ISDI-08
Assembly Instructions
for the In-Swinging Door
Deluxe 3-Season Sunroom, Standard 3-Season Room, Deluxe Screen Room and
Full Screen Room Installation of the Handle, Latch, Deadbolt & Closer
Read the instructions before starting the job. They explain the steps required
to produce a fi nished product that will meet factory specifi cations.
All references to "Left" and "Right" are while facing the home.
Check the material received.
Safety is important!
Match your shipment with the Bill of Materials.
Wear Safety Glasses and Work Gloves.
If there is a shortage or wrong material,
Follow all safety practices while assembling
call Dealer Service immediately.
and installing this product.
Dura-Bilt Products, Inc. P.O. Box 188 Wellsburg, N.Y. 14894
Dealer Service 570-596-2000 E-Mail info@durabilt.com
DURA-BILT RESERVES THE RIGHT TO CHANGE DESIGN AND/OR SPECIFICATIONS WITHOUT NOTICE.
Advertisement
Table of Contents
Summary of Contents for DURA-BILT In-Swinging Door
- Page 1 If there is a shortage or wrong material, Follow all safety practices while assembling call Dealer Service immediately. and installing this product. Dura-Bilt Products, Inc. P.O. Box 188 Wellsburg, N.Y. 14894 Dealer Service 570-596-2000 E-Mail info@durabilt.com DURA-BILT RESERVES THE RIGHT TO CHANGE DESIGN AND/OR SPECIFICATIONS WITHOUT NOTICE.
- Page 2 Door Closer Components and Instructions Push Retainer Closer Bracket Connecting Pin Closer Bracket Door Bracket 3/16” Dia. X 3/4” long Closer Bracket Screws (#10 x 1” Panhead Phillips Door Bracket Pin Hold Open Washer Sheet Metal Screw) Hole 1 Slower Faster Hole 2 Instructions...
- Page 3 Door Handle Components and Instructions Inside Handle Outside Handle Spindle #6 X 1-3/8” Pan Head Phillips Screw Striker Aluminum Shim #8 X 1-1/2” Flat Head 3-3/4” long x 3/4” Wide Phillips Door Inside Outside 1. Insert the Spindle into the Outside Handle and line up holes, then push the Outside Handle on to the door. 2.
- Page 4 Deadbolt Components and Instructions CURVED LIP STRIKE LOCK CYLINDER SPINDLE OUTSIDE DEADBOLT PLATE DEADBOLT Step 1 Assemble key and cylinder to outside deadbolt plate by inserting the key and cylinder into the outside deadbolt plate and turning the key one half turn. Remove key from cylinder prior to further installation. Step 2 Cut spindle to 3/4”...
