NR-BX460
(WKVN, WSVN)
Thank you for purchasing this Panasonic product.
● Before operating this unit, please read these instructions completely.
Before using this product, please pay particular attention to the
"Safety precautions" section (Pages 2 to 7) for safe use.
● Please ensure the date and name of store of purchase are stamped
in warranty card and keep it stored together with these operating
instructions in a safe place for future reference.
VN
ARAH1E201010_EN.indd 1
ARAH1E201010_EN.indd 1
Operating Instructions
Refrigerator (For Household Use)
NR-BX460 (WKVN, WSVN)
Model No.
NR-BX410 (WKVN, WPVN)
Contents
Safety Precautions ........................................2
Installation .....................................................8
Parts Identifi cation ......................................10
To use all features ....................................... 11
- Control Panel ....................................11
- ECONAVI Operation ......................... 13
- Prime Fresh + ................................... 13
- Quick Freezing ................................. 14
- Food Stored ..................................... 15
- Using Tips......................................... 16
- Refrigerator Compartment ............... 17
- Prime Fresh ...................................... 18
- Freezer Compartment ...................... 18
Troubleshooting ..........................................22
Specifi cations ..............................................24
ARAH1E20
20
10
T1219-0
Printed in Thailand
12-2019
2019/12/13 10:57:18
12/19/2562 BE 10:16
12/19/2562 BE 10:16

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic ECONAVI NR-BX460

  • Page 1: Table Of Contents

    (WKVN, WSVN) Troubleshooting ..........22 Specifi cations ..........24 Thank you for purchasing this Panasonic product. ● Before operating this unit, please read these instructions completely. Before using this product, please pay particular attention to the “Safety precautions” section (Pages 2 to 7) for safe use.
  • Page 2: Introduction

    Introduction Safety Precautions WARNING CAUTION This expression presumes This expression presumes possibility of a death or possibility of personal injury serious injury. or property damage. This sign means prohibited action This sign means required actions This sign means do not disassemble iso-butane Risk of fi...
  • Page 3 Introduction For power plug and cord... ● Do not let the cord get damaged. ● Do not insert or disconnect the power plug into/from the wall socket with wet hands. ● When positioning the appliance, ensure the supply cord is not trapped or damaged. ●...
  • Page 4 Introduction Safety Precautions WARNING ● Do not use electrical appliances such as a deodorizer in the refrigerator. Leaked refrigerant may catch fi re from a spark of the electrical contacts and may cause an explosion. ● Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
  • Page 5 Introduction When using... ● Do not let any children hang or ride on the refrigerator door, the unit may turn over and cause an accident. ● Do not apply water on the body or interior. Electrical insulation could deteriorate and may cause shocks or fi re. ●...
  • Page 6 Introduction Safety Precautions CAUTION When storing food... ● Do not freeze glass bottles, that there is a risk of injury. (If the liquid in a glass bottle is frozen and broken, you may be injured.) ● Do not touch frozen foods or containers (especially metallic) with wet hands.
  • Page 7 Introduction When moving or transporting the refrigerator... ● Do not transport the refrigerator in a horizontal position. Laying the refrigerator horizontally may damage the piping. If any damage is noticed, do not touch the refrigerator. Avoid using fi re and ventilate the room and contact the service agent immediately.
  • Page 8: Installation

    Installation Installation Before using for product. Is the refrigerator installed in the following locations? ●Locations subject to heat and direct sunlight (The cooling power will be reduced and electricity wasted.) ●Poorly ventilated locations with high humidity (Rust will be caused.) ●Locations where the surface is unstable and slanted On carpet, mats, or vinyl fl...
  • Page 9 Installation Requests and notices Do not peel the seal on the back. Otherwise, the cooling performance may deteriorate. If you have peeled it, then cut a cloth packing tape into a square and paste it Seal onto the refrigerator. Refrigerator doors should not be opened during the interior cooling process.
  • Page 10: Operation

    Operation Parts Identifi cation REFRIGERATOR COMPARTMENT PRIME FRESH CASE FREEZER COMPARTMENT LED lamp PC Glass tray Glass tray crisper Vegetable case Shelf Free rack Egg tray Water tank Hygiene filter Bottle shelf Door gasket PC Door gasket FC Top freezer case Ice twister Ice box Middle freezer case...
  • Page 11: To Use All Features

    Operation To use all features Control Panel  Temperature setting and a guide of temperature Model : NR-BX460 (WKVN, WSVN) The temperature can be adjusted for Min-Max levels. Touch [Fridge] button to adjust temperature in refrigerator compartment and touch [Freezer] button to adjust temperature in freezer compartment.
  • Page 12 Operation To use all features Model : NR-BX410 (WKVN, WPVN) 1 Set the LED display to “Min” position by pressing the [Select] button to select [Fridge] (refrigerator compartment) then press the [Temp. Control] button to select Min. 2 Press and hold the [Temp. Control] button for approximately 10 seconds until the LED display returns to the “Min”...
  • Page 13: Econavi Operation

    Operation ECONAVI Operation Model : NR-BX460 (WKVN, WSVN) The refrigerator detects the opening and closing of the refrigerator door and the brightness around the refrigerator to automatically control operation to ensure maximum energy saving.*  ECONAVI operation ●The refrigerator learns the lifestyle patterns of your family from door opening and time periods of infrequent use to maximise energy effi...
  • Page 14: Quick Freezing

    Operation To use all features Quick Freezing  When [Quick Freezing] is set, the refrigerator will reduce the temperature quickly for better performance of preserving food. Model : NR-BX460 (WKVN, WSVN) ●Touch the [Freezer] button until “Blue LED light at Quick Freezing” turns on.
  • Page 15: Food Stored

    Operation Food Stored  In order to preserve food quality for long time, please store it in the right place. When storing food... ●Foodstuff such as vegetable, fruits and fresh Refrigerator compartment food should be wrapped or pack in box before freezing and refrigerating.
  • Page 16: Using Tips

    Operation To use all features Using Tips Basics of energy saving Save cool air! Do not stuff food into Do not block the cold the compartments. air outlet with food items! That may interfere If cool air does with the not spread into cold air fl...
  • Page 17: Refrigerator Compartment

    Operation Refrigerator Compartment The position of the second tray from the top can be changed (1) Lift up the back of the tray and pull it forward. (2) Insert the tray in the desired position by Once the protrusions of the tray are unhooked reversing the steps.
  • Page 18: Prime Fresh

    Operation To use all features Prime Fresh The temperature in the Prime Fresh Case can be selected from “Prime Fresh +”, “Min”, “Med”, or “Max”. When using the refrigerator, temperature can be adjusted according to your personal usage. *The temperature is set at “Med” as default from factory. Using as the prime fresh Approx.
  • Page 19: Appendix

    Appendix Cleaning, removing and re-installing Before cleaning or conducting maintenance, be absolutely sure to disconnect the power plug from the power outlet. Do not connect or disconnect the power plug with wet hands. When the plug is disconnected, leave it for 10 minutes before plugging again. If not, the compressor may not work.
  • Page 20 Introduction Appendix Cleaning, removing and re-installing Trays Once every 3 months  Removing  Attaching Lift up the back of the tray and pull it Push the tray until it reached the end forward. Once the protrusions of the lock. tray are unhooked from the rails, tilt the tray and remove it.
  • Page 21 Appendix Water Tank Once a week Removing Attaching Pull the water tank up using both hands Insert the valve tip into the hole. Position both and slightly tilt it towards yourself. left and right sides of the tank onto the lock. Fully push the tank under “...
  • Page 22: Troubleshooting

    Introduction Appendix Troubleshooting In these cases? Check here. ●Check that the plug and wall socket are in good condition. The refrigerator does ●Check if there is any problem with the mains fuse or house wiring. not operate. ●Check by unplugging for 10 minutes and plugging back in. ●Check to be sure that light in control panel is display at proper position (P.11, P12) ●Check to ensure that the refrigerator is not overloaded with...
  • Page 23 Appendix In these cases? Check here. ●Has the “Quick Freezing” mode been activated? (P.14) ●Is the temperature setting of the freezer compartment and ECONAVI does fridge compartment set to something other than “Med”? not operate. (the ECONAVI ●Has the door been opened frequently or has hot food been lamp does not placed in the refrigerator? light)
  • Page 24: Specifi Cations

    Rated Voltage (V) Refer to the rating label attached at the door or the Rated Frequency (Hz) back of the cabinet. Panasonic Corporation http://www.panasonic.com © Panasonic Appliances (Thailand) Co., Ltd. 2019 ARAH1E201010_EN.indd 24 ARAH1E201010_EN.indd 24 2019/12/13 10:57:25 12/19/2562 BE 10:16...
