- Page 1 Assembly manual Overhead guard (7181.05)
- Page 2 Place the machine on a level surface and secure it with the parking brake. Valid as from: August 2021 Switch the machine off and pull out the key. Hako GmbH 23843 Bad Oldesloe, Germany Hamburger Str. 209-239 Phone +49 4531 806-0...
-
Page 3: Overhead Guard
Overhead guard Overhead guard Parts list 1 1x overhead guard - Right front bar (Fig. 1/1A) - Left front bar (Fig. 1/1B) - Right rear bar (Fig. 1/1C) - Left rear bar (Fig. 1/1D) - Frame (Fig. 1/1E) - Front roof (Fig. 1/1F) - Rear roof (Fig. - Page 4 Overhead guard Before installation 1. Remove side panelling with provided wrench (Fig. 2/1). 2. Swivel seat console all the way upwards (Fig. 2/2). 3. Remove cover (Fig. 2/3). 4. Unscrew seat bearing (Fig. 2/4). 5. Remove battery at lifting points (Fig.
- Page 5 Overhead guard Installing the bars 1. Insert the six sealing plugs into the open ends of the four bars (Fig. 3/1). 2. Attach the two front bars (Fig. 3/2) with the M12x120 screws and the six washers to the chassis finger-tight (Fig.
- Page 6 Overhead guard 1.4.1 B 260 R - drill new bore holes 1. Drill two new bore holes (Fig. 4/1). 2. Position the rear spar on the left in the direction of travel in front of the new drill holes. 3. Attach each of the rear bar to the chassis with two M10x20 hex screws and the SKM 10 detent edge washers (tighten ...
- Page 7 Overhead guard Frame installation 1. Position the frame (Fig. 5/1) between the front and rear bars as per the illustration and attach to the bars with the eight M6x20 cylinder head screws (secure with Loctite type 243) and detent edge washers (Fig.
- Page 8 Overhead guard Roof installation B175 R 1. Attach the front roof (Fig. 6/1) to the two front bars with four M6x20 flat round screws, washers, M6 nuts (Fig. 6/2) and four M8x20 flat round screws, washers and M8 nuts (Fig.
