Installation and User Instructions
Mayku Multiplier
MMUA22100AA, MMUA22123UK, MMUA22123EU, MMUA22123AU, MMUA22112US
These are the original English instructions
If incorrectly used this machine may cause severe injury - please read this manual carefully
before operating your machine and keep for future reference.
May 2022
Version 1.00
Mayku Limited
The Biscuit Factory, Unit J410, Jam Studios, 100 Drummond Road, London, United Kingdom, SE16 4DG.
Advertisement
Table of Contents
Summary of Contents for Mayku Multiplier MMUA22100AA
- Page 1 Installation and User Instructions Mayku Multiplier MMUA22100AA, MMUA22123UK, MMUA22123EU, MMUA22123AU, MMUA22112US These are the original English instructions If incorrectly used this machine may cause severe injury - please read this manual carefully before operating your machine and keep for future reference.
-
Page 2: Table Of Contents
3.4 Simplified Declaration of conformity 3.5 FCC Compliance Statement 4 PREPARATION 4.1 How to transport and store the Mayku Multiplier 4.1.1 Dimensions and mass 4.1.2 Lifting, handling and transporting the product 4.1.3 Storing the product / Storing during intervals in normal use 4.2 How to install the Mayku Multiplier... - Page 3 5 OPERATION/USE 5.1 How to use the Mayku Multiplier 5.1.1 Power on 5.1.2 Turn on 5.1.3 Follow on-screen instructions 5.1.4 Connecting to WiFi 5.1.5 Machine Registration 5.1.6 Starting/Stopping the product’s operation 5.1.7 Checks before using the machine Ensure the machine is on a level and even surface Ensure both safety release valves have clearance and are not obstructed.
-
Page 4: Preface
PREFACE Description of the user These instructions are intended for the end-user of the Multiplier. The end-user can be described as each person who interacts directly with the machinery. The end-user typically includes, but is not limited to the: Operator Installer Maintenance personnel or technicians Any maintenance required outside of this user manual shall be carried out by an authorised, qualified and... -
Page 5: Explanation Of Safety Warnings
Explanation of safety warnings DANGER indicates a hazard with a high level of risk which, if not avoided, will result in death or serious injury WARNING indicates a hazard with a medium level of risk which, if not avoided, could result in death or serious injury. -
Page 6: Obtaining Documentation And Information
Obtaining documentation and information The latest version of the documentation is available at the following address: mayku.me/manuals For other questions, information, technical assistance or ordering user instructions, please contact the manufacturer: Mayku Ltd The Biscuit Factory Unit J410 Jam Studios 100 Drummond Road... -
Page 7: Description Of The Mayku Multiplier
DESCRIPTION OF THE MAYKU MULTIPLIER Intended use and reasonably foreseeable misuse The Multiplier is intended to be used as a desktop pressure forming machine, for making high detail molds from suitable templates for a range of applications. The Multiplier is intended for indoor use in a well ventilated area only. -
Page 8: Technical Data
Technical data Parameter Unit Device name Mayku Multiplier Designation Pressure Former Type Thermoforming Machine Technical life span 10 Years Input 110-240V, 12A/6A (Single Phase) Maximum Pressure 4.1 bar/60 psi (Dome), 12 Bar/175 psi (Tank) Max Power 1500W Weight Unboxed: 57kg (125lbs) | Boxed: 67.5kg (149lbs) Frequency band 2.4GHz... - Page 9 Operation and storage temperature +5 to +40°C range Relative humidity 0 to 85% FCC ID 2A6JZMMUA221 Software version...
-
Page 10: Product Elements
Product Elements Front: Back:... - Page 11 Internal: Base:...
-
Page 12: Understanding The User Interface
Understanding the user interface Control Panel: Explanation of auditory and visual signals The Multiplier uses on-screen commands and auditory beeps to convey instructions. The Mayku logo lights up when the machine is turned on. -
Page 13: Safety Instructions
Do not touch under operation. ● When a sheet has been formed in the Mayku Multiplier, it will remain hot for a period of time. Do not touch the sheets until they have cooled. - Page 14 ● Always place the Multiplier on a stable, flat, heat-resistant surface. Also ensure that the surface can take the weight of the Multiplier during use. ● Do not use the Multiplier if the plug, the mains cord or the machine itself shows physical damage, or if the machine functions abnormally in any way, or if the machine has been dropped or has been exposed to water or other liquid.
- Page 15 ● Do not use non-certified Mayku sheets and materials with your Multiplier. ● Only use Mayku branded air accessories with the Multiplier. ● Mayku are not responsible for the use of any experimental and potentially damaging materials used as sheets or templates in the Multiplier.
-
Page 16: Graphical Symbols
Graphical symbols 3.1.1 Explanation of safety information on the product and packaging. Symbol Meaning CE Marking UKCA Marking FCC Marking RCM Marking Warning, risk of crushing fingers. Warning, hot surface Warning, possibility of electric shock... -
Page 17: Potential Health Consequences
● Hearing protection - for tank venting during maintenance Simplified Declaration of conformity Hereby, Mayku ltd declares that the radio equipment type Mayku Multiplier MMUA22100AA is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: mayku.me/compliance... - Page 18 determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ●...
-
Page 19: Preparation
PREPARATION How to transport and store the Mayku Multiplier Ensure that the Multiplier is on a stable surface before use. Moving the Multiplier during use is dangerous and may result in injury or death. 4.1.1 Dimensions and mass Unboxed 585mm (L) x 515mm (W) x 420mm (H). -
Page 20: Lifting, Handling And Transporting The Product
4.1.2 Lifting, handling and transporting the product To lift and handle the product safely: 1. Make sure that your path is clear from obstacles. Make sure that surfaces are not wet or slick. 2. Wear proper protective shoes and gloves 3. -
Page 21: Storing The Product / Storing During Intervals In Normal Use
1. The machine shall be used and stored on a strong and stable surface. 2. Ensure the machine is stored in the closed position at all times. How to install the Mayku Multiplier The Multiplier is a heavy machine, and requires a minimum of (2) people to lift. Do not attempt to lift the machine by yourself. -
Page 22: Unpacking The Product
4.2.2 Unpacking the product Once the cardboard lid and shipping box have been removed follow these steps: 1. Remove the quick start guide, user manual and tool kit from the foam lid. 2. Lift off the foam lid 3. Remove the four foam side panels 4. -
Page 23: Packaging Contents
4.2.3 Packaging contents Your delivery will contain the following items: A. Multiplier machine (One) B. Mains cable (One) C. Quick start guide D. Instruction manual E. Set of maintenance tools a. Allen keys (Two) b. Cleaning cloth (One) -
Page 24: Minimum Space Required
4.2.4 Minimum space required The machine dimensions are: 585mm (H) x 515mm (W) x 420mm (H) A minimum of 150mm is required behind the machine to allow for cables and other accessories. -
Page 25: Installation Of The Mayku Multiplier
4.2.5 Installation of the Mayku Multiplier Ensure that both safety release valves (located on the bottom of the machine) are not blocked during positioning. No tools are required for installation To install the Mayku Multiplier: 1. Once the machine is in its final position check to ensure there is 150mm of space behind the machine, and the safety release valves on the base are not blocked. -
Page 26: How To Commission The Multiplier
Multiplier. Maintenance can be found by going to Menu > Maintenance on the machine. Employers shall conduct a risk assessment and national requirement to inform employees on hazards. Mayku will not be held liable for any injuries caused by an unsafe work environment due to not following these procedures. - Page 27 OPERATION/USE How to use the Mayku Multiplier 5.1.1 Power on Make sure that the mains cable is connected to the machine, and turn the power switch to the ON position. 5.1.2 Turn on Push the on/off button to the ON position to power up the machine.
- Page 28 5.1.3 Follow on-screen instructions For further guidance on using the Multiplier, please visit: platform.mayku.me 5.1.4 Connecting to WiFi The Multiplier can be updated wirelessly over WiFi. This means we can add new material profiles, new functions and new accessories to your machine over time.
- Page 29 Multiplier Academy — your community hub of resources, projects and personalised help to get the most out of your Multiplier. You can also register any time by visiting: platform.mayku.me 5.1.6 Starting/Stopping the product’s operation The machine can be stopped at any time during forming by following the below: Hold the ‘X’...
- Page 30 5.1.7 Checks before using the machine 1. Ensure the machine is on a level and even surface 2. Ensure both safety release valves have clearance and are not obstructed. 3. Ensure the machine is clean and clear of debris 4. Ensure the heaters are not cracked or broken 5.
- Page 31 MAINTENANCE Opening or modifying the machine will void your warranty and could cause serious injury or death. How to maintain the machine Product maintenance by non-skilled persons 6.1.1 Cleaning and lubrication Cleaning the seal: 1. Use a damp microfiber cloth and clean the seal in a circular motion, making sure the seal is seated properly into the dome.
- Page 33 Wipe clean the seal with a damp cloth. Check the bed for debris or dirt Wipe down with a damp cloth, or remove for better cleaning. Check heaters for signs of cracking or Do not attempt to fix. Contact customer failure. support at support@mayku.me.
- Page 34 6.2.2 Monthly Inspection tasks Task Action Drain the tanks Follow the on-screen maintenance instructions in the settings menu. Check the heat temperature sensor Clean gently with a damp cloth or cotton swab. Check the heat reflector Wipe down the heat reflector. Check the rail lubrication Apply recommended lubricant if dry.
- Page 35 Frequently Asked Questions Question Answer Where can I purchase sheets You can purchase sheets on our website, at mayku.me. for my machine? How much pressure does the The Multiplier uses a maximum of 60PSI (4.1 Bar) in the dome Multiplier use? to form the sheet, and a maximum of 175PSI (12 Bar) in the tanks for air storage.
- Page 36 - so you can put them in your regular household recycling waste. More than a machines company Mayku is a community of Makers. And we need you - to join us in creating a sustainable future. Please help us care for our environment by recycling Mayku products and consumables whenever possible.
- Page 37 If a hardware defect arises and a valid claim is received within the Warranty Period, at our sole option and to the extent permitted by law, Mayku will either 1) repair the hardware defect at no charge, using new or refurbished replacement parts, 2) exchange the Hardware Product with a...
- Page 38 This warranty gives you specific legal rights, and you may also have others rights which vary from state to state or country to country. Mayku responsibility for hardware defects is limited to repair or replacement service as determined by Mayku in its sole discretion.
- Page 39 All information in the quick start guide, instruction manual and packaging materials is subject to change at any time without notice and is provided for convenience purposes only. Mayku reserves the right to modify or revise the quick start guide, instruction manual and packaging materials in its sole discretion and at any time.
- Page 40 10.2 Limitation of Liability In no event will Mayku or any of our respective officers, directors, employees, shareholders, affiliates, agents, successors, or assigns, nor any party involved in the creation or production of our products, be liable to you or anyone else for any indirect, special, punitive, incidental, or...
