Summary of Contents for Globalsat HR-50
- Page 1 Globalat HR-50 / HR-50B / HR-50N Optical Heart Rate and Activity Tracking Fitness Band User Manual...
-
Page 2: Table Of Contents
Content 1. Introduction 1.1 Product Description 1.2 Features 2. Getting Started with Your HR-50 / HR-50 B/ HR-50N 2.1 First Time Use 2.2 Battery Change Method 2.3 Take HR-50/B/N Out from Device Holder 2.4 Wear HR-50/B/N on Your Wrist 2.5 Trigger Your Device 2.6 Show Time of Day... -
Page 3: Introduction
1. Introduction 1.1 Product Description HR-50 / HR-50B / HR-50N is a heart rate monitor device with activity tracking function (B/N model). You can know your heart rate when heart rate function is working (all model). Besides, HR-50 B / HR-50N also records your daily steps, calories and sleep pattern. -
Page 4: Getting Started With Your Hr-50 / Hr-50 B/ Hr-50N
Show time of day. NFC tag for identification recognition. 2. Getting Started with Your HR-50 / HR-50 B/ HR-50N 2.1 First Time Use Please take out the battery insulation film to enable HR-50 / HR-50 B/ HR-50N before first time use. -
Page 5: Battery Change Method
2.2 Battery Change Method 2.2.1 Put HR-50/B/N main device into device holder. 2.2.2 Open top case by using the attached top case opener and rotate top case in counterclockwise direction for about 15 degree. 2.2.3 Lift top case by your hand. Please note that you could lift the top case easier by... -
Page 6: Take Hr-50/B/N Out From Device Holder
2.3 Take HR-50/B/N Out from Device Holder You could take HR-50/B/N out from device holder by bending the latch of device holder (in 6 or 12 o’clock direction) and push HR-50/B/N from its back at the same time. 2.4 Wear HR-50/B/N on Your Wrist... -
Page 7: Trigger Your Device
As for heart rate function, press button for 3 seconds to turn on (off) HR-50B/N heart rate function and LED will light in clockwise (counterclockwise) direction. 2.5.2 For HR-50 Press button for 3 seconds to turn on (off) heart rate function and 12 o’clock LED will flash. -
Page 8: Low Power Indication
2.7 Low Power Indication When HR-50/B/N is going to run out of battery, LED in 12 o’clock direction will keep flashing. This is a reminder for user to replace a new battery. Please note that when battery is low, heart rate / time / APP data transfer function will be off. However, step / calorie / sleep function will still be working until HR-50/B/N runs out of battery. -
Page 9: Getting Started With Your App
3. Getting Started with Your APP PS: Please note that when using HR-50 with this APP, this APP only supports instant HR function in TODAY page. 3.1 APP Installation Please go to App store / Google play and search “globalsat gsport2”. Then, you will find below icon. -
Page 10: Start Your App
3.2 Start Your App Step 1: Place your HR-50/B/N near your mobile device. Step 2: Look for gSport2 icon in your mobile device, and then click to open the gSport2 APP. - Page 11 PS: If this is your first time use, please go to DEVICE page. Then, follow steps described in DEVICE page to do the pairing process. When you successfully pair your HR-50/B/N with gSport2 APP, you can start to use it.
-
Page 12: Today Page
When you run gSport2 APP, you will enter TODAY page and gSport2 APP will synchronize with your HR-50/B/N automatically. Then, you can check today’s steps, calories burned and current heart rate. You can also synchronize your HR-50/B/N with gSport2 APP instantly by pressing the sync. icon on upper-right of TODAY page. -
Page 13: Main Page
3.4 MAIN page: You can go to different functions of gSport2 APP in this MAIN page. Besides, you can also check you battery and connection status in MAIN page. battery status go to previous page go to TODAY page connection status go to PROFILE page go to GOAL page go to ACTIVITY page... -
Page 14: Goal Page
3.6 GOAL page: You can set your daily goal of steps and sleep hours in GOAL page. Please press “Apply” button when you finish setting your daily goal. Besides, gSport2 APP will also show your heart rate intensity zone. go to MAIN page... -
Page 15: Activity Page
3.7 ACTIVITY page: (1) Load record: By pressing the synchronization button on the upper-right of ACTIVITY page, you can load activity record from HR-50B/N to gSport2 APP. (2) Review record: You can check your daily steps record in ACTIVITY page. When you select a specific daily step date, you can view your steps bar chart, total steps, calorie burned, goal achieved, walking/running/total distance and walking/running time on that date. -
Page 16: Sleep Page
3.8 SLEEP page: (1) Load record: Your sleep record will show up “AUTOMATICALLY” once you load your activity data in ACTIVITY page. Or, you can also press the synchronization button on the upper-right of SLEEP page to load sleep record. However, if you want to assign your specific start/end time of sleep, please press the “+”... -
Page 17: Heart Rate Page
3.9 HEART RATE page: (1) Load record: By pressing the synchronization button on the upper-right of HEART RATE page, you can load heart rate record from HR-50B/N to gSport2 APP. (2) Review record: You can check your heart rate status during your exercise by entering this HEART RATE page. -
Page 18: Device Page
3.10 DEVICE page: You can pair your HR-50/B/N with gSport2 APP in DEVICE page. Press the icon in upper-right of DEVICE page and gSport2 APP will start to search HR-50/B/N device. When your HR-50/B/N is found, please tap the device shown. Then, there will be a pop-up message asking you to connect with your HR-50/B/N. -
Page 19: About Page
3.11 ABOUT page: You can view your gSport2 APP version in Version row and HR-50/B/N device firmware version in Device firmware row in ABOUT page. 4. Firmware Upgrade 4.1 Firmware Upgrade Notification Please note that if your HR-50B/N device firmware is not the latest. There will be a pop-up message showing up in ABOUT page reminding you to upgrade your HR-50B/N device firmware. -
Page 20: Firmware Upgrade Steps
4.2 Firmware Upgrade Steps Press YES when there is pop-up message showing up to remind you to upgrade your HR-50B/N device firmware. Then, the latest HR-50B/N firmware will be transferred from gSport2 APP to HR-50B/N device. After the transferring process finishes, please make sure to press OK at the message showing firmware transfer completed.
