Summary of Contents for Nulite NL-M10Y/32
-
Page 2: Table Of Contents
Contents Package Contents afety nstructions achine arameters 3.1 Machines Scheme 3.2 Performance parameters table 3.3 Exploded View Installation Guide 4.1 omponent 4.2 Installation require ents 4.3 Connection diagram of the machine inlet and outlet 4.4 Electrical connection Instructions 5.1 Water quality requirements 5.2 Use in harsh climates 5.3 Reuse peration anual... -
Page 3: Package Contents
1. Pack ge contents After unpacking, please check that you have the following components. Heat pump x 1 Operating instructions x 1 Heat pump Operating instructions 2. Safety Instructions This manual provides you with the information necessary for optimal use and maintenance. Please read this manual carefully before installation and use and keep it for future reference. -
Page 4: M Achine Arameters P
35 ° C. When the water temperature is higher than 35 ° C, please do not let water enter the machine. achine arameters 3.1 Machines Scheme φ32 model NL-M10Y/32 NL-M15Y/32 NL-M18Y/32 NL-M22Y/32 Unit: mm *There maybe deviation in the d imension, please refer to the real objec t. -
Page 5: Performance Parameters Table
3 2 Performance parameters table Model M10Y/32 M15Y/32 M18Y/32 M22Y/32 Advised pool volume (m³) 5~15 10~20 11~20 12~25 Power supply 230V~/ 1 Ph/ 50Hz Operating ambient temp (°C) 7~43 Casing type Galvanized metal case Refrigerant capacity (kW) 2.91 4.20 5.20 6.45 0.58 0.83... -
Page 6: Exploded View
NL-M10Y/32 Number Number... - Page 7 NL-M15-18-22Y/32 Number Number...
-
Page 8: Installation Guide
4. Instructions Guide 4.1 Components Before the machine is installed, the following components need to be configured to complete the installation: 1. Circulating water pump: 1 set, providing water circulation power between the machine and the swimming pool. 2. Swimming pool: 1 3. -
Page 9: Electrical Connection
step2 4.4 Electrical connection Mini plug Circulation pump Outdoor socket 1. Make sure the power supply has a reliable ground. The machine and the circulating water pump run at the same time, so it is recommended to connect the two on the same circuit. 5. -
Page 10: Use In Harsh Climates
Min. Max. 7 0 . 7 8 . Free chlorine (mg/l) TAC (mg/l) TAC (°F) Salt (g/l) If the water quality exceeds the data range of the above table, it may cause irreversible damage to the machine. If the machine is damaged as a result, the corresponding warranty terms are invalid. -
Page 11: 2 . Description Of Button And Operating Display
6 2 . Description of button and operating display ON / OFF: In the main interface, press this button for two seconds to switch on or off. Display status after shutdown Real time water inlet temperature ℃ Shutdown status display Display status at startup Real time water inlet temperature... -
Page 12: Maintenance And Repair
Flashing display ℃ Status query 1. Press and hold the " " key for 3 seconds to enter the status query. After entering the query interface, press the " " or " " key to query the parameters and cycle through them. Short press the "ON / OFF"... -
Page 13: Repair Processing
3. The area around the machine should be clean and well ventilated. The evaporator and the evaporator shield should be cleaned regularly to maintain good air flow and ensure that the machine has high operating efficiency. 4. Check the power and cable connections frequently. If there is abnormal operation or a burning odor near the electrical room, please turn off the machine and contact a professional technician for maintenance. - Page 14 CODE M ACHINE STATE S TATE DESCRIPTION SUGGESTION 1. The exhaust temperature Exhaust tempera- 1. Replace the sensor EE 04 sensor is damaged ture sensor 2. Replace the circuit board 2. Circuit board is damaged malfunction 1.Ambient temperature 1. Replace the sensor Ambient tempera- EE 05 sensor is damaged...
-
Page 15: Recycling Instructions
compressor, it is necessary to wait at least 3 minutes before restarting the compressor. This is a normal protective measure. ( ) The machine is in defrosting operation. At this time, the compressor will stop, and it will automatically resume operation after the defrost is over. (5) The machine is in fault or other protection status, please refer to the above table for details.
