Operating Instructions
2.63kW Portable Air Conditioner
Model: GCPAC100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Goldair GCPAC100 and is the answer not in the manual?

Questions and answers

Summary of Contents for CDB Goldair GCPAC100

  • Page 1 Operating Instructions 2.63kW Portable Air Conditioner Model: GCPAC100...
  • Page 3 General Care and Safety Guide Thank you for choosing this Goldair product. This Goldair appliance has been designed and manufactured to high standards of engineering and with proper use and care, as described in this leaflet, will give you years of useful service. Please read these instructions carefully and keep them for future reference.
  • Page 4 General Care and Safety Guide 28. Never twist, kink or wrap the cord around the appliance, as this may cause the insulation to weaken and split. Always ensure that all cord has been removed from any cord storage area and is unrolled before use. 29.
  • Page 5 Components Control Panel Air outlet with adjustable louvres Carry Handle Air inlet with air filter Casters Drainage Hole Air Exhaust Remote Control Assessories A. Exhaust Hose B. Hose Connector C. Window Kit Adapter D. Window Kit...
  • Page 6: Installation

    Installation NOTE: The air-conditioner should be installed on a flat surface with at least 300mm clearance all around, including from the top of the unit as it is important that the air outlet is not blocked. Power supply must be nearby. WARNING: THIS APPLIANCE MUST BE INSTALLED, OPERATED AND STORED IN A ROOM WITH A FLOOR AREA LARGER THAN 9m...
  • Page 7: Control Panel And Remote Control

    Control Panel and Remote Control This Portable Air Conditioner is designed to be operated in cooling mode, fan mode or dehumidifying mode. When switching between these functions keep an interval of at least 3 minutes between each ON/OFF. Allow the refrigerant to settle by leaving the appliance to stand for 24 hours after transport or after the unit has been on its side.
  • Page 8 Control Panel and Remote Control Before operating this appliance, please open the louvres on the front. These are not automatic. You can manually adjust them up or down to distribute the air flow around your room. Power Button (1) Press the button to turn the unit ON and OFF. The default setting is FAN mode. Mode Button (2) Press the button to switch between Fan, Cooling and Dry (Dehumidification) modes.
  • Page 9 Control Panel and Remote Control Remote Control The remote control has the same functions as the unit control panel.
  • Page 10: Care And Maintenance

    Care and Maintenance Self Evaporating System As part of the air conditioning process, water is extracted and builds up on the evaporator surface. The water will drop down from evaporator to the bottom of the unit. There is spray motor at the bottom which sprays the water to the surface of condenser. As the condenser surface temperature is very high, when the water touches the condenser surface, it will evaporate from water to air and be expelled out through the exhaust hose.
  • Page 11: Care And Cleaning

    Care and Maintenance CARE AND CLEANING Cleaning the Air Filter (every 2 weeks) Dust collects on the filter and restricts the airflow. The restricted airflow reduces the efficiency of the system and if it becomes blocked it can cause damage to the unit. The air filter requires regular cleaning.
  • Page 12: Troubleshooting

    To receive warranty retain receipt as proof of purchase. (Refer to back of booklet). SUPPORT AND TECHNICAL ADVICE Goldair – New Zealand Goldair – Australia Monday – Friday 8am-5pm Monday – Friday 8am-5pm Phone +64 (0)9 917 4000 Phone +61 (0)3 9336 4423 Phone 0800 232 633 Phone 1300 465 324 info@cdb.co.nz info@cdbgoldair.com.au...
  • Page 13: One Year Warranty

    In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993). Goldair – New Zealand Goldair – Australia CDB Goldair CDB Goldair Australia Pty PO Box 100-707 PO Box 574 N.S.M.C South Morang...
  • Page 16 New Zealand PO Box 100707, North Shore Mail Centre, Auckland, 0745 www.goldair.co.nz Australia PO Box 574, South Morang, Victoria, 3752 www.goldair.com.au...
