Shampoo Bowl
User Manual
Package Contents
Bowl x 1
Faucet x 1
Vacuum Breaker x 1
Sprayer x 1
Hose x 1
Strainer x 1
Page 1
Safety Instructions
1.
Before using the product, ensure that all of the parts are
connected firmly.
2.
It is the responsibility of the user or the installer to make sure
that the installation of this product conforms to local
plumbing codes and regulations.
3.
Keep the small parts of this product away from children to
avoid risk of choking.
4.
Children should not use this product unless sufficient
supervision is provided by adults.
5.
Regularly clean the hair trap as it might be congested by
hair.
6.
Ensure that the bowl is hung securely on the mounting
bracket first before using.
Drain Hose x 1
Mounting Bracket x 1
Mounting kit
(for Vacuum Breaker) x 1
Mounting kit
(for Mounting Bracket) x 1
Neck Rest x 1
Hair Trap x 1
Converter (3/8") x 2
Base
(for Vacuum Breaker) x 1
Advertisement
Summary of Contents for Yescom 12SPB003-F-S-06
- Page 1 Safety Instructions Shampoo Bowl Before using the product, ensure that all of the parts are User Manual connected firmly. It is the responsibility of the user or the installer to make sure that the installation of this product conforms to local plumbing codes and regulations.
-
Page 2: Specifications
Specifications Shampoo Bowl Size 19” x 20” x 11” (L x W x H ) (48 x 50 x 27 cm) Assembly Instructions Loosen the two iron rings from the vacuum breaker as shown Thread the vacuum breaker through base and secure it with the above. - Page 3 Thread the faucet through the hole of the bowl and secure it with the iron washer which is preinstalled on the faucet. Connect the Connect the hose to the thread of the faucet. other end of the hose to the longer thread of the vacuum breaker. Loosen the plastic ring and the rubber gasket from the Install the strainer on the bottom of the bowl.
- Page 4 These parts preinstalled on the hair trap. You need to loosen them out first. Ensure rubber gasket is in the hose before installing it Connect the plastic hose to the bottom of the strainer. Connect the hair trap to the plastic hose. Install the mounting bracket onto your wall with the mounting kit (for mounting kit.) Install the neck rest onto the bowl.
- Page 5 If necessary, use the converter (from 1/2” to 3/8”) These two hoses should be connected to hot and cool Ensure this water supply respectively. fastened firmly. ( ⌀:1/2”) Hang the bowl onto the mounting bracket. This part should connected waste water drainage.
