Summary of Contents for MT MTPA0050-1
- Page 1 MTPA0050-1 Broadband Power Amplifier Operation Manual...
- Page 2 1．Product Description The MTPA0050-1 Amplifier is a broadband, high power, high gain instrumentation grade amplifier. The amplifier was designed to provide exceptional gain flatness per octave over greater than 5 octaves of frequency coverage. The 10 MHz to 50 GHz amplifier provides up to 28dB of gain and 30dBm output power with low harmonics and low residual phase noise.
- Page 3 2．Specification ENVIRONMENTAL SPECIFICATIONS Parameter Unit Min. Typical Max. Voltage V(AC) Current@220V Operating Temperature ºC Non-Operating Temperature ºC MECHANICAL SPECIFICATIONS: Parameter Unit Min. Typical Max. 200×150×52 Dimensions LxWxH inch 7.87×5.91×2.05 Weight RF Input&Output 1.85mm Female MODEL APPEARANCE Unit：mm(inch)
- Page 4 3．Operational Instructions Always keep the voltage within 110-220V. It is suggested to connect the AC power wire first, then turn on the rear AC switch. Finally, switch on the front DC button. The MAX input power is +15dBm . ...
