SERVICE MANUAL
DVD RECORDER
PY90DG
OPEN/CLOSE
CHANNEL
PREV
NEXT
STOP
PLAY
STANDBY-ON
REC MODE
REC/OTR
S-VIDEO
VIDEO
L
AUDIO
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E7A02UD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pye Video E7A02UD

Summary of Contents for Pye Video E7A02UD

  • Page 1 SERVICE MANUAL DVD RECORDER PY90DG OPEN/CLOSE CHANNEL PREV NEXT STOP PLAY STANDBY-ON REC MODE REC/OTR S-VIDEO VIDEO AUDIO...

  • Page 2: Table Of Contents

    IMPORTANT SAFETY NOTICE Proper service and repair is important to the safe, reliable operation of all Funai Equipment. The service procedures recommended by Funai and described in this service manual are effective methods of performing service operations. Some of these service special tools should be used when and as recommended.

  • Page 3: Specifications

    SPECIFICATIONS Item Conditions Unit Nominal Limit 1. VIDEO 75 Ω load 1-1. Video Output Vp-p 1-2. S-Video Output 75 Ω load Y (Luminance) Vp-p 75 Ω load C (Chrominance) Vp-p 0.286 1-3. Component Output 75 Ω load Y (Luminance) Vp-p 75 Ω...

  • Page 4: Laser Beam Safety Precautions

    LASER BEAM SAFETY PRECAUTIONS This DVD player uses a pickup that emits a laser beam. Do not look directly at the laser beam coming from the pickup or allow it to strike against your skin. The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your eyes at least 30 cm away from the pickup lens when the diode is turned on.

  • Page 5: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Product Safety Notice Also check areas surrounding repaired locations. J. Be careful that foreign objects (screws, solder Some electrical and mechanical parts have special droplets, etc.) do not remain inside the set. safety-related characteristics which are often not K.
  • Page 6 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts, and wires have been returned to their original positions. Afterwards, do the following tests and confirm the specified values to verify compliance with safety standards. 1.

  • Page 7: Standard Notes For Servicing

    STANDARD NOTES FOR SERVICING Circuit Board Indications Pb (Lead) Free Solder 1. The output pin of the 3 pin Regulator ICs is When soldering, be sure to use the Pb free solder. indicated as shown. How to Remove / Install Flat Pack-IC Top View Bottom View 1.
  • Page 8 3. The flat pack-IC on the CBA is affixed with glue, so With Soldering Iron: be careful not to break or damage the foil of each 1. Using desoldering braid, remove the solder from pin or the solder lands under the IC when all pins of the flat pack-IC.
  • Page 9 2. Installation With Iron Wire: 1. Using desoldering braid, remove the solder from 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder the foil of each pin of the flat pack-IC on the CBA flux which is applied to all pins of the flat pack-IC, so you can install a replacement flat pack-IC more you can remove it easily.
  • Page 10 Instructions for Handling Semi- conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body.

  • Page 11: Cabinet Disassembly Instructions

    CABINET DISASSEMBLY INSTRUCTIONS 1. Disassembly Flowchart Note: (1) Identification (location) No. of parts in the figures This flowchart indicates the disassembly steps to gain (2) Name of the part access to item(s) to be serviced. When reassembling, (3) Figure Number for reference follow the steps in reverse order.
  • Page 12 (S-4) Desolder (L-1) [4] SW CBA [5] PCB Holder S Earth (L-1) (S-3) Plate (L-1) (L-2) [2] Front Assembly Fig. D2 Fig. D4 (S-2) (S-2) [3] DVD Mechanism & DVD Main (S-7) CBA Assembly (S-7) CN101 Heat Sink Earth Plate CN701 Main Sheet [7] AV CBA...
  • Page 13 3. How to Eject Manually Note: When rotating the gear, be careful not to damage the gear. 1. Remove the Top Cover. 2. Rotate the gear in the direction of the arrow manually as shown below until the tray descends. 3.

  • Page 14: How To Initialize The Dvd Recorder

    HOW TO INITIALIZE THE DVD RECORDER To put the program back at the factory-default, initialize the DVD recorder as the following procedure. 1. Turn the DVD recorder on. 2. Confirm that no disc is loaded or that the disc tray is open.

  • Page 15: Firmware Renewal Mode

    FIRMWARE RENEWAL MODE 1. Turn the power on and remove the disc on the tray. 4. Select the firmware version pressing arrow buttons, then press [OK]. 2. To put the DVD recorder into version up mode, Fig. d appears on the screen and Fig. e appears press [CM SKIP], [6], [5], and [4] buttons on the on the VFD.

  • Page 16: Function Indicator Symbols

    FUNCTION INDICATOR SYMBOLS Note: If an error occurs, a message with the error number appears on the screen. Recording Error Error message You cannot record on this disc as Power Calibration Area is full. Error No. Error Message Solution Error Description Priority An error occurs during data reading.
  • Page 17 Error Message Solution Error Description Priority This program is not recordable Set “DVD-RW Recording During the CGMS picture (possible to in Video mode. Format” to “VR mode”. record once) input. (Video Format Disc) During the CGMS picture (possible to This program is not allowed to Insert a ver.1.1 CPRM record once) input.

  • Page 18: Block Diagrams

    BLOCK DIAGRAMS System Control Block Diagram 1-9-1 E7A02BLS...
  • Page 19 Digital Signal Process Block Diagram 1-9-2 E7A02BLD...
  • Page 20 Video Block Diagram 1-9-3 E7A02BLV...
  • Page 21 Audio Block Diagram 1-9-4 E7A02BLA...
  • Page 22 Power Supply Block Diagram 1-9-5 E7A02BLP...

  • Page 23: Schematic Diagrams / Cba's And Test Points

    SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS Standard Notes WARNING Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
  • Page 24 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQES D'INCELE N'UTILISER QUE DES FUSIBLE DE MÊME TYPE. RISK OF FIRE-REPLACE FUSE AS MARKED.
  • Page 25 DVD Main 1/5 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD Main Schematic Diagram Section. 1-10-3 E7A02SCD1...
  • Page 26 DVD Main 2/5 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD Main Schematic Diagram Section. 1-10-4 E7A02SCD2...
  • Page 27 DVD Main 3/5 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD Main Schematic Diagram Section. E7A02SCD3 1-10-5...
  • Page 28 DVD Main 4/5 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD Main Schematic Diagram Section. 1-10-6 E7A02SCD4...
  • Page 29 DVD Main 5/5 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD Main Schematic Diagram Section. E7A02SCD5 1-10-7...
  • Page 30 AV 1/5 Schematic Diagram *6 NOTE These components (IC1502, C1509) can be used in any models. However, you cannot mix components under Group A with the ones under Group B. You can choose either Group. The difference between Group A and Group B is shown below. Group A Group B BU4219G-TR...
  • Page 31 AV 2/5 Schematic Diagram 1-10-9 E7A02SCAV2...
  • Page 32 AV 3/5 Schematic Diagram E7A02SCAV3 1-10-10...
  • Page 33 AV 4/5 Schematic Diagram CAUTION ! For continued protection against fire hazard, CAUTION ! replace only with the same type fuse. Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. NOTE: ATTENTION : Pour une protection continue les risqes The voltage for parts in hot circuit is measured using If Main Fuse (F1001) is blown , check to see that all components in the power supply d'Incele n'utiliser que des fusible de même type.
  • Page 34 AV 5/5 Schematic Diagram FL2001 MATRIX CHART P.SCAN VCD VCR REPEAT VCD VCR XP SP LP EP REPEAT P.SCAN E7A02SCAV5 1-10-12...
  • Page 35 SW Schematic Diagram E7A02SCSW 1-10-13...
  • Page 36 AV CBA Top View CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F1001) is blown , check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail.
  • Page 37 AV CBA Bottom View CAUTION ! CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. For continued protection against fire hazard, If Main Fuse (F1001) is blown , check to see that all components in the power supply replace only with the same type fuse.
  • Page 38 SW CBA Top View SW CBA Bottom View BE7A00F01023B 1-10-16...

  • Page 39: Waveforms

    WAVEFORMS Pin 24 of CN1101 Pin 26 of CN1101 VIDEO-Y 0.2V 20µsec VIDEO-Cr 0.2V 20µsec Pin 22 of CN1101 Pin 14 of CN1101 VIDEO-C 0.2V 20µsec AUDIO(L)-OUT 0.5ms C1418 PLUS LEAD Pin 28 of CN1051 VIDEO-CVBS 0.5V 20µsec SPDIF 0.1µsec Pin 28 of CN1101 NOTE: Input: COLOR BAR SIGNAL...

  • Page 40: Wiring Diagram

    WIRING DIAGRAM   E7A02WI 1-12-1...

  • Page 41: System Control Timing Charts

    SYSTEM CONTROL TIMING CHARTS [ Tray Open ] Power on Push Close button is pressed. Tray insertion INNER-SW Case 3 open? [ open ] button is pressed. Is Timer Case 1 Is slit S5 ET3 passed? passed? Rezero 1 Rezero 2 Is Timer Case 4 ET1 passed?
  • Page 42 Parameter S*: Encoder pulse ET*: Error V*: Voltage (HEX) T*: Event timer (HEX) detection timer V0: 2.0 V (00d) S1: 300 (12c) T1: 0.1 s ET1: 5.0 s V1: 4.5 V (022) S2: 3300 (ce4) T2: 3.0 s ET2: 5.0 s V2: 2.2 V (010) S3: 3935 (f5f) T3: 3.0 s...
  • Page 43 Tray close Tray ejection direction SLED Tray insertion direction open INNER-SW close Timer Push close Push Close Encoder pulse SLED Tray insertion direction open INNER-SW close Timer 1-13-3 R2NTI...
  • Page 44 Case 1 SLED Tray insertion direction open INNER-SW close Timer Rezero 1 Case 2 Tray ejection direction SLED Tray insertion direction open INNER-SW close Rezero 2 Case 3 (When [OPEN] button is pressed before the S5 passage.) Encoder pulse Tray ejection direction SLED Timer Case 4 (When [OPEN] button is pressed after the S5 passage.)
  • Page 45 Case 5 (Retry.) Tray ejection direction SLED Tray insertion direction open INNER-SW close Start retry. Retry frequency 1st time retry 2nd time retry 3rd time retry 4th time retry 5th time retry 6th time retry 1-13-5 R2NTI...

  • Page 46: Ic Pin Function Descriptions

    IC PIN FUNCTION DESCRIPTIONS IC1501 (SUB MICRO CONTROLLER) Signal Function Name Signal Function Name Serial Data IN KEY-1 Key Data Input 1 34 OUT SCL Serial Clock IN KEY-2 Key Data Input 2 Not Used IN POW-SW Abnormal Voltage Detection Not Used IN AFT Tuner Voltage Input Signal...
  • Page 47 IC2001 (VFD DRIVER) Signal Function Name IN CLK Serial Clock IN STB Serial Interface Strobe Not Used Not Used Power Supply Segment Output Pull Down Level 16 OUT i Segment Output Grid Output Power Supply IN OSC Oscillator Input Not Used IN DIN Serial Data Input 1-14-2...

  • Page 48: Lead Identifications

    LEAD IDENTIFICATIONS KTC3203-Y-AT/P KTA1267-Y-AT/P UTC4558 PQ070XF01SZH KTA1271-Y-AT/P KTC3199-GR-AT/P KRC103M-AT/P 1 2 3 4 E C B E C B PT6313-S-TP(L) 2SK3757(Q) MM1697AJBE S2Y52(FUNAI Q H) G D S E C B MN101C77AFK1 CD4052BNSR BU4219G-TR R3112N191A-TR-FA PST3619NR 1 2 3 Note: PS2561A-1(Q) MM1637XVBE AN5832SA-E1V...

  • Page 49: Exploded Views

    EXPLODED VIEWS Cabinet 2L021 See Electrical Parts List for parts with this mark. 2L021 Some Ref. Numbers are not in sequence. 2L021 DVD Mechanism & DVD Main CBA Assembly 2L031 2L021 2L031 2L081 2L012 SW CBA 2L021 2L081 2L081 2L081 2B10 AV CBA 1-16-1...
  • Page 50 Packing Some Ref. Numbers are not in sequence. Unit 1-16-2 E7A02PEX...

  • Page 51: Mechanical Parts List

    FRONT ASSEMBLY E7A02UD 1VM323125 TOP COVER E6700UD 1VM120049A REAR PANEL E7A60UD 1VM221810 CHASSIS E6700ED 1VM120045A FOOT K7010UA 0VM403657A MODEL NO. LABEL E7A02UD ---------- TELEPHONE NO. LABEL E9A12UD ---------- LABEL BAR CODE HB400UD ---------- PCB HOLDER E7A00UD 1VM220926 CABLE COVER E7A00UD 1VM422494...

  • Page 52: Electrical Parts List

    ELECTRICAL PARTS LIST PRODUCT SAFETY NOTE: Products marked with a Ref. No. Description Part No. # have special characteristics important to safety. C1063 ELECTROLYTIC CAP . 1000µF/16V M(105°C) CE1CMASTH102 Before replacing any of these components, read C1064 ELECTROLYTIC CAP . 470µF/16V M CE1CMASDL471 carefully the product safety notice in this service C1065...
  • Page 53 Ref. No. Description Part No. Ref. No. Description Part No. C1335 CHIP CERAMIC CAP .(1608) F Z 0.1µF/50V CHD1JZ30F104 C1727 CHIP CERAMIC CAP .(1608) F Z 0.1µF/50V CHD1JZ30F104 C1336 PCB JUMPER D0.6-P5.0 JW5.0T C1728 CHIP CERAMIC CAP .(1608) B K 0.022µF/50V CHD1JK30B223 C1337 CHIP CERAMIC CAP .(1608) F Z 0.1µF/50V...
  • Page 54 Ref. No. Description Part No. Ref. No. Description Part No. IC1401 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102 R1008 METAL OXIDE FILM RES.(STRAIGHT 1W J 15k RN01JZLZ0153 Ω IC1501 MICROCONTROLLER 8BIT MN101C77AFK1 QSZAB0RMS047 CARBON RES. 1/4W J 6.8k Ω R1009 RCX4JATZ0682 If IC1502 is R3112N191A-TR-FA or BU4219G-TR, then C1509 is 0.015µF. METAL OXIDE FILM RES.
  • Page 55 Ref. No. Description Part No. Ref. No. Description Part No. CHIP RES. 1/10W J 22k Ω CHIP RES. 1/10W J 75 Ω R1120 RRXAJR5Z0223 R1430 RRXAJR5Z0750 CHIP RES.(1608) 1/10W F 33k Ω CHIP RES. 1/10W J 3.3k Ω R1121 RRXAFR5H0333 R1501 RRXAJR5Z0332 CHIP RES.(1608) 1/10W F 33k Ω...
  • Page 56 Ref. No. Description Part No. Ref. No. Description Part No. CHIP RES. 1/10W J 10 Ω CHIP RES. 1/10W J 6.8k Ω R2008 RRXAJR5Z0100 R3006 RRXAJR5Z0682 CHIP RES. 1/10W J 2.2k Ω MISCELLANEOUS R3007 RRXAJR5Z0222 CHIP RES. 1/10W J 1k Ω R3008 RRXAJR5Z0102 FL HOLDER E6700UD...
  • Page 57 PY90DG E7A02UD 2006-6-12...
