- Page 1 SEED-10IA-55 User Manual Display Screen SEED-10IA-55 User Manual | Shanghai Rising Digital Co.,Ltd.
-
Page 2: General Introduction
SEED-10IA-55 User Manual General introduction As an on‐board display screen, SEED-10IA-55 can meet the needs of human‐computer interaction, network connection, data storage, multimedia audio‐visual entertainment under adverse working conditions such as construction machinery and special machinery. In the engineering automation situation, IPC can be replaced as monitoring station equipment. High‐Performance:Dual Core Processor, 800MHz, 1G Memory, 8G Hard Disk Universality: Intelligent Operating System, Configuration Software Beautiful shape: flat panel, capacitive touch screen; antenna built‐in Wireless Networking: GPRS/4G, BT, GPS | Shanghai Rising Digital Co.,Ltd. - Page 3 SEED-10IA-55 User Manual Catalog Functions and Characteristics ....................1 1、 Integration of Display and Communication ............... 1 2、 General Configuration Program Development Environment ........ 1 3、 Adapt to harsh environment .................. 1 4、 Seamless connection of remote monitoring system .......... 1 Functional description of External interface ................1 1、 External characteristics ..................... 1 2、 Port Definition of 34 Pin Plug‐in ................ 2 Development and debugging .................... 3 1、 Hardware platform .................... 3 2、 Software Development Platform ................ 3 3、 ...
-
Page 4: Functions And Characteristics
SEED-10IA-55 User Manual Functions and Characteristics 1、Integration of Display and Communication Display：10.4 inch, 1024 x 768 resolution, industrial TFT LCD screen, capacitive touch Communication：Supporting 4G/GPRS/BT wireless communication， Support GPS/BD positioning， Supporting CAN communication,compatibleJ1939 / CANOpen / CAN2.0B agreement Camera: Supports 4 analog cameras, single, 2-partition, 4-partition display 2、General Configuration Program Development Environment ... - Page 5 SEED-10IA-55 User Manual 2、 Port Definition of 34 Pin Plug‐in Function definition port number 1 CAN2_H 2 NC 3 SET 4 +12VOUT 5 CAN1_L 6 CAN1_H 7 CAMRA2_V‐ 8 GND 9 +5V OUT 10 CAN2_L 11 NC 12 +12VOUT CAMRA1_V+ CAMRA1_V‐ CAMRA2_V+ CAMRA3_V‐ 18 NC ...
- Page 6 SEED-10IA-55 User Manual 22 CAMRA4_V‐ 23 CAMRA3_V+ 24 GND 25 24V in 26 NC 27 TX232 28 RX232 29 RS485_A RS485_B NC NC +24V in Development and Debugging 1、 Hardware platform The configuration development software QT is installed on the PC. The power supply and camera are connected to the display screen, and the platform is built.
- Page 7 SEED-10IA-55 User Manual Supporting configuration software, using standard IDE development environment, can develop applications according to project requirements. You can refer to the commonly used sample programs to develop applications quickly. Include： 1） QuickStart Human-Machine Interface, including Common Man-Machine Operating Controls 2）...
- Page 8 SEED-10IA-55 User Manual （2）Update device tree, serial console input command：run update_fdt （3）Update Kernel, Serial Console Enter Command：run update_kernel Install 1、 Installation Dimensions 2、 Installation method 4×M6 Screws (including spring washers, flat washers) 3、 Installation accessories Electrical connectors should be equipped with when choosing products. The following table is recommended： Number Product name Model Icon Manufacturer AMP Plug‐in socket 1 4‐1437290‐0 sheath Tyco Electronlcs 2 AMP Plug‐in metal pin 3‐1447221‐3 Tyco Electronlcs 5 | Shanghai Rising Digital Co.,Ltd. ...
- Page 9 SEED-10IA-55 User Manual Description of product parameters and environmental indicators Number Detailed Product name Video input 4 channel，PAL / NTSC signal 12 V OUT 2 channel CAN：2 channel，Rate selectable ISO11898 CAN2.0B、J1939、 CanOpen； USB：1 channel，USB2.0； 4G，Antenna built-in： FDD LTE: B5 TDD LTE: B41 Communication 2G：850MHz/1900MHz...
- Page 10 SEED-10IA-55 User Manual working temperature：- 25 ~ 65 °C Storage temperature：- 30 ~ 80 °C Overvoltage protection：37.2 V Work environment Anti vibration：4 - 300 HZ 10mm 5G Impact resistance：50G 6ms & 11ms Relative temperature：10 % ~ 95 % Protection level：IP 65...
- Page 11 SEED-10IA-55 User Manual Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
