IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or
require any replacement fittings please contact
Customer Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is
found to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two person is required to assemble this product.
PRODUCT INFORMATION
• Made from engineered board with a wood effect finish.
• Made in China.
CARE INSTRUCTIONS
•For general cleaning, periodically dust with a soft clean lint-free cloth or a soft micro fibre cloth.
• Do not rub or scrub the surface when cleaning.
• Any spills should be removed immediately with a soft clean lint-free cloth or micro fibre cloth and dried
immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage. Ensure the mats and coasters used do not have an abrasive surface underneath.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration
or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should be tightened properly. Periodically check all fixings and tighten if necessary.
932185 STANTON COFFEE TRUNK
ASSEMBLY INSTRUCTIONS.
P a g e 1 o f 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Next STANTON 932185
Summary of Contents for Next STANTON 932185
- Page 1 932185 STANTON COFFEE TRUNK ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
- Page 2 FITTINGS *NOTE: 2 spare camlocks are included in case a failure during assembly. PARTS STEP ONE 1. Insert cambolts(A) into panel (1)&(3)&(4) & (8)x2 by using a screwdriver until tight . 2. Insert cambolts(C) into panel(13) by using a screwdriver until tight . P a g e 2 o f 6...
- Page 3 STEP TWO 1. Glue and insert wooden dowels (E) into panel (2). 2.Attach panel(8)x2 to panel(2) with camlocks (B) by using a screwdriver until tight. Ensure the arrow indicator is pointing towards the panel edge and turn camlocks clockwise until tight using a screwdriver. STEP THREE 1.
- Page 4 STEP FIVE 1. Glue and insert wooden dowels (E) into panel (2). 2.Attach panel (4) to panels(2)&(7)x2 with camlocks(B) by using a screwdriver. Ensure the arrow indicator is pointing towards the panel edge and turn camlocks clockwise until tight using a screwdriver. STEP SIX 1.
- Page 5 STEP EIGHT 1.Glue and insert wooden dowels (E) into panel (3) & (4) &(5). 2.Attach panel(1) to panel (3)&(4)&(5) with camlocks(B) by using a screwdriver. Ensure the arrow indicator is pointing towards the panel edge and turn cam locks clockwise until tight using a screwdriver.
- Page 6 Ensure all shelf pins are at the same height for each shelf. 2.Place adjustable panels (6)x2 onto shelf pins in each cupboard. Next Retail Ltd, Desford Road, Leicester, LE19 4AT P a g e 6 o f 6...
