- Page 1 4MP H.265 IP IR Eyeball Camera with 2.8mm Fixed Lens and Facial Recognition WIPX4EB Quick Start Guide Please read these instructions carefully before operating the unit and keep for further reference.
- Page 2 Intro Section Please read this instruction carefully before operating the product and keep it for further reference. All examples and pictures used here are for reference only. The contents of this manual are subject to change without notice. CAUTION: • If the product does not work properly, please contact your dealer or the nearest service centre.
-
Page 3: Table Of Contents
Contents 1.0 Introduction ......................4 1.1 Product Features ...................4 1.2 Product Dimensions ..................4 1.3 Contents ......................4 1.4 Specification ....................5 2.0 Overview ......................7 3.0 Installation ......................9 4.0 Network Connection ...................11... -
Page 4: Introduction
1.0 Introduction The Genie WIPX4EB is a 4MP IP IR eyeball camera with a 2.8mm lens. The camera also features up to 30m IR night view distance as well as being IP67. 1.1 Product Features • 4MP (2592 × 1520) H.265 full real-time coding •... -
Page 5: Specification
Quick Start Guide 4MP H.265 IP IR Eyeball Camera with 2.8mm Fixed Lens and Facial Recognition 1.4 Specification Image Sensor 1 / 3 “CMOS Image Size 2592 × 1520 Electronic Shutter 1 / 30 s ~ 1 / 100000 s Iris Type Fixed Iris 0.005 Lux @ F1.6, AGC ON: 0 Lux with IR... - Page 6 Quick Start Guide 4MP H.265 IP IR Eyeball Camera with 2.8mm Fixed Lens and Facial Recognition Remote Monitoring Web browsing, CMS remote control Supports simultaneous monitoring for up to 10 users. Supports Online Connection multi-stream real time transmission UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, Network Protocol SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS Interface Protocol...
-
Page 7: Overview
2.0 Overview Ethernet Connector 2. Audio Input Connector 3. Power Connector 4. Mounting Base 5. Fixed Screw 6. Microphone Micro SD Card Slot 8. Reset Security Cap DC12V • It is recommended to install the security cap for outdoor installation. •... - Page 8 Quick Start Guide 4MP H.265 IP IR Eyeball Camera with 2.8mm Fixed Lens and Facial Recognition Connecting Network Cable Loosen the nut from the main element. 2. Run the network cable (without RJ 45 connector) through both elements. Then crimp the cable with RJ 45 connector.
-
Page 9: Installation
3.0 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in and under a dry environment. Loosen the fixed screw to disassemble the camera. Mounting Base Fixed Screw Enclosure... - Page 10 Quick Start Guide 4MP H.265 IP IR Eyeball Camera with 2.8mm Fixed Lens and Facial Recognition 5. Install the cover back to the camera and fix it with the screws firmly. Please note that the cover should not be installed unevenly. 6.
-
Page 11: Network Connection
4.0 Network Connection In LAN, there are two ways to access the camera: Access Through IP-Tool 2. Direct Access Through Web Browser Access the Camera through the IP Tool Make sure that the camera and the PC are well connected via LAN. 2. - Page 12 Quick Start Guide 4MP H.265 IP IR Eyeball Camera with 2.8mm Fixed Lens and Facial Recognition Access the Web Browser The default network settings are as shown below: • IP address: 192.168.226.201 • HTTP:80 • Subnet Mask: 255.255.255.0 • Data Port:9008 •...
- Page 13 Sales +44(0)1707 330541 Enquiries sales@genieproducts.co.uk Website www.genieproducts.co.uk...
