PJD5133/PJD5233/PJD5523w
DLP Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://www.
the upper right corner of our website. "Antes de operar su equipo lea cu idadosamente
las instrucciones en este manual"
Advertisement
Table of Contents
Related Manuals for ViewSonic PJD5133-S
Summary of Contents for ViewSonic PJD5133-S
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www. the upper right corner of our website. “Antes de operar su equipo lea cu idadosamente...
- Page 2 Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 Important Safety Instructions Read these instructions. Keep these instructions. the manufacturer’s instructions. A grounding type plug has two blades and a third grounding prong. The wide blade and the third prong are provided for your safety. If the replacement of the obsolete outlet. unit.
- Page 4 Declaration of RoHS Compliance Technical Adaptation Committee (TAC) as shown below: Proposed Substance Maximum Actual Concentration Concentration Cadmium (Cd) Polybrominated biphenyls (PBB) Polybrominated diphenyl ethers or more lead). weight.
- Page 5 Product Registration To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ® For Your Records Product Name:...
- Page 6 Notes on the AC Power Cord AC Power Cord must meet the requirement of countries where you use this projector. Please confirm your AC plug type with the graphics below and ensure that the proper AC Power Cord is used. If the supplied AC Power Cord does not match your AC outlet, please contact your sales dealer.
-
Page 7: Table Of Contents
CONTENTS Introduction ................ 5 Projector Features ....................... 5 Package Contents ....................... 6 Projector Overview ...................... 7 Using the Product .............. 9 Control Panel ......................9 Connection Ports ....................... 10 Remote Control ......................11 Installing the Batteries ....................13 Remote Control Operation ..................14 Connection ............... -
Page 8: Introduction
Introduction Projector Features The projector integrates high-performance optical engine projection and a user - friendly design to deliver high reliability and ease of use. The projector offers the following features: SVGA (800 x 600 pixels) XGA (1024 x 768 pixels) WXGA (1280 x 800 pixels) Compatibility with Macintosh®... -
Page 9: Package Contents
AC Power Cord Remote Control (IR) & batteries (AAA *2 PCS) VGA Cable (D-SUB to D- ViewSonic CD Wizard Quick Start Guide SUB) Contact you dealer immediately if any items are missing, appear damaged, or if the unit does not work Save the original shipping carton and Packing material;... -
Page 10: Projector Overview
Projector Overview Front View Front IR remote control sensor Control panel Elevator foot Zoom ring Projection lens Focus ring Speaker Lamp cover Ventilation holes... - Page 11 Rear View Connection ports AC power socket Kensington lock Bottom View Security bar Ceiling mount holes Ventilation holes This projector can be used with a ceiling mount for support. The ceiling mount is not included in the package. Contact your dealer for information to mount the projector on a ceiling.
-
Page 12: Using The Product
Using the Product Control Panel MENU/ POWER EXIT TEMP/LAMP Power Turn the projector on or off. SOURCE Display the source selection bar. MENU/EXIT Display or exit the on-screen display menus. Keystone/Arrow keys ( /Up, /Down) Manually correct distorted images resulting from an angled projection. Four directional buttons Use four directional buttons to select items or make adjustments to your selection. -
Page 13: Connection Ports
Connection Ports AUDIO IN Connect an audio output from video equipment or computer to this jack. HDMI Connect HDMI output from video equipment to this jack. S-VIDEO Connect S-Video output from video equipment to this jack. COMPUTER IN 1 Connect image input signal (analog RGB or component) to this jack. RS-232 When operating the projector via a computer, connect this to the controlling computer's RS-232C port. -
Page 14: Remote Control
Remote Control Power Turn the projector on or off. VGA1 Display COMPUTER IN 1 signal. Menu/ Left mouse Display on-screen display menus. Perform the left button of the mouse when mouse mode is activated. Mouse Right mouse Switch between the normal and mouse modes. - Page 15 Video/Page Up Using the remote mouse control Switch input source to Composite/ The capability of operating your computer S-Video/HDMI by sequence. with the remote control gives you more Perform page up function when flexibility when delivering presentations. mouse mode is activated. Connect the projector to your PC or VGA2 notebook with a USB cable prior to...
-
Page 16: Installing The Batteries
Installing the Batteries Open the battery cover in the direction shown. Install batteries as indicated by the diagram inside the compartment. Close the battery cover into position. Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Make sure the plus and minus terminals are correctly aligned when loading a battery. -
Page 17: Remote Control Operation
Remote Control Operation Point the remote control at the infrared remote sensor and press a button. Operating the projector from the front The remote control may not operate when there is sunlight or other strong light such as a fluorescent lamp shining on the remote sensor. Operate the remote control from a position where the remote sensor is visible. -
Page 18: Connection
Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. Audio cable VGA (D-Sub) to HDTV (RCA) cable HDMI cable VGA cable (D-Sub to D-Sub) Composite Video cable... -
Page 19: Connecting A Computer Or Monitor
Connecting a computer or monitor Connecting a computer The projector provides two VGA input sockets that allow you to connect them to both ® ® compatibles and Macintosh computers. A Mac adapter is needed if you are connecting legacy version Macintosh computers. To connect the projector to a notebook or desktop computer: Take the supplied VGA cable and connect one end to the D-Sub output socket of the computer. -
Page 20: Connecting Video Source Devices
Connecting Video source devices You can connect your projector to various Video source devices that provide any one of the following output sockets: HDMI Component Video S-Video Video (composite) You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality. - Page 21 Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output sockets available: If so, you can continue with this procedure. If not, you will need to reassess which method you can use to connect to the device.
- Page 22 details. Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: If so, you can continue with this procedure. If not, you will need to reassess which method you can use to connect to the device.
-
Page 23: Operation
Operation Powering On/Off the Projector Powering On the Projector: Complete the AC power cord and peripheral signal cable(s) connections. Press to turn on the projector. The projector takes a minute or so to warm up. Turn on your source (computer, notebook, DVD, etc.). The projector automatically detects your source. -
Page 24: Adjusting The Projector Height
Adjusting the Projector Height Elevator foot The projector is equipped with an elevator foot to adjust the image height. To raise or lower the image, turn the elevator foot to fine-tune the height. To avoid damaging the projector, make sure that the elevator foot is fully retracted before placing the projector in its carrying case. -
Page 25: Adjusting Projection Image Size
Adjusting Projection Image Size Refer to the graphic and table below to determine the screen size and projection distance. Maximum zoom Minimum zoom Screen Center of lens Vertical offset Projection distance PJD5133/PJD5233 4 : 3 Screen Screen size Projection distance [inch (m)] Image Vertical Diagonal... - Page 26 PJD5523w 16 : 10 Screen Screen size Projection distance [inch (m)] Image Vertical Diagonal height [inch offset [inch (cm)] (min. zoom) (max. zoom) (cm)] [inch (cm)] 45 (114) 55.4 (1.4) 69.3 (1.8) 23.85 (60.58) 2.96 (7.51) 60 (152) 74.5 (2.0) 92.9 (2.4) 31.8 (80.77) 3.94 (10.02)
-
Page 27: Locking Control Keys
Locking control keys With the control keys on the projector locked, you can prevent your projector settings from being changed accidentally (by children, for example). When the Panel Key Lock is on, no control keys on the projector will operate except Power. -
Page 28: Setting The Presentation Timer
Setting the presentation timer The presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Go to the Option > Presentation Timer menu and press on the projector or Enter on the remote control to display the Presentation Timer page. -
Page 29: Menu Operation
Menu Operation The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. Auto, 4:3, 16:9, 16:10*... - Page 30 *16:10 for PJD5523w only...
- Page 31 How to operate Press MENU on the projector or Menu on the remote control to open the OSD menu. When OSD is displayed, use to select any feature in the main menu. After selecting the desired main menu item, press to enter sub-menu for feature setting.
- Page 32 User Color User Color provides six sets (RGBCMY) of colors to be adjusted. When you select each color, you can independently adjust its range, hue, saturation and gain according to your preference. White Intensity Increase the brightness of white areas. Gamma Effect the represent of dark scenery.
- Page 33 Video Setting Allow you to enter the Video Setting menu. Sharpness: Sharpen or soften the image. Tint: Shift colors toward red or green. Color: Adjust the color saturation level. Audio Setting Allow you to enter the Audio Setting menu. Volume: Adjust the projector’s volume level. Mute: Cut off the sound temporarily.
- Page 34 Enable this function when power consumption is under 1W. Option Closed Caption Enable or disable closed captions by selecting CC1 (closed caption1, the most common channel), CC2, CC3, CC4, T1, T2 or OFF. DCR (Dynamic Contrast Ratio) Enable DCR will further enhance contrast ratio by darkening the black scenes. Disable DCR will resume to normal contrast performance.
- Page 35 Resolution Display current input source resolution. H. Frequency Display current image horizontal frequency. V. Frequency Display current image vertical frequency. Lamp Hours Display the lamp’s elapsed operating time (in hours).
-
Page 36: Maintenance
Maintenance The projector needs proper maintenance. You should keep the lens clean as dust, dirt or spots will project on the screen and diminish image quality. If any other parts need replacing, contact your dealer or qualified service personnel. When cleaning any part of the projector, always switch off and unplug the projector first. -
Page 37: Replacing The Lamp
Replacing the Lamp As the projector operates over time, the brightness of the projector lamp gradually decreases and the lamp becomes more susceptible to breakage. We recommend replacing the lamp if a warning message is displayed. Do not attempt to replace the lamp yourself. - Page 38 Turn off the projector. If the projector is installed in a ceiling mount, remove it Unplug the power cord. Loosen the screw in the side of the lamp cover and remove the cover. Remove the screws from the lamp module, raise the handle, and lift out the module.
-
Page 39: Specifications
Specifications Model PJD5133 PJD5233 PJD5523w Display system Single 0.55" DLP panel Single 0.65" DLP panel Resolution SVGA WXGA (800 x 600 pixels) (1024 x 768 pixels) (1280 x 800 pixels) Zoom 1.1X 1.2X F/No. 1.97 - 2.17 1.47 - 1.83 Focal length 21.95 - 24.18mm 21.0 - 25.6mm... -
Page 40: Dimensions
Dimensions 284.0 mm (W) x 234.3 mm (D) x 81.5 mm (H) 284.0 76.4 234.3 81.5 50.9 Ceiling mount installation 193.6 Ceiling mount screws: M4 x 8 (Max. L = 8 mm) 139.0 Unit: mm 210.6... -
Page 41: Appendix
Appendix LED Indicator Messages LED Type Color Status Meaning Power LED Blue Solid Standby mode when green mode is turned on. Temp/Lamp Blue/Red Off Power LED Blue Flash Standby mode when green mode is turned off. Temp/Lamp Blue/Red Off Power LED Blue Solid Powering up... -
Page 42: Compatibility Modes
Compatibility Modes Computer: Resolution H-Sync [KHz] V-Sync [Hz] 640 x 350 37.9 85.0 640 x 480 24.6 50.0 31.5 59.9 37.9 72.8 37.5 75.0 43.3 85.0 61.9 120.0 720 x 400 31.5 70.0 37.9 85.0 800 x 600 31.0 50.0 35.2 56.0 37.9... - Page 43 Video: Compatibility Resolution H-Sync [KHz] V-Sync [Hz] 480i 720 x 480 15.8 480p 720 x 480 31.5 576i 720 x 576 15.6 576p 720 x 576 31.3 720p 1280 x 720 37.5 720p 1280 x 720 1080i 1920 x 1080 33.8 1080i 1920 x 1080...
-
Page 44: Troubleshooting
Troubleshooting Refer to the symptoms and measures listed below before sending the projector for repairs. If the problem persists, contact your local reseller or service center. Please refer to "LED Indicator Messages" as well. Start-up problems If no lights turn on: Be sure that the power cord is securely connected to the projector and the other end is plugged into an outlet with power. -
Page 45: Rs-232 Command And Configuration
RS-232 Command and Configuration Function Action Control Code Return Code Power Power on BE,EF,10,05,00,C6,FF,11,11,01,00,01,00 Power off BE,EF,03,06,00,DC,DB,69,00,00,00,00,00 Source input Computer1 BE,EF,03,19,00,19,29,01,47,02,CC,CC,00 Computer2 BE,EF,03,19,1E,90,72,01,47,02,CC,CC,00 S-Video BE,EF,03,19,00,E8,69,01,47,02,CC,CC,00 Video BE,EF,03,19,00,78,A8,01,47,02,CC,CC,00 HDMI BE,EF,03,19,00,DA,2B,01,47,02,CC,CC,00 Projector Front table BE,EF,10,07,9F,9D,0E,0A,EF,00,00,00,00 position Rear table BE,EF,10,07,9F,9D,0E,0A,EF,01,00,00,01 Front ceiling BE,EF,10,07,9F,9D,0E,0A,EF,02,00,00,02 Rear ceiling BE,EF,10,07,9F,9D,0E,0A,EF,03,00,00,03 Menu... - Page 46 Factory BE,EF,03,06,00,6B,DA,6E,00,00,00,00,00 default Firmware BE,EF,03,06,00,D5,D9,70,00,00,00,00,00 PXX37- version 9..System BE,EF,03,06,00,04,D8,71,00,00,00,00,00 03=Power Status On 00=Off 3D Sync 3D Sync on BE,EF,02,06,00,54,EF,7C,00,01,00,00,01 3D Sync off BE,EF,02,06,00,54,EF,7C,00,00,00,00,00 Color mode Brightest BE,EF,03,06,00,38,5A,88,12,08,08,12,08 BE,EF,03,06,00,38,5A,88,10,00,00,10,00 Movie BE,EF,03,06,00,38,5A,88,13,01,01,13,01 ViewMatch BE,EF,03,06,00,38,5A,88,14,02,02,14,02 White Board BE,EF,03,06,00,38,5A,88,15,05,05,15,05 Black Board BE,EF,03,06,00,38,5A,88,16,06,06,16,06 Green Board BE,EF,03,06,00,38,5A,88,17,07,07,17,07 User 1 BE,EF,03,06,00,38,5A,88,18,03,03,18,03...
- Page 47 D-Sub 9 pin Wire List 1 CD COLOR Black Brown Orange Yellow Green Blue Purple White SHELL SHELL...
-
