Summary of Contents for Intellijel Ring Mod 1U
- Page 1 Ring Mod 1U Ring Modulator Manual (English) Revision: 2022.07.26...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS COMPLIANCE INSTALLATION Before You Start Installing Your Module FRONT PANEL Using Ring Mod 1U as a VCA Calibrating the Ring Mod 1U TECHNICAL SPECIFICATIONS Ring Mod 1U Manual... -
Page 3: Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Intellijel Designs, Inc. could void the user’s authority to operate the equipment. Any digital equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Installation
INSTALLATION This module is designed for use within an Intellijel-standard 1U row, such as contained within the Intellijel Palette cases, or 7U Performance cases. Intellijel’s 1U specification is derived from the Eurorack mechanical specification set by Doepfer that is designed to support the use of lipped rails within industry standard rack heights. -
Page 5: Installing Your Module
Eurorack case. Ensure the red stripe on the cable lines up with the -12V pins on the bus board. On Intellijel power supplies the pins are labeled with the label “-12V” and a thick white stripe. -
Page 6: Front Panel
(meaning it acts mostly as an output indicator). But at LFO rates, the LED provides a visual representation of the complex LFO shape being generated by the ring mod. Ring Mod 1U Manual... -
Page 7: Using Ring Mod 1U As A Vca
RING OUT jack. Calibrating the Ring Mod 1U Ring Mod 1U is calibrated at the factory before shipping, so it’s unlikely you’ll ever need to perform this procedure. However, if necessary, you can easily do it using only an oscillator (capable of generating a simple, static waveform like a square wave) and an oscilloscope. -
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS Width 6 hp Maximum Depth 32 mm Current Draw 25 mA @ +12 V 20 mA @ -12 V Ring Mod 1U Manual...
