Summary of Contents for Absolute Measurement CLT
- Page 1 Transducer Instruction Manual Range: Ultra Type: Revision: V1.0...
-
Page 2: Table Of Contents
Low Output Signal With Maximum Tension ................. 7 Wrong Polarity of Output Signal ....................7 Output Signal Not Linear, Zero Shifts During Operation............... 8 Transducer Strain Gauge Resistance ..................... 8 _____________________________________________________________________________________________________________________ Absolute Measurement Ltd. (T/A CMC Controls) t: (0) 1732 763278 | e: sales@absolutemeasurement.co.uk | w: absolutemeasurement.co.uk... -
Page 3: Principle Of Transducer Operation
Size 2 20, 25, 30, 35 66.7 89.0 15.7 115 63.5 47.5 49.3 _____________________________________________________________________________________________________________________ Absolute Measurement Ltd. (T/A CMC Controls) t: (0) 1732 763278 | e: sales@absolutemeasurement.co.uk | w: absolutemeasurement.co.uk Unit 19 | Silver Birches Business Park | Aston Road | Bromsgrove | B60 3EU... -
Page 4: Installation Precautions
SECURELY tighten the mounting bolt. The cable connector should bisect the web wrap angle. The mounting bolt must not bottom in the transducer, the depth of the mounting hole in the CLT-SCM transducer is 14mm. Check that there is clearance between the mounting bolt and the bottom of the transducer mounting hole. -
Page 5: Clt-Flcm Installation
"LOAD LINE" label as shown, then secure the transducer firmly in the machine frame using the lockplate. A spacer over the transducer body may be used if required. _____________________________________________________________________________________________________________________ Absolute Measurement Ltd. (T/A CMC Controls) t: (0) 1732 763278 | e: sales@absolutemeasurement.co.uk | w: absolutemeasurement.co.uk... -
Page 6: Sensing Roller Installation
Any out of balance force should not exceed 10% of the maximum working force (MWF) of the transducer. The recommended maximum roller length is 450mm to avoid an excessive bending moment being applied to the transducer and roller deflection. _____________________________________________________________________________________________________________________ Absolute Measurement Ltd. (T/A CMC Controls) t: (0) 1732 763278 | e: sales@absolutemeasurement.co.uk | w: absolutemeasurement.co.uk... -
Page 7: Temperature Compensation And Shaft Expansion
The formula for calculation of the transducer maximum working force (MWF) or force rating allows a 100% overload for tension transients or a tight edge to the web. Remember to use the correct units. _____________________________________________________________________________________________________________________ Absolute Measurement Ltd. (T/A CMC Controls) t: (0) 1732 763278 | e: sales@absolutemeasurement.co.uk | w: absolutemeasurement.co.uk... -
Page 8: Troubleshooting
The transducer may be incorrectly orientated, rotate 180 to correct this. If rotation is not possible, interchange the transducer excitation supply or output signal leads at the indicator or controller terminals. _____________________________________________________________________________________________________________________ Absolute Measurement Ltd. (T/A CMC Controls) t: (0) 1732 763278 | e: sales@absolutemeasurement.co.uk | w: absolutemeasurement.co.uk... -
Page 9: Output Signal Not Linear, Zero Shifts During Operation
(Varies slightly based on load cell 133 Ω RD/BU 1 - 3 temperature) _____________________________________________________________________________________________________________________ Absolute Measurement Ltd. (T/A CMC Controls) t: (0) 1732 763278 | e: sales@absolutemeasurement.co.uk | w: absolutemeasurement.co.uk Unit 19 | Silver Birches Business Park | Aston Road | Bromsgrove | B60 3EU...
