- Page 1 Instruction Manual FY-2HF This equipment is approved by the following car manufacturers (China)
-
Page 2: Table Of Contents
Contents 1. Precautions 2. Specifications 3. Installation 4. Controls 5. Operation 6. Troubleshooting 1) Troubleshooting 2) Lamp Tube Replacement 7. Exploded View 8. Circuit Diagram... -
Page 3: Precautions
1. Precaution 1. Read this manual carefully before installing or servicing this equipment. 2. This equipment is designed for paint drying applications. Adjust to the correct temperature and check minimum safe distance from the heat source when using. Improper servicing can cause paint surface damage. 3. -
Page 4: Specifications
2. Specifications FY-2HF Model Input power source Single Phase 220V 50/60Hz Input power (W) 2 × 1000 Curing Area (mm) 1200 × 1000 Temperature (°C) 35 - 80 Time Setting 0 - 60mins adjustable Light Intensity (%) 10% - 100%... -
Page 5: Installation
3. Installation The shortwave infrared curing lamp is divided into 3 parts (a base, a frame and a cassette) 1) Installation of the base: a. Open the packing of the base. b. Install the four wheels on the base and tighten up the screws. Usually, the wheels with brakes are mounted on the rear of the base. -
Page 6: Controls
4. Controls OPERATING VOLTAGE AC220V-240V 50/60Hz POWER CONTROL SYSTEM TIME CONTROL SYSTEM 1. Operating Voltage 2. Power Adjustment 3. Time Adjustment Page 4... -
Page 7: Operation
5. Operation Connection of electrical supply. Make sure that the supply cable is at least 4mm at 220V. Note: Make sure that the facility supply voltage and frequency are the same as shown on the equipment name plate. Connect to AC 220V power supply. Switch on the equipment. The LED display will show the normal voltage as 220V. -
Page 8: Troubleshooting
6. Troubleshooting 1. Troubleshooting PROBLEM CAUSE SOLUTION 1) Lamp tube damaged 1) Check lamp tube Lamp tube does not work 2) Lamp tube not plugged in 2) Check connections 3) Check control silicon 3) Control silicon damaged Lamp tube does not turn off 1) Control silicon damaged 1) Check control silicon 1) Unplugged flat wire in... -
Page 9: Lamp Tube Replacement
6. Troubleshooting 2. Lamp Tube Replacement 1) Prepare cassette for replacement 2) Remove the grille of cassette ( 2) 3) Remove the plates from both ends of the cassette ( 3) 4) Remove the fixed plates from both ends of the cassette ( 4) 5) Loosen fixed screws and cut off connections, the lamp can be... -
Page 10: Exploded View
7. Exploded View Page 8... -
Page 11: Circuit Diagram
8. Circuit Diagram Page 9...
