SERVICE MANUAL
3
2005
YF087
GR-DF420EK, GR-DF420EX,
GR-DF420EY, GR-DF420EZ,
GR-DF425EK, GR-DF425EG,
GR-DF430EK, GR-DF460EK,
GR-DF470EK, GR-DF470EX,
GR-DF470EY, GR-DF470EZ
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700(MECHANISM ASSEMBLY).
1
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
5
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
DIGITAL VIDEO CAMERA
TABLE OF CONTENTS
COPYRIGHT © 2005 Victor Company of Japan, Limited
GR-DF420EKM, GR-DF420EXM, GR-DF420EYM, GR-DF420EZM,
GR-DF425EKM, GR-DF425EGM[M5D5S2] ,
GR-DF430EKM[M5D5S3],GR-DF460EKM[M5D5S6],
GR-DF470EKM, GR-DF470EXM GR-DF470EYM, GR-DF470EZM[M5D5S7]
No.YF087
2005/3
