- Page 1 Instruction Manual VETSPIN DUO® VETERINARY CENTRIFUGE FOR IN VITRO DIAGNOSTIC USE...
- Page 3 Product Number 01500-00 – Hawksley VetSpin Duo (for 240VAC, 50/60Hz) VetSpin Duo is a registered trademark of Hawksley & Sons Ltd, whose address is 25 Marlborough Road, Lancing Business Park, Lancing, East Sussex, United Kingdom, BN15 8TN Company number : 01503795...
-
Page 4: Table Of Contents
Contents Introduction 6 Intended Use ..................6 Symbol Key ..................7 Product Overview 8 Product Contents ................8 Technical Specifications ..............9 General Considerations ..............10 Transport & Installation 13 Transportation ..................13 Installation ..................13 Delivery ..................13 Set up ....................13 Installation Considerations ............14 Initial Operation ................16 Moving the Centrifuge ..............16 Storage ....................17... - Page 5 Cleaning & Maintenance 25 Cleaning ................... 25 Sterilization ..................27 Service ....................27 Rotor Gasket Replacement .............. 27 Mechanical Emergency Door Release ..........28 Troubleshooting 29 Error Indicators ................29 Safety Precautions ................30 VetSpin Duo® Warranty 32 VetSpin Duo® Disposal 33...
-
Page 6: Introduction
Introduction This manual is for the Hawksley Vetspin Duo® centrifuge. It is vital that all instructions in this manual are understood and followed, otherwise no claim of warranty will be considered by the manufacturer. Customers should be aware that these operating instructions are a part of this medical device and need to be kept readily available. -
Page 7: Symbol Key
Symbol Key Signal Words & Colours Degree of Hazard Warning Indicates a hazardous situation that, if not addressed, can result in serious injury or death. Caution Indicates a hazardous situation that, if not addressed, could result in minor injury Notice Important Information that is non-hazard related Symbol on Device &... -
Page 8: Product Overview
Product Overview Product Contents • 1 x VetSpin Duo® Combination Centrifuge • 1 x Combination Rotor • 1 x Power Cable • 1 x User Manual • 1 x Rotor Removal Tool • 2 x 3amp Fuse • 1 x Rotor Lid •... -
Page 9: Technical Specifications
Technical Specifications Manufacturer Hawksley & Sons Model VetSpin Duo® Centrifuge Mains Voltage 220-230V Mains Frequency 50/60Hz Motor Type AC Brushless Motor Max RPM 10,000 rpm Maximum RCF 9,380 RCF Max Time 99 minutes Speed Accuracy ± 50 rpm Maximum Capacity:... -
Page 10: General Considerations
• The Hawksley VetSpin Duo® is an exceptionally safe machine and has been designed and tested to be compliant with all European and National safety standards. However, when users operate the centrifuge for procedures it is not intended for, Hawksley &... - Page 11 • To avoid damage as a result of condensation, when changing from cold to warm locations, or vice versa, the following protocols should be followed: Cold to Hot: when moving to a hotter climate, the centrifuge must rest at room temperature for at least 3 hours before being connected to a power supply.
- Page 12 • Only original spare parts and original accessories licensed by Hawksley & Sons Ltd can be used with this centrifuge. • The following safety regulations apply: EN/IEC 61010-1, EN/IEC 61010-2-020, EN/IEC 61010-2-101, including any national deviations.
-
Page 13: Transport & Installation
Delivery • Check the Centrifuge, accessories, and packaging for any shipping damage. If there is any visible damage, notify Hawksley & Sons Ltd and the shipping company immediately. • Check the order for completeness – If not contact Hawksley & Sons Ltd. -
Page 14: Installation Considerations
Notice Once placed, the horizontal alignment of the centrifuge must be inspected. The VetSpin Duo® should ideally be checked with a spirit measure (tool). The bench where the centrifuge is set-up must be suitable. - Page 15 Caution Ultraviolet rays can damage the plastics and coatings of the centrifuge & accessories. Caution Harmful chemicals (e.g., strong ph.) must be avoided. Contact can lead to corrosion of the protective casing, damaging the structural integrity of the centrifuge and accessories. Corrosion of the rotors can lead to rotors being more likely to develop cracks and general damage compromising their structural integrity.
-
Page 16: Initial Operation
Initial Operation • During centrifugation; hazardous substances and all people must be outside the clearance zone • Connect the centrifuge with the power cord to a standard mains socket that is turned off • Turn the mains socket on • Check that the digital display is working •... -
Page 17: Storage
The centrifuge should be stored upright on its feet Operating the Centrifuge Overview Hawksley’s VetSpin Duo® is designed for a busy veterinary practice. The VetSpin Duo® has a succinct interface with 3 pre-set programs for rapid spinning, whilst giving practitioners options to adjust speeds and time. -
Page 18: Interface Map
Interface Map... -
Page 19: Quick Start Guide
Quick Start Guide For those who require simple speed and time adjustment: • Ensure that the lid is closed, and a LID OPEN message is not displaying on the digital display • Press the PROGRAM button to select the pre-set program •... -
Page 20: Control Panel Keys
Selects the program directly. When pressed, the program button will alternate between the 3 pre-set cycles of the VetSpin Duo. The current program will be displayed by an LED as per the image. Program parameters are as follows: Serum/Plasma – 10,000RPM for 2 minutes PCV(MHct) –... -
Page 21: Rotor Installation And Balancing
Check Rotor Gaskets. Replace if they appear worn or damaged and post-pone procedure until replaced (Rotor Gaskets can be pur- chased directly from Hawksley & Sons Ltd) Weigh the samples and make sure samples of the same weight are placed in such an orientation that they are opposite one another... -
Page 22: General Guidelines To Make Sure You Load A Rotor Correctly
Loading the Rotor General guidelines to make sure you load a rotor correctly: • The minimum tubes required is two (loaded opposite each other to balance). One can process a single sample by using a second tube with the same weight as a counterbalance, placed exactly opposite. •... -
Page 23: Centrifuged Vessels
They must also be filled to a level so far that no fluid can be expelled from them whilst the centrifuge is running. NB: Do not place tubes that are too large or too small into the centrifuge. The Hawksley VetSpin Duo® takes • 75mm capillary tubes (Plain, Heparin, K2 EDTA, Lithium) •... -
Page 24: Calculations
Examples of incompatible tubes: 3ml, 5ml, 7ml, 10ml, 15ml & 15ml centrifuge tubes/vacutainers PCR Strips 40mm capillary tubes Blood or specimen bags Open or damaged consumables Calculations Calculating Maximum Rotor Speed The maximum speed is calculated for samples with a maximum density of 1.2 gram/ cm . -
Page 25: Notes On Rcf & Rpm
Notes on RCF & RPM The Hawksley VetSpin Duo® digital display shows the speed in Revolutions per Minute (RPM) of its rotor. If a user is ever required to calculate from RPM to RCF, or vice versa, there is a calculation that allows the user to do... - Page 26 Caution If damage is found that could compromise the safety of the centrifuge, please get in touch with Hawksley’s engineers, who can advise on safety concerns, as well as repair information. Caution If a rotor has any signs of wear or corrosion, they can no longer be used.
-
Page 27: Sterilization
• Do not autoclave rotors. Service Refer to the Hawksley warranty for further instruction and make sure to fill out the warranty card before return. Remember that decontamination of the centrifuge & all of its accessories must be completed before returning for servicing, repair, or disposal. -
Page 28: Mechanical Emergency Door Release
After sample retrieval place the plastic plug back into its slot Plug the power cable back in and close the lid Wait 10 seconds and then press the ‘lid open’ button If after these steps your centrifuge is no longer working - contact Hawksley’s services department or your distributor. -
Page 29: Troubleshooting
If you are using the supply External power supply correct power supply, get in contact voltage is exceeds AC242V. with Hawksley’s repair team, who will high advise on next steps, including any required repairs. E2 or Either the sensor is not... -
Page 30: Safety Precautions
If errors continue to be displayed despite having taken recommended measures, then the centrifuge Caution sensors are most likely damaged. Call our services department. Safety Precautions • Do not move the centrifuge while rotor is turning This includes if the centrifuge is set up incorrectly Notice (e.g., not horizontal) do not use unless rectified •... - Page 31 • Proceed with caution if rotor and accessories are not original or specially recommended, ensuring correct rotor speeds have been calculated for the new rotor • Do not centrifuge any materials that are flammable or explosive • Do not centrifuge chemically reactive solutions •...
-
Page 32: Vetspin Duo® Warranty
VetSpin Duo® Warranty The VetSpin Duo® is warranted to be free from defects in material and/or workmanship, under normal use for a period expiring of two years from date of installation. This is dependent that the purchaser of the centrifuge has completed and forwarded the Hawksley Warranty document. - Page 33 VetSpin Duo® Disposal IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH THE EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) At the end of its working life, the product must not be disposed of as urban waste.
- Page 34 HAWKSLEY & SONS LTD 25 MARLBOROUGH ROAD LANCING BUSINESS PARK LANCING SUSSEX BN15 8TN UNITED KINGDOM WEBSITE—https://hawksley.co.uk/ Email—enquiries@hawksley.co.uk TEL— +44 (0)1903 752815...
