RTG6 Digital Tyre & tread depth gauge Instructions for use
Tyre pressure gauge
Refer to vehicles handbook to determine the correct pressure for the front and rear wheels.
Check tyre pressures when tyres are cold.
Please remove screen protector before use
If you are using the gauge for the first time the battery tab protector needs to be removed using a small
Philips screwdriver remove the screw, separate the batteries and remove the plastic disk. Reassemble
and do not over tighten the screw.
Inflate / deflate to correct pressure to use less fuel and reduce CO² emissions.
The tyre gauge must not be used when the vehicle is moving. Ensure you are parked in a safe location
off the road with the car handbrake on and your personal safety is not at risk.
If used during darkness press the to illuminate the LED guide light. The light automatically turns off
after 60 seconds.
Unscrew the valve cap on the tyre, keeping it safe. Press the On button (•) the figure 0.0psi will be
displayed. To change the pressure setting press the On button to switch among the pressure setting of
psi,bar, kpa and Kg/cm2. Push the gauge onto the valve firmly and hold in place for approximately 3-4
seconds for the pressure reading. To check other tyre pressures connect to the tyre valve and the gauge
will automatically reset and display the new reading.
The gauge will automatically turn off approximately 60 seconds after the last reading.
Replace the valve cap
Tyre tread depth gauge
Slide the switch on the front of the gauge to depress the tread depth gauge.
The UK legal minimum tread depth for cars and light trailers (inc caravans) up to 3500kgs gross vehicle
weight and or 8 seated passenger vehicles including the driver is a minimum of 1.6mm in a continuous
band throughout the central three-quarters of the tread width throughout the whole of the
circumference
