Luna Twin/400
Ceiling hoist
User manual
Important information
Please read this user manual carefully
before using the product!
This user manual is intended as a guide
for caregivers and other users, as well as
technical personnel during servicing and
maintenance of the product.
maintenance of the product.
Date: 02-06-2017
Ver: 2
Scan the QR code for further information
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winncare Luna Twin/400
Summary of Contents for Winncare Luna Twin/400
- Page 1 Luna Twin/400 Ceiling hoist User manual Important information Please read this user manual carefully before using the product! This user manual is intended as a guide for caregivers and other users, as well as technical personnel during servicing and maintenance of the product.
-
Page 3: Table Of Contents
CONTENTS 1 PURPOSE AND SAFETY _____________________________________ 4 Purpose __________________________________________ 4 Safety instructions __________________________________ 4 Before use ________________________________________ 5 Terminology _______________________________________ 5 Unpacking ________________________________________ 6 Transport _________________________________________ 6 2 INSTALLATION AND OPERATION _____________________________ 7 Installation and dismantling of the ceiling hoist___________ 7 Pictograms and functions ____________________________ 9 Operation of safety functions ________________________ 11 Charging _________________________________________ 12... -
Page 4: Purpose And Safety
1 PURPOSE AND SAFETY Luna Twin/400 is a modular ceiling hoist, which can be used as a single or a double (Twin) ceiling hoist. The single Luna has a lifting capacity of 275 kg. By an easy modification to the Luna Twin solution, where two single Luna are interconnected and then brings the total lifting capacity on 400 kg. -
Page 5: Before Use
The carer is responsible for ensuring that a check is carried out BEFORE Luna and accessories are used, including the following: • Luna ceiling hoist is mounted in suitable track systems, approved by Winncare Nordic ApS. • The installation of the track system was done by qualified installers with proposals from Winncare Nordic ApS. -
Page 6: Unpacking
Check that all the parts are present and undamaged. Any suspicion of damage or shortage should be reported to your dealer or Winncare Nordic ApS. We recommend that the packing carton is retained if the Luna is to be used on other sites or for return shipment in case of repair or annual check. -
Page 7: Installation And Operation
2 INSTALLATION AND OPERATION Be aware that each of the Luna devices weights 6.7 kilos without the distance rod and spreader bars. Installation and dismantling of the ceiling hoist Mounted of Luna/275 ceiling hoist Luna/275 mounted directly on to the ceiling track in cart. Lift the ceiling hoist up to the cart and connect the bayonet bracket into the Luna (resistance will be ( 2 ) - Page 8 Connect the hand control on the main ceiling hoist (see section 2.2) and adjust the Luna with the up/down buttons, so the spreader bar is in level. Connect the Twin cable on the inactive side foil. Press STOP on the hand control and hold the Reset button for 5 seconds. The Luna Twin ceiling hoists are now synchronized.
-
Page 9: Pictograms And Functions
Pictograms and functions (1) ON – The LED lights green to indicate, Active side foil that the ceiling hoist is ready. (1) (2) If not used for a while the hoist will go into sleep-mode and the LED turns off. Activate the hoist again by pressing down (3) or the up button (4) on the hand control. - Page 10 (1) ON – The LED lights green to indicate, Hand control: that the ceiling hoist is ready. Under use the LED will show yellow. (2) BATT. – Indicates the level of the battery (see section 2.4). (3)+(4) Up/Down – With a constant hold the Luna will move in the desired direction.
-
Page 11: Operation Of Safety Functions
Note! If one of the emergency stop functions has been activated due to an emergency the Luna must not be used again before a check has been made and any defect repaired. If in doubt, contact your dealer or Winncare Nordic ApS... -
Page 12: Charging
Move the Luna to the charging station and place the hand control onto the charger after which charging starts automatically. Note: Luna is fitted with batteries that require regular charging. Winncare Nordic ApS recommends that Luna is charged every night or when the hoist is not in use. -
Page 13: Using Luna Twin
Note: Use of non-approved slings will render Winncare Nordic ApS responsibility for faults and accidents null and void. Winncare Nordic ApS can assist in choosing slings and also the correct use of slings. Hanging slings on the Winncare Nordic ApS spreader bar... -
Page 14: Using Luna In A Shower Environment
Using Luna in a shower environment The Luna ceiling hoist and the hand control are water resistant and can tolerate being sprayed with water. Winncare Nordic ApS recommends that the Luna is used as Fig. 3.3A (Shown as a single Luna). -
Page 15: Check, Warranty And Troubleshooting
The manufacturer Winncare Nordic ApS recommends that the ceiling hoist MUST be checked by a qualified person at least once a year in accordance with Winncare Nordic ApS service instructions. An annual check is also recommended to the European Standard (EN/ISO 10535) for patient lifters/hoists including ceiling hoist. -
Page 16: Technical Data And Dimensions
Connect charger to main supply. to the main supply. (see section 2.4). Charger defect. Try another charger or get a new one from the dealer or Winncare Nordic ApS. Connection to the hand Try another charger or get a new control is defective. -
Page 17: Dimensions
Dimensions Measurements, Twin Luna/400: A) Width of Luna device 710 mm B) Spreader bar (see section 8 600 mm ”accessories” for other sizes) C) Height of Luna device 170 mm D) Min. height from hook to track 450 mm E) Lifting range from min. height 1950 mm... -
Page 18: Environment And Quality
Winncare Nordic ApS at the end of their lifetime. Quality Winncare Nordic ApS is certified according to the quality standard ISO 9001 and ISO 13485. These certifications mean that the products and the company complies with the international standards for quality management and standards for traceability of medical products. -
Page 19: Symbols And Abbreviations
Spreader bar for strap, width 36 cm 015-02037 Spreader bar for strap, width 48 cm 015-02038 Spreader bar for strap, width 58 cm Accessories 017-00137 Weight scale, 400 kg A complete list of spare parts is available. Please contact Winncare Nordic ApS for details... - Page 20 Manufactuerer: Phone: + 45 70 27 37 20 93/42/EØF CLASS I Winncare Nordic ApS Fax: + 45 70 27 37 19 EN/ISO 10535 Taarnborgvej 12 C EN 60601-1-2 Email: info@ergolet.dk 4220 Korsoer www.ergolet.com Denmark UM-910-00778UK...
