Summary of Contents for HAKO 7181.85
- Page 1 Assembly manual Flashlight on overhead guard (7181.85)
- Page 2 Place the machine on a level surface and secure it with the parking brake. Valid as from: November 2018 Switch the machine off and pull out the key. Hako GmbH 23843 Bad Oldesloe, Germany Hamburger Str. 209-239 Phone +49 4531 806-0...
- Page 3 Flashlight on overhead guard Flashlight on over- head guard Parts list 1 1x flashlight, pre-assembled (with cable loom W 66) 2 3x hexagon bolt M6x16 3 3x detent edge washers SKM6 4 1x corrugated hose holder Fig. 1...
- Page 4 Flashlight on overhead guard Flashlight installation 1. Remove side panelling with provided wrench (Fig. 2/1). 2. The flashlight is fitted to the left rear overhead guard from the inside using the three M6x16 screws and the washers (Fig. 2/2). When tightening the screws it must be ensured that the flashlight is aligned in a vertical position.
- Page 5 Flashlight on overhead guard Setting in the configuration menu The Flashlight on overhead guard option must be activated via the configuration menu. Option Value Flashlight on overhead 1. A. 1. guard Requirements: • Batteries inserted • 4-digit code or diagnosis plug 97097737 present If diagnosis plug is used: Plug diagnosis plug into slot X20 of...
