Switch
LED Power Driver +
96W/24VDC -
Units can be parallel connected to obtain total 88W maximum or equivalent for model
FAME2-L126-24V，FAME2-L126-24V-1，FAME2-L252-24V
FAME2-L84-24V，FAME2-L84-24V-1 ，FAME2-L168-24V
SELF Electronics Co.,Ltd.
No. 1345 JuXian Road, Ningbo Hi Tech Park, Ningbo, China 315103
Right
Center
Center
Splitter
Center
Center
Left
Optional
FAME2-LX-24V
Advertisement
Summary of Contents for SELF FAME2 Series
- Page 1 LED Power Driver + 96W/24VDC - Center Splitter Center Center Left Optional Units can be parallel connected to obtain total 88W maximum or equivalent for model FAME2-L126-24V，FAME2-L126-24V-1，FAME2-L252-24V FAME2-L84-24V，FAME2-L84-24V-1 ，FAME2-L168-24V SELF Electronics Co.,Ltd. No. 1345 JuXian Road, Ningbo Hi Tech Park, Ningbo, China 315103...
-
Page 2: Led Driver
INSTRUCTION MANUAL SERIES: FAME2 1/16”(50.8) Read these instructions completely and carefully. ATTENTIONS ” 4 ” 8 • Read the instruction carefully before installation，non-observance of this instruction may cause damage to the fixture or hurt to human body. The installation must be carried out by a qualified electrician in accordance with local or national codes. -
Page 3: Retrofit Installation
Tools(Not included): Install the LED light. Tape measure Screwdriver Electrical Safety Gloves Driller Wire Stripper The thickness of steel for mounting should be between 0.0157"~0.118" (0.4mm-3mm) Retrofit Installation: Remove existing lamps,lampholder and ballast. Left Right Center Center... - Page 4 Typical Installation(without existing lights): Install LED driver and wiring. Ready for mounting. Note: The driver should be installed in the metal enclosure of refrigerator. The thickness of metal enclosure should be no less than 0.026"(0.66mm) in case of steel.
- Page 5 Parts Needed Per Case: Wiring. FAME2 2 doors 3 doors 4 doors 5 doors 6 doors Center LED Lights Right LED Lights Left LED Lights LED Drivers(standard version)-LED Lights) LED Drivers(high power version)-LED Lights) 2-door 3-door 3-door 4-door...
