- Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 34WP60C www.lg.com Copyright © 2021 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE ........3 - Connecting to a PC...........10 HDMI Connection OPEN SOURCE SOFTWARE DisplayPort Connection NOTICE INFORMATION ....4 - Connecting AV Devices ...........11 HDMI Connection ASSEMBLING AND PREPARING 4 - Connecting Peripherals...........11 Connecting Headphones - Supported Drivers and Software ......4 - Product and Button Description......5 USER SETTINGS ....... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Open Source Software Notice Information
• It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Illustrations in this document represent typical procedures, so they may look different from the actual product. -
Page 5: Product And Button Description
Product and Button Description Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. •... -
Page 6: Installing On A Table
Installing on a Table Adjusting the Angle • Lift the monitor and place it on the table in an upright position. Place the monitor Place the monitor mounted on the stand base in an upright position. at least 100 mm (3.94 inches) away from the wall to ensure sufficient ventilation. Adjust the angle of the screen. -
Page 7: Using The Kensington Lock
Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the bottom of the This monitor meets the specifications for the wall mount plate or other compatible monitor. devices. For more information on installation and usage, refer to the Kensington lock owner’s NOTE manual or visit the website at http://www.kensington.com. - Page 8 The length of the screw may differ for each wall mounting bracket. Be sure to use A non-VESA standard screw may damage the product and cause the monitor the proper length. to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. •...
-
Page 9: Using The Monitor
USING THE MONITOR Wall Mount Plate • Illustrations in this manual may differ from the actual product. Back of the Monitor Press the joystick button, go to Settings → Input, and then select the input option. CAUTION • Do not press the screen for a prolonged time. This may cause image distortion. Wall Mount Plate •... -
Page 10: Connecting To A Pc
Connecting to a PC DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the *Plug and Play feature. * Plug and Play: A feature that allows you to add a device to your computer without having to reconfigure anything or install any manual drivers. -
Page 11: Connecting Av Devices
Connecting AV Devices Connecting Peripherals HDMI Connection Connecting Headphones HDMI transmits digital video and audio signals from your AV device to the monitor. Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. NOTE •... -
Page 12: User Settings
USER SETTINGS Button Menu Status Description Main menu disabled Enables the main menu. Exits the main menu. NOTE (Holding down the button to turn off the monitor. You can Main menu enabled • Your monitor’s OSD (On Screen Display) may differ turn off the monitor this way at any time, including when the slightly from that shown in this manual. -
Page 13: Main Menu Features
Main Menu Features Main Menu Description Input Sets input mode. Power Off Power Off Turns off the monitor. Settings Configures the screen settings. Exit Input Settings Game Mode Sets the game mode for gaming. Exit Exits the main menu. Game Mode... -
Page 14: User Settings
User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Settings. Configure the options by moving the joystick up/down/left/right. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it. - Page 15 Game Mode on SDR(Non-HDR)signal. Settings > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 16 Game Mode on HDR signal. Settings > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 17 Settings > Game Adjust Description This mode minimizes motion blur in fast-moving videos. To take full advantage of this function, select 3440 x 1440 before enabling 1ms Motion Blur Reduction. This function is available for the following vertical frequency. (HDMI 85Hz, DP 100,144,160Hz) Turns 1ms Motion Blur Reduction Mode off.
- Page 18 Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output signal. CAUTION • Supported Interface: DisplayPort. • Supported Graphic Card : A graphic card that supports AMD’s FreeSync is necessary. FreeSync Premium •...
- Page 19 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Once Faster Mode is selected, Motion Blur may occur depending on the content. Response Time Faster Sets the response time to Faster.
- Page 20 Settings > Picture Adjust Description Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. Mode 1, Mode The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes.
- Page 21 Adjusts the brightness automatically according to the screen. Disables the DFC feature. Do you want to reset your picture settings? Picture Adjust Picture Reset Cancel the select. Returns to the default settings.
- Page 22 Settings > Input Description Input List Selects the input mode. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input. Original Displays video according to the aspect ratio of the video signal input. Aspect Ratio Input NOTE...
- Page 23 Settings > General Description Language Sets the menu screen to the desired language. High Saves energy using the high-efficiency SMART ENERGY SAVING feature. Saves energy using the low-efficiency SMART ENERGY SAVING feature. Disables the SMART ENERGY SAVING feature. SMART ENERGY SAVING NOTE •...
- Page 24 This feature disables the configuration and adjustment of menus. Enables OSD Lock. Disables OSD Lock. OSD Lock NOTE General • All features are disabled except Brightness, Contrast in Picture Adjust, Input, OSD Lock and Information in General. Information The display information will be shown the Total Power On Time, Resolution. Do you want to reset your settings? Reset to Initial Cancel the select.
-
Page 25: Troubleshooting
Have you installed the display driver? • Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function. Some features are disabled. - Page 26 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
- Page 27 The display color is abnormal. Does the display appear discolored • Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > Menu > Color Quality. (The settings (16 colors)? may differ depending on the operating system (OS) you use.) Does the display color appear unstable or •...
-
Page 28: Product Specification
PRODUCT SPECIFICATION LCD Screen Color Depth 8-bit / 10-bit color is supported. Resolution Max Resolution 3440 x 1440 @ 85 Hz (HDMI) 3440 x 1440 @ 160 Hz (DP) Recommended Resolution 3440 x 1440 @ 85 Hz (HDMI) 3440 x 1440 @ 160 Hz (DP) Power Sources Power Rating 19 V... - Page 29 Dimensions Monitor Size (Width x Height x Depth) With Stand 809.0 x 483.3 x 223.2 (mm) 31.8 x 19.0 x 8.7 (inches) Without Stand 809.0 x 358.9 x 91.5 (mm) 31.8 x 14.1 x 3.6 (inches) Weight (Without Packaging) With Stand 6.8 kg (14.9 lbs) Without Stand 5.8 kg (12.7 lbs)
-
Page 30: Factory Support Mode (Preset Mode, Pc)
Factory Support Mode (Preset Mode, PC) (DisplayPort) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 60.0 1920 x 1080 67.5 3440 x 1440 88.84 59.99 3440 x 1440... -
Page 31: Hdmi Timing (Video)
(HDMI) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 3440 x 1440 43.76 29.95 3440 x 1440 73.63 49.95 3440 x 1440 127.35 84.96... -
Page 32: Beep Guide
Beep Guide Menu Location Menu Location Menu Location Game Mode Game Adjust - Response Time - Fast 2 4 2 Picture Adjust - Gamma - Mode 4 3 4 4 Game Mode - Gamer1 Game Adjust - Response Time - Normal 2 4 3 Picture Adjust - Color Temp Game Mode - Gamer2... - Page 33 Menu Location Menu Location Menu Location Picture Adjust - Six Color - Cyan Input - Aspect Ratio - Original 4 2 2 General - SMART ENERGY SAVING 3 7 8 Slider Saturation General - SMART ENERGY SAVING - Input - Auto Input Switch 5 2 1 Picture Adjust - Six Color - Magenta High...
- Page 34 Menu Location General - Information General - Reset to Initial Settings General - Reset to Initial Settings - No 5 9 1 General - Reset to Initial Settings - Yes 5 9 2...
- Page 35 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com The model and serial number of the product are located on the back and on one side of the product.
