ARCO Stadium Grille Installation Procedure

INDUSTRIAL/LARGER ALUMINIUM ROLLER SHUTTERS
STADIUM ALUMINIUM ROLLER GRILLE - Ultra Strong 19mm All Aluminium, provides increased flexibility in
high level security for external (Shutter) and internal (Shop Front Door) applications and is the product of
choice for areas where high air flow and vision is required. Designed to suit openings up to 4.5m high and up
ARCADE 3 – Ultra strong 118mm Aluminium Roller Shutter which provides greater options especially in retail
shop front sector. Designed to suit openings up to 4.5m high and up to 10.0 meters wide for motorised
Q100 STEEL ROLLER SHUTTER – Roll formed 100mm slat from Galvanized Steel. The Heavy Duty Steel Slat is
designed to withstand the wear and tear of industrial and commercial applications with minimal maintenance.
The rolled slat can be replaced individually should the damaged occur. The roll formed Guide Channel has
Nylon Rubber to minimize the noise that comes from the interlocking slats. Q100 Steel Roller Shutter can be

Installation of Roller Shutter Door should only be undertaken by experienced Installer/Technician.

Never allow anybody to be in close proximity when installing this door.

Before commencing installation, ensure that the structure is suitable to carry the load of the door
during operation. Consult the Structural Engineer/Builder of the project.
Arco Qld Pty Ltd/Manual
Page 1 of 7
Arco Qld Pty Ltd
PO Box 6340 Yatala Qld 4207
Phone +61 7 3807 5364
Fax +61 7 3382 7929
INSTALLATION PROCEDURE
& MAINTENANCE
to 8.0 meters wide for motorized operation.
operation.
Hand Chain operated or Electric operated.
