Markwort C-FLAP Quick Mount Quick Start Manual

For use with the C-Flap and batting helmets
Boombah DEFCON®, Boombah DEFCON® Sleek & Rawlings®
Coolflo® (RCFH)*
Front side of C-Flap® Quick Mount
with hole indications
1
2
3
Left side of Boombah/Rawlings®
helmet with hole indications
4
5
6
A
B
C
Patent Pending
Designed and Manufactured by Titon Corp., S. A. in Guatemala.
Distributed by Markwort Sporting Goods Company Saint Louis, Missouri 63132.
Please visit markwort.com for more C-Flap® and Quick Mount content.

Disclaimers and Notes:

Assembly Instruction and the C-Flap® Quick Mount are designed for
use with the C-Flap Cheek & Jaw Protector and approved batting
helmets only. Please visit markwort.com for more information.
*Rawlings Coolflo® requires removal of the snap-on feature located
on the lowest pre-drilled hole by drilling it on the side on which the
C-Flap® will be assembled. Then, the ear flap foam must be carefully
peeled, not completely, only to remove the insert (nut) located inside
the lowest pre-drilled hole. A tee nut, included with the C-Flap® must
then be placed inside this pre-drilled hole, allowing it to be used for
fastening the system.
Extruded view of helmet, Quick Mount, and
C-Flap® protective system assembly
