: Introduction To The Ac36/45/54Vhes

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..INTRODUCTION TO THE AC36/45/54VHES The AC36VHES, AC45VHES, and AC54VHES are high performance Shore Power Converters utilizing dual-conversion technology. These converters will accept any single or three phase input service with a frequency between 40-70Hertz, and a voltage between 170-520VAC; the converter will auto-configure for the applied power form.
  • Page 9 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..The converter is designed to have the heat it introduces into its internal atmosphere cooled via this back -mounted, air-to-liquid heat exchanger. The heat-exchanger is designed for use with chilled water or coolant (not seawater).

  • Page 10: Specifications

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..SPECIFICATIONS ELECTRICAL SPECIFICATIONS Parameter AC36VHES-1, -3 AC45VHES-1, -3 AC54VHES-1, -3 4.1.1 Input Service Input Power Form Single of Three Phase Single or Three Phase Single or Three Phase Input Voltage Range...
  • Page 11 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..SPECIFICATIONS ELECTRICAL SPECIFICATIONS cont. 4.1.2 Output Service, cont. Table 1 - Output Current, Rated Continuous RMS Output Form AC36VHES-1 AC45VHES-1 AC54VHES-1 1Ø, 220V 164A /Ø 205A /Ø 245A /Ø 1Ø, 230V 156A /Ø...

  • Page 12: Control, Metering, And Status

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..SPECIFICATIONS, cont. ELECTRICAL SPECIFICATIONS, cont. 4.1.3 Control, Metering, and Status Input Power Control Input Service Disconnect Switch, 2 pos. Shore Power Control Membrane Switch, Input ON/OFF Control Converter Power Control Membrane Switch, Output ON/OFF Control, Ship’s Power Control...

  • Page 13: Physical Specifications

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..SPECIFICATIONS, cont. PHYSICAL SPECIFICATIONS Parameter AC36VHES-1, -3 AC45VHES-1, -3 AC54VHES-1, -3 4.2.1 Mechanical Height 56.13"/142.6cm 56.13"/142.6cm 56.13"/142.6cm Width, Enclosure 32.66"/83.0cm 32.66"/83.0cm 32.66"/83.0cm Depth 21.81"/55.4cm 21.81"/55.4cm 21.81"/55.4cm Weight 836lbs/379kg 836lbs/379kg 840lbs/381kg 4.2.2 Environmental...

  • Page 14: Installation

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..INSTALLATION The installation section is divided into two parts. The first will cover mechanical installation, the second, electrical installation. Read this manual thoroughly prior to attempting the installation. Improper installation is the most significant cause of system start-up problems and service issues over the product’s life.

  • Page 15: Mechanical Installation

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..MECHANICAL INSTALLATION 5.1.1 General The converters were designed for deck mount installations and as such are provided with six mounting holes, three per side. Mounting holes have been provided with 1/2” (12.7mm) diameters;...

  • Page 16: Mechanical Outline

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..MECHANICAL INSTALLATION, cont. FIGURE 3 MECHANICAL OUTLINE...

  • Page 17: Deck Mounting Pattern

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..MECHANICAL INSTALLATION, cont. FIGURE 4 DECK MOUNTING PATTERN...

  • Page 18: Chilled Water Loop Requirements

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..MECHANICAL INSTALLATION 5.1.3 Chilled Water Loop Requirements 1. Coolant lines a. The four coolant line connections are to 1/2" diameter copper pipes. b. Use Teflon sealant to ensure that no leakage will occur.

  • Page 19: Electrical Installation

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION This procedure assumes the physical installation of the converter has been completed. It is the installer’s responsibility to provide input service over-current protection and disconnect means. It is recommended that connection be made to the distribution bus through a manually operated...

  • Page 20: Input Power Connections

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION, cont. INPUT WIRING MUST BE PERFORMED BY A QUALIFIED ELECTRICIAN FAMILIAR WITH STANDARD SAFEGUARDS AND PROCEDURES REQUIRED BY THE INSTALLATION OF THIS TYPE OF EQUIPMENT. POWER MUST BE REMOVED FROM THE INPUT DISTRIBUTION SYSTEMS SUPPLYING POWER TO THE CONVERTER PRIOR TO THE START OF THE FOLLOWING STEPS.
  • Page 21 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION, cont. 5.2.2 Output Power Connections, cont. Three phase WYE output forms such as 120/208VAC and 230/400VAC use a 4-wire plus ground wiring configuration. In the case of those power forms, the Converter Output ØA, ØB, ØC, and N terminals are used.

  • Page 22: Input And Output Connections

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION, cont. FIGURE 5 INPUT AND OUTPUT CONNECTIONS Prepare the power cables by removing approximately 6” of the outer cable insulation (in the case of SO type portable cables). Strip the insulation back exposing 1” of the bare conductor for all input, output, and grounding conductors.

  • Page 23: Grounding

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION, cont. 5.2.3 Grounding The FAULT GROUND terminal on the Shore Power Input Terminal Block is for termination of the shore cord ground. The terminal is internally connected to a copper shield placed between the primary and secondary coil of the three input isolation transformers.

  • Page 24: Multi-Cabinet Connections

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION, cont. 5.2.4 Multi-Cabinet Connections Multi-cabinet systems should have each cabinet’s output connections paralleled at the switchgear panel. The converters’ terminal blocks are sized for a single, appropriated sized cable per phase, neutral, and grounding conductor.

  • Page 25: Seamless Transfer Connections

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION, cont. 5.2.5 Seamless Transfer Connections If the Seamless Transfer Option was ordered with the system, connections must be made between the generator/switchgear and converter. These connections are used by the converter to successfully manage Seamless Transfer operation and are comprised of control, signal, and feedback functions.

  • Page 26: Other Optional Connections

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..ELECTRICAL INSTALLATION, cont. 5.2.6 Other Optional Connections In support of the Seamless Transfer Option, or in support of switchgear and/or power monitoring integration, other options may be ordered and installed in a converter. Installation requirements for such options vary in accordance with switchgear design and hence are beyond the scope of this Operations Manual.

  • Page 27: Operation

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..OPERATION POWER TURN-ON PROCEDURE Close the shore power (input) circuit breaker or switch to the converter. Turn the disconnect (14) switch to the ON position. After 1-3 seconds, fans will be heard, and the display will become active.
  • Page 28 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..POWER TURN-ON PROCEDURE, cont. The display will sequence to the SUMMARY DISPLAY indicating the converter’s operational state. Both input and output (converter) should indicate OFFLINE at this time. Press the INFO (13) button to review the Shore Power state if desired.

  • Page 29: Systems Not Equipped With The Seamless Transfer Option

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..POWER TURN-ON PROCEDURE, cont. Press the CONVERTER POWER (4) button and the screen will now change. As with the shore power displays, the F1-F4 (13) buttons will cycle through a variety of converter power data.

  • Page 30: Systems Equipped With The Seamless Transfer Option

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..POWER TURN-ON PROCEDURE, cont. 6.1.2 Systems Equipped With The Seamless Transfer Option With the converter in the Standby State (as left at the end of Section 6.1), press the GENERATOR POWER (3) display button. The generator voltage and form will now be displayed.
  • Page 31 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..POWER TURN-ON PROCEDURE, cont. 6.1.2 Systems Equipped With The Seamless Transfer Option, cont. If the generator is supplying power to the ship, the SHIP’S POWER - GENERATOR LED (12A) is lit, and the GENERATOR metering display indicates approximately the same voltage as the CONVERTER metering display, then proceed by pressing the SHIP’S POWER - CONVERTER...

  • Page 32: Multi-Cabinet Operation

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..MULTI-CABINET OPERATION Multi-cabinet systems are operated from the Master’s control panel. Each cabinet retains its own control panel and metering display for individual monitoring. A load management option exists that allows individual cabinets to load according to shore cord size (see section 7 for details).

  • Page 33: Auto-Restart Feature

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..AUTO-RESTART FEATURE The Auto-Restart feature will safely and automatically bring the shore power converter back on- line following a power failure and recovery event. Highlights include:  Automatically routes power from the dock to the ships power buss.

  • Page 34: Operation

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..AUTO-RESTART FEATURE, cont. 6.3.1 Operation Auto-Restart must be enabled from the converter front panel by simultaneously pressing two buttons. Anytime the system status is “FAILURE,” the converter will disable the Auto-Restart feature.

  • Page 35: Turn-Off Procedure

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..TURN-OFF PROCEDURE 6.4.1 Systems Not Equipped With The Seamless Transfer Option Transfer power from the converter to the generator. This must be performed in a “break-before- make” method. That is to say that at no time can the generator(s) and shore power converter be operated in parallel.

  • Page 36: Systems Equipped With The Seamless Transfer Option

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..6.4.2 Systems Equipped With The Seamless Transfer Option The generator must be started and be prepared to accept the ship’s electrical loads. Measure the generator voltage using the converter’s metering display, selecting the GENERATOR POWER (3) function.

  • Page 37: Remote Communication

    RS-485 standard via a din-rail mounted converter/optical-isolator. The two software protocols supported by the converter are SCPI and Modbus. Please contact an ASEA Power Systems authorized distributor or the factory for additional information and comprehensive command/query listings. The Baud Rate and fixed serial port settings can be viewed in the REMOTE INTERFACE CONFIGURATION DISPLAY (as depicted below) by pressing the SYSTEM STATUS (5) and F3 (13) buttons simultaneously.

  • Page 38: Rs-232C/Scpi

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..REMOTE COMMUNICATIONS, cont. 6.5.1 RS-232C/SCPI The RS-232C serial port is located in the upper-left corner of the Input/Output connection panel (see Figure 5 on page 22). The RS-232C TxD signal originating in the converter is approximately +15V when “High” and - 15V when “Low.”...

  • Page 39: Rs-485/Modbus

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..REMOTE COMMUNICATIONS, cont. 6.5.2 RS-485/Modbus If included in the converter, a Modbus Option converter/optical-isolator will be located adjacent to the RS-232C serial port (see Figure 5 on page 22). The Modbus Option included converter/optical-isolator connections are depicted in Figure 8 below.
  • Page 40 ASEA Power Systems designed Touch Panel computers. Additional slave converters can be set for Node Id numbers greater than 4 (5-8 recommended). As ASEA Power Systems uses Node Id numbers 9-13 for GMM products, use of these should be avoided.

  • Page 41: Software Features

    SOFTWARE FEATURES GENERAL ASEA Power Systems' shore power converters provide a variety of software-based resources. Each major function is described in detail in the following pages. BOLD upper-case text indicates when a display button is being referenced. Where two buttons are given as BUTTON + BUTTON, the buttons must be pressed simultaneously.
  • Page 42 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT, cont. Load Sharing The slave converter of a paralleled converter system can be forced to draw less current than the master converter, if attached to a shore cord with lesser available power due to lower amperage, lower voltage, or different form (i.e.

  • Page 43: Load Management Operation

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION 7.3.1 Shore Cord Alarm, Single, Master, and Slave converters If the yacht’s electrical system includes a power management or load-shed feature, the Shore Cord Alarm can be used to effect a change in loading when the converter reaches a programmed load threshold, or simply draw the yacht engineer’s attention.

  • Page 44: Shore Cord Setup, Single, Master, Or Slave Converters

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION, cont. 7.3.2 Shore Cord Setup, Single, Master, or Slave Converters The Shore Cord Setup screen is used to set the actual shore cord ampacity based on the marina’s dock or pedestal circuit breaker.

  • Page 45: Load Sharing, Slave Converters With Shore Cord Management Option

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION, cont. 7.3.3 Load Sharing, Slave converters with Shore Cord Management Option The function of this special Slave converter screen includes those functions of the normal Shore Cord Setup screen described on the previous page with one addition: Load Sharing between the two converters of a paralleled converter system is controlled by entering the MASTER CAPACITY here.
  • Page 46 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION, cont. 7.3.3 Load Sharing, Slave converters with Shore Cord Management Option, cont. From the front panel, press the SHORE POWER + F2 buttons, and then Cord (F1) to access the...

  • Page 47: Voltage Droop, Single Or Master Converters

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION, cont. 7.3.4 Voltage Droop, Single or Master Converters Upon Shore Alarm, the Voltage Droop feature may be used to save up to 10% converter capacity by reducing the converter output voltage up to 5%. This is offered as a solution where the yacht does not already have power management and load-shed capabilities that can be triggered with the Shore Cord Alarm signal.

  • Page 48: Automatic Transfer To Generator, Single Or Master Converters (Seamless Transfer Installed)

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION, cont. 7.3.5 Automatic Transfer to Generator, Single or Master Converters (Seamless Transfer installed) Upon Shore Alarm, the Automatic Transfer to Generator feature may be used to perform a Seamless Transfer to a pre-selected generator.

  • Page 49: Quick Setup Of Shore Cord Alarm, Single, Master, Or Slave Converters

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION, cont. 7.3.6 Quick Setup of Shore Cord Alarm, Single, Master, or Slave Converters 1. Turn on the red Disconnect switch of both converters and wait 15-20 seconds for initialization.

  • Page 50: Expert Load Sharing Use, Paralleled Converters

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..LOAD MANAGEMENT OPERATION, cont. 7.3.7 Expert Load Sharing Use, Paralleled Converters The Load Sharing system described in this document has been programmed for simple use and comprehensive gathering of all pertinent data into a few, simple screens. However, the controls can be bypassed and Load Sharing implemented by the user directly via the Slave’s...

  • Page 51: Generator Frequency Analysis

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..GENERATOR FREQUENCY ANALYSIS Press the SYSTEM STATUS + GENERATOR POWER buttons to access the Generator Frequency Analysis Display. Used for observing lifetime generator frequency range. GENERATOR FREQUENCY ANALYSIS DISPLAY Generator MIN Frequency: XX.XXHz...

  • Page 52: Agc Control

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..used in conjunction with re-measurement at the remote location to determine the correction needed. Drastic changes in Duty Cycle will result in equally drastic voltage changes. Transfer Impedance is usually only modified by factory trained personnel when commissioning a converter.

  • Page 53: Kw-Hour Meter And Maximum Power Level Display

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..kW-HOUR METER AND MAXIMUM POWER LEVEL DISPLAY Press the SHORE POWER + CONVERTER POWER buttons to access the Automatic KW- HOUR METER and maximum power level display. KW-HOUR METER kW-Hours:XXXXXXX.XX Run Time. XX:XX:XX:XX Max.

  • Page 54: Converter Output Voltage Control

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..CONVERTER OUTPUT VOLTAGE CONTROL Press the CONVERTER POWER + F5 buttons to access the CONVERTER OUTPUT VOLTAGE CONTROL display. CONVERTER OUTPUT VOLTAGE CONTROL Vout = XXX.X More Less XXXV Exit This function allows the user to increase or decrease the converter output voltage (Vout).

  • Page 55: Event Log

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..EVENT LOG Press the EVENT LOG (or CALIBRATE on older converters) button to access the EVENT LOG display. EVENT LOG CONTROL SCREEN F1: EVENT LOG VIEWER XXXX Events F2: EVENT LOG TRACKER F3: EVENT LOG REGISTRY This is for monitoring internal converter logic operation.
  • Page 56 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..EVENT LOG, cont. Press the F3 button to access the EVENT LOG REGISTRY display. EVENT LOG REGISTRY PRESS: ‘SHORE POWER’ to edit Registry, The ‘F1’ for log On & ‘F2’ for log Off.

  • Page 57: Trouble-Shooting And Diagnostics

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..TROUBLE-SHOOTING AND DIAGNOSTICS COMMON PROBLEMS When encountering difficulty in achieving successful operation of the converter, there are some problems which are easily identified and solved. The following list is not intended to be exhaustive.

  • Page 58: Failure And Warning Messages

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..FAILURE AND WARNING MESSAGES The converter can display various FAILURE or WARNING messages under certain circumstances. If the event causing such as message has subsided, pressing buttons F1 (13) and F2 (13) simultaneously will clear the FAILURE or WARNING message.

  • Page 59: Status Words

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..STATUS WORDS To aid in system diagnostics, three STATUS WORDs have been provided in the STATUS WORD DISPLAY, which is accessed by pressing the SYSTEM STATUS (5) and F2 (13) buttons simultaneously.

  • Page 60: Status Word Bit Definitions

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..DIAGNOSTICS, cont. FIGURE 9 STATUS WORD BIT DEFINITIONS...

  • Page 61: Calibration

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..CALIBRATION In an uncalibrated state the input and output voltage and input current metering system should be within 5%. The uncalibrated output current meter is normally 10% low. For calibration an external reference voltmeter will be required along with a calibrated current transformer or probe.
  • Page 62 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..CALIBRATION, cont. Generator Power Calibration - Use an external reference voltmeter to measure the generator voltage at the generator terminals located on TB12-1, 2, 3, 4. To enter the meter calibration screen, press and hold the GENERATOR POWER (3) button down for 7 seconds, or until the calibration display appears, then release the button.

  • Page 63: Maintenance

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..MAINTENANCE Due to the design and construction of the converter, preventative maintenance is held to a modest level. The following table lists minimum recommended tasks and frequency. TASK FREQUENCY COMMENTS...

  • Page 64: International Power Form Reference

    AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..INTERNATIONAL POWER FORM REFERENCE Country Frequency Nominal Voltage Comments American Samoa 60Hz 120/240 277/480 Antigua 60Hz 230/400 Argentina 50Hz 220/380 Aruba 60Hz 127/220 115/230 Australia 50Hz 240/415 250/435 Azores 50Hz...
  • Page 65 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..250/440 Benin 50Hz 220/380 Bermuda 60Hz 120/240 120/208 Brazil 60Hz 115/230 127/220 220/380 Brunei 50Hz 240/415 Bulgaria 50Hz 220/380 Burma 50Hz 230/400 Canada 60Hz 120/240 120/208 277/480 Canary Islands 50Hz...
  • Page 66 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..Costa Rica 60Hz 120/240 120/208 Cyprus 50Hz 240/415 Denmark 50Hz 220/380 Dominica 50Hz 230/400 Dominican 60Hz 120/240 Republic 120/208 Ecuador 60Hz 120/240 120/208 Fiji 50Hz 240/415 Finland 50Hz 220/380 France...
  • Page 67 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..120/208 Haiti 60Hz 110/220 120/208 Honduras 60Hz 110/220 120/208 Hong Kong 50Hz 220/380 Ireland 50Hz 220/380 Israel 50Hz 230/400 Italy 50Hz 127/220 220/380 Jamaica 50Hz 110/220 Japan 50Hz 100/200 60Hz...
  • Page 68 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..Mauritius 50Hz 230/400 Mexico 60Hz 127/220 Monaco 50Hz 127/220 220/380 Montserrat 60Hz 230/400 Morocco 50Hz 127/220 220/380 Netherlands 50Hz 220/380 Netherlands 50Hz 127/220 Antilles 220/380 60Hz 120/240 New Caledonia 50Hz...
  • Page 69 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..St. Vincent 50Hz 230/400 Saudi Arabia 60Hz 127/220 Seychelles 50Hz 240/415 Sierra Leone 50Hz 230/400 Singapore 50Hz 230/400 South Africa 50Hz 220/380 Spain 50Hz 127/220 220/380 Sweden 50Hz 220/380 Tahiti...
  • Page 70 AC36VHES-1, -3 / AC45VHES-1, -3 / AC54VHES-1, -3 Operations Manual..Uruguay 50Hz 220/380 Venezuela 60Hz 120/240 120/208 Amer. Virgin 60Hz 120/240 Islands 120/208...

  • Page 71: Index
