Before operating your new machine, read this manual carefully and pay particular attention to the "IMPORTANT
SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power equipment can be dangerous if used
improperly. Also keep in mind that SAFETY requires careful use in accordance with the operating instructions
and common sense!
NOTE: Specifications are correct at time of printing and are subject to change without notice.
Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors.
COPYRIGHT © 2004
SNAPPER – A DIVISION OF SIMPLICITY MFG., INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
PUSH YARD VACUUM
RESIDENTIAL MODELS
Model
SV25550HC
SV25675B
SV25650B
COMMERCIAL MODELS
Model
SV25500HV
SV25550HV
MANUAL No. 7050477 (I.R. 9/17/04)
SERIES 0
Mfg. No.
7085638
1696095
7085687
Mfg. No.
7085644
7085642
3092650
6/17/2011
Rev. -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simplicity SNAPPER SV25550HC
Summary of Contents for Simplicity SNAPPER SV25550HC
- Page 1 NOTE: Specifications are correct at time of printing and are subject to change without notice. Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors. COPYRIGHT © 2004 SNAPPER – A DIVISION OF SIMPLICITY MFG., INC. ALL RIGHTS RESERVED MANUAL No. 7050477 (I.R. 9/17/04)
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: This powerful machine is capable of amputating hands and feet and can throw objects that can cause injury and damage! Failure to comply with the following SAFETY instructions could result in serious injury or death to the operator or other persons. The owner of the machine must understand these instructions and must allow only persons who understand these instructions to operate machine. - Page 3 IMPORTANT SAFETY INSTRUCTIONS SAFE HANDLING OF GASOLINE OPERATION (Continued From Previous Page) (Continued From Previous Column) 3. DO NOT remove fuel cap or add fuel with the engine 12. Engine must be completely STOPPED before running. Allow the engine to cool before refueling. removing debris bag.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................2-3 TABLE OF CONTENTS ..................... 4 SETUP INSTRUCTIONS ....................5 SECTION 1 – FAMILIARIZATION ..................6-7 Nomenclature ......................... 6 Safety and Instruction Labels..................7 SECTION 2 - OPERATING INSTRUCTIONS ..............8-9 Pre-start Checklist ......................8 Starting Engine ......................9 Stopping Engine ...................... -
Page 5: Setup Instructions
SETUP INSTRUCTIONS The majority of the assembly has been completed at the factory. After removing the machine from the shipping container you will be required to unfold the handles, attach the debris bag, and insert the accessory plug into the vacuum nozzle. Initial adjustments and operational tests were performed prior to shipping the machine. -
Page 6: Section 1 - Familiarization
Section 1 – FAMILIARIZATION ENGINE SPEED CONTROL CHOKE FAST HEIGHT CONTROL ENGINE SPEED CONTROL SLOW STOP DEBRIS BAG BRIGGS HONDA (PRIMER) (CHOKE) VENT, WITH ZIPPERS DISCHARGE DOOR ENGINE PRIMER VACUUM NOZZLE ACCESSORY PLUG FIGURE 1.1 1.1 INTRODUCTION 2.2.2 NOMENCLATURE This manual has been prepared for the operator’s of the The nomenclature picture above, Figure 1.1, shows the Yard Vacuum. -
Page 7: Safety And Instruction Labels
Section 1 – FAMILIARIZATION 1.3 SAFETY AND INSTRUCTION LABELS The safety and instruction labels included with your Yard Vacuum are very important. Read, understand and follow all instructions and warnings. Keep these labels clean and legible at all times. Replace any labels that are lost or can no longer be read. -
Page 8: Section 2 - Operating Instructions
Section 2 – OPERATING INSTRUCTIONS 2.1 PRE-START CHECK LIST Read, understand and follow instructions and BAG ADAPTER MOUNTED. warnings in this manual and on the machine, engine and attachments before operating. Know the controls ATTACHED TO and the proper use of the machine before starting. HANDLES. -
Page 9: Starting Engine
Section 2 – OPERATING INSTRUCTIONS 1. Adjust height of vacuum inlet. For maximum WARNING debris pickup, inlet should be as close to debris Entire debris bag and bag adapter must be properly as possible without blocking airflow and engine installed before starting engine. The debris bag and speed set to “FAST”. -
Page 10: Section 3 - Maintenance Instructions
Section 3 – MAINTENANCE 3.2.2. SERVICE ENGINE AIR CLEANER WARNING The engine is equipped with a dual element air DO NOT attempt any adjustments, maintenance, cleaner. Both the foam pre-cleaner and cartridge service or repairs with the engine running. STOP require service. -
Page 11: Section 4- Adjustments And Repair
Section 4 - ADJUSTMENTS & REPAIR 4.3 IMPELLER HOUSING LINER REPLACEMENT WARNING (Commercial Models Only) DO NOT attempt any adjustments, maintenance, The impeller housing liner is a wear item and can service or repairs with the engine running. Stop be replaced. To inspect the impeller housing and engine. -
Page 12: Troubleshooting
TROUBLESHOOTING PROBLEM PROBABLE CAUSE CORRECTIVE ACTION 1. Fuel tank empty. 1. Fill fuel tank with fresh fuel to proper level. Engine Will Not Start Using 2. Engine needs choking or priming. 2. Move control to “CHOKE”, press primer. Recoil Starter 3. -
Page 13: Maintenance Schedule
MAINTENANCE SCHEDULE EACH EACH SUBJECT SERVICE REFERENCE HOURS HOURS HOURS HOURS SEASON TO BE PERFORMED PAGES Engine Check Oil Level Page 8 Engine Initial Oil Change Page 10 Engine Periodic Oil Change Page 10 Air Pre-Cleaner Service Sponge Pre- Engine Manual Cleaner Element Air Cleaner Replace Element... -
Page 14: Product Registration Form
3092649 Manual No. 3004100 PUSH YARD VACUUM TP 400-5085-C-VA-G SERIES 0... - Page 15 HANDLES, CONTROLS, BAG Item Part No Description Note 7075801 HANDLE, Upper Was ASSY 7058669 Included Foam Grip, Part No. 26216 7022779 GUIDE, Pull Rope 7079577 SCREW, 1/4-20 x 1-1/2" Hex Head Cap, GR5 7076978 NUT, 1/4-20 Hex Nyloc 7075800 HANDLE, Height Adjust 7091315 WASHER, 5/16"...
- Page 16 ENGINE, IMPELLER, HOUSING, WHEELS 3092649 Manual No. 3004100 PUSH YARD VACUUM TP 400-5085-C-VA-G SERIES 0...
- Page 17 ENGINE, IMPELLER, HOUSING, WHEELS Item Part No Description Note 6.75 Series B&S VS 126L02-0156-F1 123K02-0140 * ENGINE, 6.5HP B&S Quantum Modular XRM, was 123K02-0126-E1 Recoil Start (A1072) 7034902 PLATE, Engine Base Vacuum Universal replaces 7075793 7044853 WELDMENT, Upper Housing 7075807 ASSEMBLY, Hinge Door 7091604 BOLT, 1/4-20 x 1/2"...
- Page 18 DECALS 3092649 Manual No. 3004100 PUSH YARD VACUUM TP 400-5085-C-VA-G SERIES 0...
- Page 19 DECALS Item Part No Description Note 7075861 DECAL, GIANT VAC Logo 7013010 DECAL, Danger, Cut Finger 7022841 DECAL, WARNING Euro models only 7075892 DECAL, Thrown Objects 7075893 DECAL, Personal Protection 7075894 DECAL, Warning, Vacuum 7029776 DECAL, Euro Community (CE) Euro models only 7074329 DECAL, SOUND 110 Euro models only...
- Page 20 PRODUCT REGISTRATION FORM IMPORTANT: KEEP THIS INFORMATION FOR YOUR PERSONAL RECORDS (Complete the following information on your new purchase) Model _____________________________________________________________________ Manufacturer Number ______________________________________________________ Serial Number _____________________________________________________________ Date of Purchase ___________________________________________________________ Retailer____________________________________________________________________ Retailer’s Phone Number ____________________________________________________ A product registration card has been included with your new purchase. It is very important that you register your purchase with the manufacturer to ensure warranty coverage.
- Page 21 NOTES ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________...
- Page 22 ENGINE EXHAUST, SOME OF ITS CONSTITUENTS, AND CERTAIN VEHICLE COMPONENTS CONTAIN OR EMIT CHEMICALS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER OR OTHER REPRODUCTIVE HARM. COPYRIGHT © 2004 SNAPPER – A DIVISION OF SIMPLICITY MFG., INC. ALL RIGHTS RESERVED 3092650 MANUAL No. 7050477 (I.R. 9/17/04)
