Summary of Contents for Orava LiveBass2 Gaming
- Page 1 Gaming Instruction manual Gaming headphones with USB and microphone...
-
Page 2: Intended Use Of The Device
• ORAVA electrical appliances are manufactured in accordance with the state of the art and recognized safety regulations. Nevertheless, incorrect and unprofessional use or use contrary to the intended purpose may create a risk of injury or endanger the life of the user or a third party, resp. - Page 3 Unpacking/Packaging • Unpack the device and accessories before putting them into operation and dispose of all parts that increase the packaging materials, labels and tags. • Store packaging materials in a safe place or keep them out of the reach of children and incompetent persons.
- Page 4 • If the device subsequently shows signs of malfunction or damage, take it to a specialist garage for inspection. • Never overload the device beyond the limits set by the technical parameters! • Do not expose the device to: - direct sunlight, sources producing excessive heat, - vibration and mechanical stress, - chemical pollutants, - water and excessive humidity,...
-
Page 5: Description Of Parts
• Do not use the device in areas with flammable liquids, gases or dust. The device can be a source of sparks, which can result in the ignition of dust or fumes. Characteristics of the operating environment 1. Ambient temperature: +5 - +40 °... -
Page 6: Headphone Connection
Headphone connection The headphones allow you to listen to the sound from the connected external device. PC connection • Connect the USB cable to the computer, then connect the reducer (7) to the 3.5 mm jack and connect it to the PC - audio link (green) and microphone (red). -
Page 7: Troubleshooting
Troubleshooting It is recommended that you connect this device directly to a USB port on your computer. When connecting a device via a USB hub (hub), make sure that your USB hub (hub) and the USB port on the computer to which it is connected are capable of supplying enough power to power all devices connected to the same USB hub (hub). - Page 8 Maintenance and information Cleaning the surface of the device Use a soft cloth slightly moistened with water to clean the surface of the device and controls. Do not use any type of abrasive pad, scouring powder, or solvent, such as thinner, petrol, or alcohol.
-
Page 9: Technical Specifications
Technical specifications Microphone Type: omnidirectional, electret capacitor Dimensions: 6 x 2.2 mm Sensitivity: - 42 dB ± 3dB Frequency: 100 - 16 kHz Headphones Type: closed stereo headphones Rated power: 20 mW Headphone speakers: closed, dynamic, 2x drivers with a diameter of 50 mm Frequency range of reproduction: 20 Hz - 20 kHz Impedance: 32 ohm ±... - Page 10 DECLARATION OF CONFORMITY Short text Declaration of Conformity: ORAVA retail 1, a.s. hereby declares that the LiveBass 2 C/B Gaming complies with the essential require- ments and other relevant conditions of Directive 2014/53/ EU of the European Parliament and of the Council.
