Summary of Contents for Philips 286NS-05

  • Page 1: Table Of Contents

    Copyright reserved 1998 Philips Consumer Electronics B.V. Eindhoven, The Netherlands. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise...
  • Page 2: Technical Specifications

    Technical specifications Comet : 220-240V ± 10% AC; Mains Voltage: Technical specifications 50-60Hz (± 5%) Mains frequency : 50 Hz : 60 Hz Power Consumption in stand-by : < 5 Watt Power Consumption normal mode : 28” : 75Watt +/- 10% Aerial input impedance TV : 75 Ohm - coax Min.
  • Page 3: Connection Facilities

    Connection facilities Comet Connection facilities R (0.5Vrms ≤1kΩ) 1 - Audio R (0.5Vrms ≥10kΩ) 2 - Audio L (0.5Vrms ≤1kΩ) 3 - Audio 4 - Audio 5 - Blue L (0.5Vrms ≥10kΩ) 6 - Audio 7 - Blue (0.7Vpp/75Ω) 8 - CVBS- status 0-1.3V:INT, 4.5-7V:EXT 16:9, 9.5- 12V:EXT 4:3...
  • Page 4: Safety Instructions, Maintenance Instructions

    Safety instructions, Maintenance instruction, Comet Safety instructions for repairs – When the set is used in circumstances with higher dust, Safety instructions, Maintenance instruction, Warnings and Notes grease or moisture levels, for example in a kitchen, the recommended interval is 1 year. –...
  • Page 5 Safety instructions, Maintenance instruction, Comet 3. Where necessary, the oscillograms and direct voltages are measured with and without aerial signal. Voltages in the power supply section are measured both for normal operation and in standby . These values are indicated by means of the appropriate symbols (see fig.
  • Page 6: Mechanical Instructions

    Mechanical instructions Comet For the main carrier two service positions are possible: Position A can be reached by first removing the mains cord Mechanical instructions from it's fixation, then loosen the carrier lips and then pulling the a. For faultfinding on the component side of the main carrier carrier panel for approximately 10 cm.
  • Page 7: Repair Facilities

    Repair facilities Comet Functional blocks Repair facilities Service default-alignment menu: new option settings are activated immediately. On both the service printing on the copper and the component 1. Software version of the microprocessor used in that typical side, functional blocks are indicated by lines and text. set is displayed in the right top corner 2.
  • Page 8 Repair facilities Comet SYSTEM I:UK --> For a PAL I only set SYSTEM BG+LL' -->For a PAL BG/SECAM LL' set SYSTEM BG+DK --> For a PAL BGI/SECAM LL' set NATIONAL BRAND MAxxxxx --> Selects MENU-Layout National Brand styling 5.1.3 Error messages 1.
  • Page 9: Electrical Adjustments

    Electrical adjustments Comet Adjustments on the 110 module panel Electrical adjustments 1. Horizontal amplitude: Is adjusted with potentiometer R3924 2. Vertical centring: Is adjusted with potentiometer R3921 3. Picture height: Is adjusted with potentiometer R3903 4. East-west correction: Is adjusted by potentiometer R3913 5.
  • Page 10: Circuit Description

    CIRCUIT DESCRIPTION Comet Description of the power supply: 9.1.5 Output voltage regulation: CIRCUIT DESCRIPTION This is done by the circuit D6501, R3509, TS7502, R3505, 9.1.1 General R3507, R3510. Transistor TS7502 can only conduct when the voltage on the base is 0V7 lower than the voltage the voltage Note: The voltages +96S and +96s are not mains isolated.
  • Page 11 CIRCUIT DESCRIPTION Comet mains. The optocoupler is driven by pin 37 of IC7100-6E via 110 degrees deflection module transistor TS7103. When TS7103 is not conducting,(the LED of the optocoupler is also out of conduction) TS7421 is also not For the 25" and 28" sets a 110 degrees module is needed for conducting.
  • Page 12 CIRCUIT DESCRIPTION Comet 9.7.4 Line timebase Vertical Synchronisation and Frame Amplifier The control voltage of pin 37 of the Bimos ic (=ic7100) is 9.9.1 The Vertical Sync Separator derived via opto coupler pos 7420 to transistor T7421; then send via C2428 and C2421 to pins 5 and6 of connector 0082; This functional block separates the Frame Synchronisation this is the control of the base of T7906 (=BU1508AX).
  • Page 13 CIRCUIT DESCRIPTION Comet 9.9.11 IF Source Select, Luminance And Chrominance Separation. 9.10.2 Fast Blanking The Baseband Video signal (normal amplitude 2Vpp) at Pin 7 Via the FAST BLANKING signal available at pin 21 RGB input also contains the inercarrier sound signal, however the sound selection is also made.
  • Page 14 10 Direction for use Comet Direction for use...
  • Page 15 10 Direction for use Comet...
  • Page 16 10 Direction for use Comet...
  • Page 17 10 Direction for use Comet...
  • Page 18 10 Direction for use Comet...
  • Page 19 10 Direction for use Comet...
  • Page 20 10 Direction for use Comet...
  • Page 21 10 Direction for use Comet...
  • Page 22: List Of Abbreviations

    11 List of Abbreviations Comet +96S Supply voltage from the SMPS to the line IDENT Status signal from IC7015-6B; "low" for no List of Abbreviations output stage.This voltage is 104V for 21" sets. CVBS signal (horizontal sync not present), +160V Supply voltage from the LOT for the CRT- "high"...
  • Page 23 11 List of Abbreviations Comet Switching signal from the µC for internal or mP INT/EXT external audio + video switching ("low" for external and "high" for internal). VDRIVE Vertical drive signal from IC7015-6E to frame amplifier. Tuning voltage from µC to the tuner (0-30V V-vari DC).
  • Page 24 Overview oscillograms Comet Overview oscillograms V12a 0066 9615 7600 50mV / div AC 5V / div AC 0.5V / div AC 500mV / div AC 50V / div DC 10V / div AC 0.5V / div DC 1ms / div 20µs / div 10µs / div 10µs / div...
  • Page 25 Overview oscillograms Comet...
  • Page 26 Overview oscillograms Comet...
  • Page 27 Electrical diagrams and print lay-outs Comet Electrical diagrams and print lay-outs P1 320V DC 2V / div DC 5ms / div L1 140.3V DC L2 13.6V L3 39V 50V / div DC 5µs / div 500mV / div DC 100mV / div DC 10µs / div 5µs / div 1V / div DC...
  • Page 28 Electrical diagrams and print lay-outs Comet 50mV / div DC 10µs / div 500mV / div AC 10µs / div 500mV / div AC 10µs / div 2V / div DC 5ms / div OSC_A2.AI...
  • Page 29 Electrical diagrams and print lay-outs Comet V11a 50mV / div AC 1V / div DC 1ms / div 20µs / div V11b 20mV / div AC 1V / div DC 1ms / div 20µs / div V12a 100mV / div AC 0.5V / div DC 1ms / div 20µs / div...
  • Page 30 Electrical diagrams and print lay-outs Comet 1V / div DC 0.5µs / div 500mV / div DC 0.5µs / div = 0V OSC_A4.AI...
  • Page 31 Electrical diagrams and print lay-outs Comet = 0V 10V / div AC 10V / div AC 10V / div AC 10µs / div 10µs / div 10µs / div OSC_B.AI...
  • Page 32 Electrical diagrams and print lay-outs Comet 0040 A 2 2904 A 3 2911 C 2 2918 C 2 3905 C 3 3912 A 3 3919 A 2 3926 A 1 3935 B 2 6904 A 2 7903 A 3 0041 B 1 2905 A 1 2912 C 1 2919 A 1...
  • Page 33 Electrical diagrams and print lay-outs Comet 8.6532029_007.ai 140598...
  • Page 34 Electrical diagrams and print lay-outs Comet CL 86532029_008.eps 240698...
  • Page 35 Electrical diagrams and print lay-outs Comet...
  • Page 36 Electrical diagrams and print lay-outs Comet...
  • Page 37 Electrical diagrams and print lay-outs Comet 0025 C 5 0072 G 6 2802 G 2 5800 G 2 9802 B 3 A003 G 4 A007 B 3 A011 G 2 A015 G 6 A019 H 6 0022 A 3 0050 B 6 1600 D 1 A001 D 3 A003 B 2...
  • Page 38: Spareparts List

    12 Spare parts list Comet Chassis Spare parts list 2140 4822 122 33797 47nF 20% 50V 2801 4822 122 31175 1nF 10% 500V 3317 4822 117 11896 1k5 20% 0.5W 2141∆ 4822 126 10002 100nF 20% 25V 2801 4822 126 13599 3.3nF 10% 500V 3318 4822 051 10102 1k 2% 0.25W 2142∆...
  • Page 39 12 Spare parts list Comet 3614∆ 4822 051 20008 0Ω jumper . (0805) 7600 4822 209 16832 SAA5290PS/113 4822 458 50568 LEFT GRILL 28” 3614 4822 117 10833 10k 1% 0.1W 7600 4822 209 16828 SAA5290ZP/095 4822 458 50567 RIGHT GRILL 25” 3616 4822 050 11002 1k 1% 0.4W 7601∆...
