Summary of Contents for Rollei Desview R72
- Page 1 7 inch 3D-LUT Monitor...
-
Page 2: Table Of Contents
Contents What's in the Box ■ Notice ■ Quick Start ■ Menu Operation Guide ■ LUT Import ■ Upgrade Instruction ■ Menu Guide ■ Technical Data ■ Disposal and Conformity ■ Warranty ■... -
Page 3: What's In The Box
WHAT'S IN THE BOX Before using this product, please check carefully whether everything is in the package. lf there is anything missing, please contact us. 1x Field Monitor 1x Standard HDMI Cable 1x D-Tap Cable 1x Storage Bag 1x Mini HDMI Cable 1x lnstruction Manual 1x Cold Shoe 1x USB Stick... - Page 4 Thank you for buying this monitor. The content mentioned in this instruction manual concerns your safety and legitimate rights and responsibilities. Please read this instruction manual carefully before using this product to ensure that the product has been properly set up. Failure to follow the instructions and warnings in this instruction manual may cause harm to you and the people around you, and damage the monitor or other surrounding ilems.
- Page 5 Dimensions...
- Page 6 Top / Bottom View...
- Page 7 Attention: This is a capacitive touchscreen monitor, all option and content in menu can be operated by the touchscreen or the buttons. Double-tap screen to open Touch on the screen beside the Pinch to zoom. the menu. menu to exit menu interface.
-
Page 8: Lut Import
LUT IMPORT 1. Copy the Log file into the USB stick. 2. lnsert the USB stick into the monitor's USB interface. 3. Find the ”Custom Lut_usb" in the 4. Open the LUT file you find. LUT config menu, then touch "Search USB". - Page 9 LUT IMPORT 5. Choose the LUT file you need to use, when the icon shows it indicates that the LUT file has been imported successfully. 6. After import the LUT file, touch "Exit USB", then pull out the USB stick.
- Page 10 1. Copy the downloaded upgrade program into the USB stick. 2. lnsert the USB stick into the monitor's USB interface. 3. Find the "Update" in "System config"menu, then touch "OK". The LED light near the power button will start flashing with red and green color.
- Page 14 LUT USB...
-
Page 15: Technical Data
TECHNICAL DATA 7 inch 17.8 x 11.7 x 2.22 cm 380 g 1920 x 1200 1100:1 2600 Nits 178°(HN) ABS engineering plastic DC 7 – 24 V ≤ 18 W HDMl 1.4 HDMl 1.4 3.5 mm stereo headphone jack... - Page 16 TECHNICAL DATA HDMI inpul signal formal HDMI oulpul signal formal 720x480i & 720x480p @ 59.94, 60 Hz 720x480i & 720x480p @ 59.94, 60 Hz 720x576i & 720x576p @ 50 Hz 720x576i & 720x576p @ 50 Hz 1280x720p @ 50, 59.94, 60 Hz 1280x720p @ 50, 59.94, 60 Hz 1920x1080i @ 50, 59.94, 60 Hz 1920x1080i @ 50, 59.94, 60 Hz...
-
Page 17: Disposal And Conformity
Therefore electrical and electronic equipment needs to be marked with the shown symbol. Conformity The Rollei GmbH & Co. KG herewith declare, that this device ”Desview R72” complies with the following guidelines: 2011/65/EC RoHs Directive 2014/30/EU EMC Directive The complete text of the EU Declaration of Conformity can be downloaded at the following Internet address: www.rollei.com/EGK/DesviewR72... -
Page 18: Warranty
The assertion of warranty claims is excluded in the event of violation of the obligation to examine and give notice of defects. If an error occurs and this is reported to us before the warranty expires, Rollei GmbH & Co. KG will, at its own discretion, 1. - Page 19 WARRANTY Warranty Card USER INFORMATION Name Phone: Add: SALES INFOMATION Sale Date: Distributor Name: Distributor Tel: REPAIR LOG Repair Date: Repair name: Issue: Result: repaired not repaired return...
- Page 20 Imported by: Rollei GmbH & Co. KG In de Tarpen 42 D-22848 Norderstedt Service Hotline +49 40 270750277 Production: 2022/03...
