- Page 1 CS40-734834-00D-A0 Product Manual April 2020, Rev A 5689 CS40-734834-00D-A0 2.5W Public Safety Signal Booster Users Guide WESTELL.COM © 2019 Westell Technologies April 2020; Doc No. CS14702802UM rD 1.877.844.4274 Page 1 of 52...
- Page 2 All information and statements contained herein are accurate to the best of Westell Technologies knowledge. Westell makes no warranty with respect there to, including without limitation any results that may be obtained from the products described herein or the infringement by such products of any property rights of any persons.
-
Page 3: Table Of Contents
CS40-734834-00D-A0 Product Manual April 2020, Rev A Table of Contents TABLE OF FIGURES ........................6 LIST OF TABLES ........................... 7 Preface 8 Purpose 8 Scope Audience................................8 Document Organization ............................8 References ................................10 Document Conventions ............................10 Safety Notices ..............................11 Technical Support .............................. - Page 4 CS40-734834-00D-A0 Product Manual April 2020, Rev A 2.2 Product Features ............................20 2.3 Included Accessories ............................21 2.4 Optional Accessories ............................22 3 PRODUCT SPECIFICATION ..................... 23 3.1 RF Specifications ............................23 3.2 Power Specification ............................25 3.3 Mechanical Specification ..........................25 3.4 Environmental Specification ...........................
- Page 5 CS40-734834-00D-A0 Product Manual April 2020, Rev A 6.1 Operating the Program ........................... 42 6.2 Web GUI System Status ..........................43 6.3 Alarm Page ..............................43 6.4 RF Configuration ............................45 6.5 Annunciator Test ............................47 7 SYSTEM SOFTWARE UPGRADE ....................48 7.1 Upgrading the System Software ........................
-
Page 6: Table Of Figures
Figure 5-10: Battery Cable Connected to Repeater................38 Figure 6-1: Network Connection Set-up ....................39 Figure 6-2: Destination Directory…….…………………................40 Figure 6-3: Software Installation…………………..................40 Figure 6-4: CS40-734834-00D-A0 GUI Log- In………………..................41 Figure 6-5: Status Mode………………………....................42 Figure 6-6: Control Mode………......................47 Figure 7-1: Firmware Upgrade Progress Window showing File Open tab ........... -
Page 7: List Of Tables
CS40-734834-00D-A0 Product Manual April 2020, Rev A LIST OF TABLES Table P-1: Document Conventions...................... 10 Table 2-1: Included Accessories......................17 Table 2-2: Optional Accessories ......................18 Table 3-1: RF Specifications......................... 19 Table 3-2: Power Specifications......................20 Table 3-3: Mechanical Specifications....................21 Table 3-4: Environmental Specifications.................... -
Page 8: Preface
Copyright and Trademark Acknowledgements Purpose This manual contains information and procedures for the operation of the Westell CS40-734834-00D- A0 Public Safety Signal Booster. Changes that occur after the publishing date may be incorporated by a complete manual revision or as additions. - Page 9 CS40-734834-00D-A0 Product Manual April 2020, Rev A • Chapter 4: Product Appearance – Provides physical specifications, photographs and information about the external and internal Signal Booster configuration. • Chapter 5: Installation Guidelines – Lists guidelines for installing the Signal Booster and antennas.
-
Page 10: References
CS40-734834-00D-A0 Product Manual April 2020, Rev A References • FCC Part 90 Document Conventions Table P-1 lists the conventions used throughout this document. Table P-1: Document Conventions Convention Description DANGER! Description of an imminent hazard that, if not avoided, may result in severe personal injury or death. -
Page 11: Safety Notices
Failure to comply with these precautions or specific warnings elsewhere in the manual violates the safety standards of design, manufacture, and intended use of equipment. Westell assumes no liability for the customer’s or user’s failure to comply with these requirements: •... -
Page 12: General Information
Use this guide whenever there is a need to add enhanced signal capability to an existing system or when a Signal Booster is included in a new installation. 1.3 Product Registration Information Username and Password are provided by Westell. After signing in, you can modify and check information in SYSTEM SETTING. WESTELL.COM ©... -
Page 13: Figure 1-1: Product Registration
CS40-734834-00D-A0 Product Manual April 2020, Rev A Figure 1-1: Product Registration WESTELL.COM © 2019 Westell Technologies April 2020; Doc No. CS14702802UM rD 1.877.844.4274 Page 13 of 52... -
Page 14: Safety Guidelines
Specific warnings and cautions are located in the applicable manual sections, but may not appear in this summary. Failure to comply with these precautions or specific warnings elsewhere in the manual violates safety standards of design, manufacture, and intended use of equipment. Westell assumes no liability for the customer’s failure to comply with these requirements: Grounding: This Signal Booster is designed to operate at 100-240V~, 50/60Hz, 2A power and must always be operated with the ground wire properly connected. -
Page 15: Important Safety Information
$100,000 for each continuing violation. FCC Warning Labels The following labels will appear on the CS40-734834-00D-A0 Signal Booster in accordance with the FCC: WESTELL.COM © 2019 Westell Technologies April 2020; Doc No. CS14702802UM rD 1.877.844.4274... - Page 16 CS40-734834-00D-A0 Product Manual April 2020, Rev A FCC Label Placement on the CS40-734834-00D-A0: Right-Side View WESTELL.COM © 2019 Westell Technologies April 2020; Doc No. CS14702802UM rD 1.877.844.4274 Page 16 of 52...
-
Page 17: Fcc Part 15 Class A
CS40-734834-00D-A0 Product Manual April 2020, Rev A ▣ FCC Part 15 Class A Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 18: Fcc Contact Information
CS40-734834-00D-A0 Product Manual April 2020, Rev A 1.7 FCC Contact Information: Federal Communications Commission 445 12th Street SW Washington, DC 20554 Phone: 1-888-225-5322 TTY: 1-888-835-5322 Fax: 1-866-418-0232 WESTELL.COM © 2019 Westell Technologies April 2020; Doc No. CS14702802UM rD 1.877.844.4274 Page 18 of 52... -
Page 19: Product Overview
2 Product Overview 2.1 Product Information The CS40-734834-00D-A0 Signal Booster was developed for use in enclosed structures where signals from local public safety towers to operate mobile units is poor or unavailable. Adequate signal strength must be available outside the structure as a prerequisite to achieving in-building coverage. -
Page 20: Product Features
CS40-734834-00D-A0 Product Manual April 2020, Rev A 2.2 Product Features • Easy installation • Light and small • Control using a Windows-based Graphical User Interface (GUI) and accessed by connecting a laptop or desktop computer to the 8P8C/RJ45 Female Network Connector labeled ‘GUI’... -
Page 21: Included Accessories
CS40-734834-00D-A0 Product Manual April 2020, Rev A 2.3 Included Accessories Table 2-1 contains the items that are shipped with the CS40-734834-00D-A0 Public Safety Signal Booster. Table 2-1: Included Accessories Quantity Description AC Power 3 Wire Up to 16 AWG, Length : 6 ft... -
Page 22: Optional Accessories
April 2020, Rev A 2.4 Optional Accessories A complete line of accessories is available from Westell. Check with your Westell distributor for any additional items needed. Some products that are suitable for most in-building needs are listed in Table 2-2. -
Page 23: Product Specification
CS40-734834-00D-A0 Product Manual April 2020, Rev A 3 Product Specification 3.1 RF Specifications Table 3-1: RF Specifications ITEM PARAMETER DESCRIPTION UNIT NOTES 700 DL Freq. Band 758-776 700 UL Freq. Band 788-806 700 FirstNet DL Freq. Band 758-768 700 FirstNet UL Freq. Band 788-798 800 DL Freq. - Page 24 CS40-734834-00D-A0 Product Manual April 2020, Rev A 0.250MHz @ f >210kHz >60 f tolerance +/- 20kHz 0.500MHz @ f >500kHz >60 1.0MHz @ f >500kHz >60 2.0MHz @ f >750kHz >60 3.0MHz @ f >750kHz >60 6.0MHz @ f >1MHz >60...
-
Page 25: Power Specification
CS40-734834-00D-A0 Product Manual April 2020, Rev A DL700 HPA ATT1 ATT2 ATT3 ATT4 DL700 DL700 DL800 DL800 DL800 HPA ATT4 ATT3 ATT2 ATT1 (700+800) (700+800) UL HPA MONO CAVITY TRIPLEXER TRIPLEXER +28VDC 100 ~240VAC +28VDC Power Charger Web GUI Board... -
Page 26: Environmental Specification
CS40-734834-00D-A0 Product Manual April 2020, Rev A 3.4 Environmental Specification Table 3-4: Environmental Specifications Parameter Specification Note Operating Temperature -30°C ~ +50°C (ambient) -22°F ~ +122°F Storage Temperature -40°C ~ +60°C (ambient) -40°F to +140°F Operating Humidity 5% ~ 95%... -
Page 27: Alarm Status
CS40-734834-00D-A0 Product Manual April 2020, Rev A 3.6 Alarm Status Table 3-6 Alarm Status PSR Alarm State PSR Action GUI/SNMP Alarm Description Loss of AC Power - Battery Depleted NA - System dead NA - System dead NA - System dead... -
Page 28: Alarm Relay
CS40-734834-00D-A0 Product Manual April 2020, Rev A 3.7 Alarm Relay Table 3-7 Alarm Relay PSR Alarm State PSR Action PSR Relay/Annunciator Alarm Description Loss of AC Power - Battery Depleted NA - System dead NA - System dead NA - System dead... - Page 29 CS40-734834-00D-A0 Product Manual April 2020, Rev A NOTE Either method in Table 3-7 would trigger the following alarms: AC Power Fail, Battery Capacity Low, Battery Charger Fail, RF Emitter Fail, Donor Antenna Malfunction/Disconnection and System Component Fail. ALARM 1 : EMERGENCY POWER OFF (Pin 1,2) ...
-
Page 30: Product Appearance
CS40-734834-00D-A0 Product Manual April 2020, Rev A 4 Product Appearance 4.1 External Configuration Figure 4-1: External Product Configuration WESTELL.COM © 2019 Westell Technologies April 2020; Doc No. CS14702802UM rD 1.877.844.4274 Page 30 of 52... -
Page 31: Installation Guidelines
• The CS40-734834-00D-A0 Signal Booster is designed for indoor use only. • The CS40-734834-00D-A0 Signal Booster must be installed in a vertical orientation (i.e. Connectors on the bottom of the unit). • Inadequate isolation between the outside and inside antennas may cause regenerative feedback in the system. -
Page 32: Donor Antenna Installation Guidelines
CS40-734834-00D-A0 Product Manual April 2020, Rev A CAUTION • Close proximity to the donor or server antennas with the Signal Booster in operation may expose users or installers to RF fields that exceed FCC limits for human exposure. • Turn power to the Signal Booster off when connecting or disconnecting cables. -
Page 33: Indoor Antenna Installation Guidelines
CS40-734834-00D-A0 Product Manual April 2020, Rev A 5.3 Indoor Antenna Installation Guidelines • Use omnidirectional antennas (see section 2.4. Optional Accessories) indoors and locate them centrally with respect to the intended coverage area to minimize signal leakage to the outside. Only use directional antennas indoors in special cases when higher gain and directionality would be helpful and RF exposure limits will not be exceeded. -
Page 34: Mounting The Signal Booster
Mounting Holes Mounting Holes Figure 5-1: Signal Booster Mounting Using the CS40-734834-00D-A0 as a template, mark the four (8) locations for the wall anchoring system screws. Move the CS40-734834-00D-A0 unit and drill the mounting holes at the marks in the wall. -
Page 35: Verifying The Physical System Setup
Control and monitoring the Signal Booster requires that a properly configured computer with Westell CS40-734834-00D-A0 control software installed is connected via an Ethernet cable, such as the one shown in Figure 5-2A. Connect the Ethernet cable from the Network Interface port of a computer to the GUI port on the bottom end panel of the Signal Booster. -
Page 36: Connecting To The Alarm Relay Panel
CS40-734834-00D-A0 Product Manual April 2020, Rev A 5.7 Connecting to the Alarm Relay Panel Use the provided Alarm Relay Serial Cable to connect the Public Safety Signal Booster to the alarm relay panel. If the provided cable is not long enough for your system, you will need to build one. -
Page 37: Figure 5-5: Alarm Relay Cable Connected To Repeater
CS40-734834-00D-A0 Product Manual April 2020, Rev A Connect the HFC 8404 Gland connector at the serial cable to the Alarm Relay connector on the PSR, Figure 5-5. Be sure to fasten the connector screws securely. Figure 5-5: Alarm Relay Cable Connected to Repeater WESTELL.COM... -
Page 38: Table 5-1: Alarm Relay Connections
CS40-734834-00D-A0 Product Manual April 2020, Rev A Connect the stripped end of the serial cable to the alarm relay panel. Refer to Table 5-1 for connection information. Table 5-1: Alarm Relay Connections Description Alarm# Alarm Information Relay Status Alarm1 EMERGENCY POWER OFF... -
Page 39: Connecting The Power Cable
CS40-734834-00D-A0 Product Manual April 2020, Rev A 5.8 Connecting the Power Cable Use the provided AC Power Cable to connect the Public Safety Signal Booster to an AC power source. Remove the HFC 8402 Gland Connector Molded from the AC 100~240V power connector on the Signal Booster, Figure 5-6. -
Page 40: Figure 5-8: Power Cable Connected To Repeater
CS40-734834-00D-A0 Product Manual April 2020, Rev A Screw the connector on securely Figure 5-8: Power Cable Connected to Repeater When the Signal Booster is properly set up and ready to have power applied, plug the other end into the Cabinet 100~240 VAC. -
Page 41: Connecting The Battery Back-Up Cable
CS40-734834-00D-A0 Product Manual April 2020, Rev A 5.9 Connecting the Battery Back-up Cable Use the provided DC Power Cable to connect the Public Safety Signal Booster to a 24-30VDC Battery Back-up / power source. (Pin A, White = positive, Pin B, Black = Negative) -
Page 42: System Operation
CS40-734834-00D-A0 Product Manual April 2020, Rev A 6 System Operation 6.1 Operating the Program Access the Public Safety Signal Booster through a LAN connection. The Signal Booster ships with the IP address 192.168.0.1 on the GUI port. To connect directly to the Signal Booster from a laptop or PC with a crossover CAT-5E cable or over a... -
Page 43: Web Gui System Status
CS40-734834-00D-A0 Product Manual April 2020, Rev A 6.2 Web GUI System Status When you log-in, the System Status window is displayed, and the four menus in which the sections are described are activated. The top menu displays Alarm, and if you click it, you can check the entire alarm... - Page 44 CS40-734834-00D-A0 Product Manual April 2020, Rev A Item # Section Loss Of AC Power Fail of AC Power Battery Capacity Low Low Battery capacity at 70% reduction Battery Charger Fail Battery Disconnection or Battery No charging status DL 700 HPA Fail...
-
Page 45: Rf Configuration
CS40-734834-00D-A0 Product Manual April 2020, Rev A 6.4 RF Configuration Figure 6-4: RF Configuration Item 1 Section Band 700MHz, 800MHz Band Selection Menu Item 2 Section Channels 32Ch. Selection Menu Item 3 Section Output Power UL DL output power of selected band is monitored... - Page 46 CS40-734834-00D-A0 Product Manual April 2020, Rev A Item 1 Section Item 6 Section Gain DL, UL Gain setting DL Max Gain: 90dB UL Max Gain: 80dB Item 7 Section Squelch Displays DL, UL Automatic Level Control Level setting value Item 8...
-
Page 47: Annunciator Test
CS40-734834-00D-A0 Product Manual April 2020, Rev A 6.5 Annunciator Test This test will actuate: 1) the audible annunciator for each alarm in the repeater enclosure 2) the audible and visible annunciator for each alarm in the remote annunciator panel 3) Test All: Enable alarm testing via the software GUI Figure 6-5: Annunciator Test WESTELL.COM... -
Page 48: System Software Upgrade
CS40-734834-00D-A0 Product Manual April 2020, Rev A 7 System Software Upgrade 7.1 Upgrading the System Software Follow the instructions in this section to upgrade to a newer version of system software, as required. 1) Click the “System Setting” button on the System Status to display the Control page. -
Page 49: Network (Wan) Setting
CS40-734834-00D-A0 Product Manual April 2020, Rev A 7.3 Network (WAN) Setting Figure 7-3: Network Display 1) Select “SYSTEM SETTING” button 2) Select “Network” section “EDIT” button 3) Fill network setting value(Prefix 24 is same subnet mask 255.255.255.0) IP setting •... -
Page 50: Appendix Aimportant Product Information
CS40-734834-00D-A0 Product Manual April 2020, Rev A Appendix A Important Product Information A.1 Registration Number FCC - NVRDPSA81090-78 A.2 ETL This product is ETL Listed. #5018566 A.3 Configuration LIST Part Number Band Bands Class Description CS40-734834-00D-A0 700 / 800 Dual DB-700/800 2.5W CL-A/B... -
Page 51: Table B-1: Acronyms And Abbreviations
CS40-734834-00D-A0 Product Manual April 2020, Rev A Appendix B Acronyms and Abbreviations Table B-1 contains the acronyms and abbreviations used in this manual, along with a definition for each one. Table B-1: Acronyms and Abbreviations Acronym/Abbreviation Definition Alternating Current Automatic Gain Control... -
Page 52: Appendix Cul2524 Installation Guidelines
CS40-734834-00D-A0 Product Manual April 2020, Rev A Appendix C UL2524 Installation Guidelines UL2524 Installations AC Input Connector - 1/2” Liquid Tight Conduit Fitting - Heyco 8402 - 1/2” Cordgrip - Heyco M6108 DC Input/Output Connector - 1/2” non-metallic Conduit fitting - Heyco 8402 - 1/2”... - Page 57 FCC compliance information THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
