INCA
CONTROL PTY LTD
UNIT 14/62 OWEN ST
GLENDENNING NSW 2761
A.B.N 54 131 353 636
Design & Manufacture of:
Custom-built switchboards
Electronic control equipment
AC/DC pumping controls
Installation & service
TRIPLEX PRESSURE SYSTEM VARIABLE
PVJ3
INCA MODEL
PVJ3
SPEED CONTROLLER
USER MANUAL
Inca Reference PVJ3
Software Version 1.7
Technical Support
Pumps & Mechanicals – Pump supplier
Controls – Inca Control Pty Ltd
Phone 02 9675 3815
Phone: (02) 9675 3815
Fax:
(02) 9675 1381
Email: sales@incacontrol.com.au
Web:
www.incacontrol.com.au
1
page 1
Advertisement
Table of Contents
Related Manuals for Inca PVJ3
Summary of Contents for Inca PVJ3
- Page 1 Installation & service INCA MODEL PVJ3 TRIPLEX PRESSURE SYSTEM VARIABLE SPEED CONTROLLER USER MANUAL Inca Reference PVJ3 Software Version 1.7 Technical Support Pumps & Mechanicals – Pump supplier Controls – Inca Control Pty Ltd Phone 02 9675 3815 PVJ3 page 1...
-
Page 2: Table Of Contents
Standby Start Time Setting.……………………………….. 4.10 2 Standby Stop time Setting………………………………… 4.11 2 4.12 Maximum continuous running time ……………………………. 4.13 Hour run meter………..……………………………………… 4.14 Data Logger................10 4.15 Auto Tune.................. 11 Operation……………………………………………………………… System operation……………………………………………….. Manual/off/auto selector………………………………………. Warranty Statement…………………………………………………… Drawing supplied separately PVJ3 page 2... -
Page 3: Control Panel Overview
1.0 Control Panel Overview Features PVJ3 controller with user friendly setup & display Display of system Pressure Low pressure pump shutdown Low level pump shutdown with automatic reset Manual/off/auto selectors on panel Face Hour run meter (resetable) ... - Page 4 Do not install in areas of high humidity. Locate control panel internally where possible to help reduce heat & weather damage & increase mechanical life. Vibration Do not install in a location that is subject to large amounts of vibration. PVJ3 page 4...
-
Page 5: Installation
2.0 Installation Note: If any damage to control panel if found, please notify Inca Control Pty Ltd as soon as possible prior to installation. The control panel can be wall mounted separately from the pumping unit; distance is governed by the cable sizing to the motor. -
Page 6: Maintenance
Check that all connections are tight as copper is soft & can work loose. Check that all controls are functioning as intended. Check & ensure that the ventilation mats are regularly cleaned as reduced air flow will damage drives. PVJ3 page 6... -
Page 7: Start Up
The screen displays two lines of information The top line displays the live discharge pressure in kPa. The bottom line displays each Pump motor speed in %. (P1S for Pump 1 & P2S for Pump 2) PVJ3 page 7... -
Page 8: Calibration
Simply type in the appropriate pressure you want the pumps to maintain the System at, example 400kPa Press 4, press 0, press 0 & then press Return Arrow button. Press the RIGHT ARROW Button to move onto the next Page. PVJ3 page 8... -
Page 9: Start Pressure Setting
Standby Start Speed has been reached, example 20seconds Press 0, press 0, press 2, press 0 & then press Return Arrow button. Press the RIGHT ARROW Button to move onto the next Page. PVJ3 page 9... -
Page 10: Standby Stop Time Setting
FUNCTION (Up arrow) button. The first two pump hours run meters will be displayed. Press the function button again & the 3 pump hours run meter is displayed, press the function button PVJ3 page 10... -
Page 11: Auto Tune
To carry out an auto tune ensure that 1-off selector is in auto, press& hold the LEFT ARROW button for 5seconds the display will flash AUTO-TUNE IN PROGRESS until auto tune is complete. During this time you cannot access other screens. PVJ3 page 11... -
Page 12: Operation
1. The system pressure has reached & maintains set point pressure less 5kPa. 2. The motor speed is less & maintains less than the speed set in PUMP STOP MINIMUM SPEED. 3. And the time value entered into parameter STANDBY STOP TIMER. PVJ3 page 12... -
Page 13: Manual/Off/Auto Selector
Selecting MANUAL will turn the pump on continuously at a fixed full speed. Selecting OFF will turn the pump off. Auto Selecting AUTO will select the pump on automatic & is then controlled via the set points within the PVJ3 controller. PVJ3 page 13... -
Page 14: Warranty Statement
In addition to the above, equipment manufactured, installed & commissioned by Inca Control Pty Ltd, within the Sydney Metropolitan Area, includes onsite replacement. In any event Inca Control Pty Ltd has no other obligation or liability beyond replacement or repair of this product. NOTES:...
