Zhongdi ZD-8922 Manual

2-in-1 smd hot air rework station

2-in-1 SMD Hot Air Rework Station

Model: ZD-8922

Important safety information

• When using electrical appliances basic safety precautions should always be

followed.

• Make sure that the voltage indicated on the rating plate corresponds with that of

the local network before connecting the appliance to the mains power supply.

• This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Children shall not play with the appliance. Cleaning and user maintenance shall

not be made by children unless they are older than 8 and supervised.

• Do not operate the appliance with a damaged plug or cord, after a malfunction or

after being dropped or damaged in any way.

• If the supply cord is damaged, it must be replaced by a qualified engineer in order

to avoid injury or hazard.

• The soldering iron must be placed on its stand when not in use.

• Ensure there is sufficient space and ventilation around the appliance to allow the

escape of heat and/or fumes.

• Never place the product or part of it in water, or operate if your hands are wet.

• Wear appropriate clothing and safety goggles while soldering.

• Soldering work must be conducted on a stable, non-combustible surface.

• Do not touch any metallic parts near the soldering tip/nozzle.

• Do not leave the soldering iron unattended while it is switched on.

• Wash your hands thoroughly after working with solder.

• Make sure the power switch is in the "off" position and disconnect the plug when

the unit is not in use.

• Before storage, ensure the power is off and allow the station to cool down to room

temperature.

• This 2-in-1 SMD hot air rework station is an excellent tool for soldering work.

• And it is super high cost-effective.

• It is suitable for soldering and desoldering all types of surface mounted IC, PCB or

components.

• The innovative heater and sensor provides a quick heat-up and rapid temperature

recovery.

• The hot air pump handle is embedded with sensor.

• The unit will immediately enter into Working Mode when you pick up the handle,

and will go into Standby Mode when you put the handle back to the holder.

Table of Contents

Do you have a question about the ZD-8922 and is the answer not in the manual?

Page 1 2-in-1 SMD Hot Air Rework Station Model: ZD-8922 Important safety information • When using electrical appliances basic safety precautions should always be followed. • Make sure that the voltage indicated on the rating plate corresponds with that of the local network before connecting the appliance to the mains power supply.
Page 2 Specifications Voltage: 220-240 V~50 Hz Soldering iron: 24 V, 60 W Hot air pump: 300 W Temperature range: 50-480°C (soldering iron) 100-500°C (hot air pump) Operation Place the soldering iron /hot air pump in the holder separately. Then connect the plug to the receptacle on the station and turn clockwise to tighten the plug nut.
Page 3 Maintenance Before further use, safety devices or slightly damaged parts must be carefully checked for error-free and intended operation. Inspect moving parts for error-free operation and that they don’t bind, or whether any parts are damaged. Damaged safety devices and parts must be repaired or replaced by a qualified technician, so long as nothing else is indicated in the operation manual.
