  • Page 1 Vision.net Hardware User ManUal...

  • Page 2: Additional Documentation

    Strand website at www.strandlighting.com. This User Manual provides necessary information regarding safety, installation, operation and routine mainte- nance for Strand VL2600 Series. Familiarizing yourself with this information will help you to get the most out of your product.

  • Page 3: Safety Warnings And Notices

    Vision.net Hardware User ManUal SAFETY WARNINGS AND NOTICES Read this user manual in full before attempting to install, operate or maintain the fi xture to which it relates. This user manual is intended to provide general guidance to such suitably qualifi ed personnel. Installation and opera- tion of the fi...

  • Page 4: Compliance Notice

    This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with Vari-Lite Strand system, service, and safety guidelines, may cause harmful interference to radio communications.

  • Page 5: How To Obtain Warranty Service

    As stated in the warranty, it is required that the shipment be insured and FOB our service center. IMPORTANT! When returning products to Vari-Lite Strand for repairs (warranty or out-of-warranty) from a country other than the USA, “Vari-Lite LLC”, must appear in the address block as the Importer of Record (IOR) on all shipping documentation, Commercial Invoices, etc.
  • Page 6 DesCrIPTIOn FEATURES Strand Vision.Net is a fully integrated lighting management system designed to meet the most demanding lighting environments. Scalable from a single room to large multi-building campuses, our decentralized control approach delivers unparalleled flexibility and maximum reliability. Designed to integrate with all Strand dimming systems, low voltage switching cabinets, Vari-Lite and Strand fixtures, Vision.Net can control any lighting load...
  • Page 7 Vision.net Hardware User ManUal 2  VIsIOn.neT COnTrOl sTaTIOns This section describes Vision.Net Portable Stations, Vision.Net Keyswitch Stations, and Vision.Net Wall Stations. STANDARD STATION OVERVIEW The Standard Button Station is a Button Station with Raise/Lower. This station is a push button station that has 6 full sized buttons and the last button space is split into 2 half sized buttons.
  • Page 8 Designer for Vision.Net. UnDersTanDInG THe sTaTIOns Vision.net products are controlled by the Strand Vision.net (SVN) protocol. All Vision.net control devices must be connected to the Vision.net system and given a unique ID (or address) in order to interact properly. The ID identifies the device on the network and allows the device to avoid network collisions when transmitting data.

  • Page 9: Operation Modes

    Vision.net Hardware User ManUal UnDersTanDInG BUTTOn alIGnMenT Many button stations are specified with fewer Single Button Two Button Four Button than the maximum capacity of buttons. To Station Alignment Station Alignment Station Alignment simplify manufacturing, these are still full button stations however only the quantity of buttons that are specified is exposed.

  • Page 10: Configurable Mode

    Vision.net Hardware User ManUal COnFIGUraBle MODe In Configurable Mode, VisionNet products are controlled by the Vision.net System protocol (VNS). All Vision. net devices must be given a Station ID (or address), which identifies the device on the network and allows it to avoid network collisions when transmitting data.
  • Page 11 Vision.net din rail enclosUre Vision.net Hardware User ManUal 3  oVerView VIsIOn.neT DIn raIl enClOsUres P ROD UCT NAM E OR DE R COD E Vision.net DIn rail enclosure - small 53906-001 installation and set UP To prepare the Vision.Net DIN Rail Enclosure for installation: Step 1.
  • Page 12 Install DIN rail components, following the appropriate methods and safety procedures per device. Step 3. Re-attach front cover and tighten screws. Vision.net Hardware User ManUal encloUsre groUnding Where required use threaded stud inside of enclosure and included 10-32 nut to bond the enclosure to earth.
  • Page 13 MoUnt traYs Vision.net Hardware User ManUal oVerView 4  VIsIOn.neT DIn raIl P ROD UCT NAM E OR DE R COD E raCK TraYs Vision.net DIn rail rack Mount Tray, Horizontal (3U) 53906-101 installation To install Vision.Net DIN Rail Rack Mount Trays: Step 1.
  • Page 14 PoE AP PROVED P OWE R S UP PL I E S PoE-171A-60 Planet Technology Vision.net Hardware User ManUal PoE-173 Planet Technology POE60U-1BT Phihong 5  VIsIOn.neT GaTeWaY POE90U-BT Phihong (Fully compliant) 24V AP PROVED POWER S UP PL I ES Vision.Net Gateway, Gateway Module - DMX/RDM Interface (4 port) and Gateway Module - RS485 Interface (1...
  • Page 15 Vision.net Hardware User ManUal 6  VIsIOn.neT MODUles Mounting and installation instructions for Vision.Net modules can be found in the quickstart guides available for download from our website. Configuration and programming of the Vision.Net modules is to be performed only by Certified Technicians.

  • Page 16: Occupancy Sensors

    Vision.net Hardware User ManUal 7  VIsIOn.neT sensOrs OCCUPANCY SENSORS This section provides installation and programming instructions for the following Vision.net Products: • 63059CM - Vision.net Ceiling Occupancy Sensor • 63059HB - Vision.net High Bay Ceiling Occupancy Sensor IMPORTANT INFORMATION. PLEASE READ! This unit is intended for installation in accordance with the National Electric Code®...
  • Page 17 Vision.net Hardware User ManUal WIrInG Ceiling Occupancy Sensors should be connected to a Vision.Net station. To connect wiring to ceiling occupancy sensors: Step 1. If conduit is required by local code, route low voltage wiring into adjacent junction box and secure with included 1/2- inch nipple.
  • Page 18 Vision.net touchscreen processor electronics box 95631 (for use with external monitor) (for use with external monitor) Vision.net Hardware User ManUal COM P AT I BL E M ON I TO RS COM P AT I BL E M ON I TO RS 15”...

  • Page 19: Technical Support

    The information presented in this document is not intended as any commercial offer and does not form part of any quotation or contract, unless otherwise agreed by Signify. Data subject to change. VISION.NET HARDWARE USER MANUAL VERSION DATE: JULY 14 2022...
