- Page 1 Pebble Installation Guide Version 4.7 DOC-3101-01 Document Revision 1.04.00 Oct 2019...
- Page 2 © 2019 Casa Systems, Inc. All rights reserved. Licensed software products are owned by Casa Systems or its suppliers and are protected by United States copyright laws and international treaty provisions. The information regarding the product in this manual is subject to change without notice. All statements, information, and recommendations in this manual are believed to be accurate but are presented without warranty of any kind, express or implied.
-
Page 3: Table Of Contents
Wi-Fi Connection ..............................8 Installing the Wi-Fi Connection using Sprint Set Up Assistant ..................9 Configure Pebble Wi-Fi ........................... 10 Application Dashboard .............................. 14 Resetting the Pebble ..............................17 Pebble Status & LED Behavior (Wi-Fi and Ethernet) ....................19 Pebble Installation Guide... -
Page 4: Preface
The Casa Systems – Pebble Installation Guide is intended for system administrators, support engineers, and operators who are responsible for basic installation and configuration of the Pebble units. Users who perform these tasks should be familiar with the Apex hardware and software capabilities, as well as have experience with both 3G and 4G technologies. -
Page 5: Technical Documentation
Technical Documentation Casa Systems provides the following documentation set in PDF format, viewable using current versions of Adobe Reader©. The latest documentation and revisions are uploaded on a continued basis for Casa customers. Contact Casa Technical Support or a Casa Sales Representative for assistance with downloading selected Casa documentation PDFs. -
Page 6: Overview
Overview The Pebble unit is a low-power RF emitting eNodeB for LTE RAN. The Pebble unit supports one LTE radio sector with two 50 MW (20 dBm) radio streams (4G) that is responsible for radio transmission and reception from UEs in an LTE network. -
Page 7: Network Connection Options
2. Position the GPS antenna puck near a window so it provides a clear and open view of the sky. Warning: The Pebble unit will not connect to the LTE network if the GPS antenna fails to lock on its location. -
Page 8: Wi-Fi Connection
Wi-Fi Connection The Pebble unit ships with the ability to use Wi-Fi to connect to the Sprint network. The Pebble unit can use both 2.4 GHz and 5GHz Wi-Fi access from your Wi-Fi router. Note: The default SSID is "Sprint-Pebble-XXXX”. -
Page 9: Installing The Wi-Fi Connection Using Sprint Set Up Assistant
1. Download the Sprint Set Up Assistant app from the App/Play store on your mobile device or tablet. Select Pebble from the three product options available then follow the prompts. 2. In the Set Up Assistant app, follow instructions to move to Settings and select the Pebble Wi-Fi connection (see below) click Continue. -
Page 10: Configure Pebble Wi-Fi
1. In your phone settings, connect to the Wi-Fi named “Sprint-Pebble-XXXX” and return to the Set Up Assistant app and follow prompts. 2. The app will pair with your Pebble and present the option to configure Wi-Fi backhaul using your home router. Click Configure. - Page 11 3. Select your home Wi-Fi router (5Ghz preferred over 2.4Ghz) from the list. 4. Enter the password (case sensitive) for your home Wi-Fi router then click Connect. Pebble Installation Guide...
- Page 12 5. When prompted, click Continue to setup Wi-Fi backhaul. Note: This process will take 8 to 10 minutes to complete. The app will provide prompts to continue with the Wi-Fi configuration for the Pebble. Pebble Installation Guide...
- Page 13 6. The app provides a progress bar to indicate the status of the Backhaul setup. Once the installation is complete click Continue. Pebble Installation Guide...
-
Page 14: Application Dashboard
Application Dashboard 1. Open the application and click Dashboard. 2. The Dashboard provides information for the Pebble units. Pebble Installation Guide... - Page 15 3. From the Dashboard, click My Device to display information on the Pebble model. 4. From the Dashboard, click Network Settings to display network details. Click Ethernet or Wi-Fi to display specific network details. Click Change to change network settings.
- Page 16 5. From the Dashboard, click Device Status and click LTE to display status information on the Pebble LTE settings. 6. From the Dashboard, click Device Status and click GPS to display status information on the GPS settings. Pebble Installation Guide...
-
Page 17: Resetting The Pebble
1 second short-press reset to reboot both Wi-Fi and LTE 10 second long-press reset to factory reset both Wi-Fi and LTE The Pebble can also be reset using the Set Up Assistant app functions from My Device on the Dashboard and following the prompts:... - Page 18 1. Select Factory Data Reset to clear all configuration of the Pebble. 2. Selet Reset to continue the process. 3. Wait while the device is resetting. Pebble Installation Guide...
-
Page 19: Pebble Status & Led Behavior (Wi-Fi And Ethernet)
4. Press OK to complete the reset process. Pebble Status & LED Behavior (Wi-Fi and Ethernet) The following table lists the behavior of the Pebble and the associated LED activity. Pebble Status Device Startup fixed Device Activating blinking blue Activation Complete... - Page 20 100 Old River Road A ndover, MA 01810 978-688-6706 Pebble Installation Guide © 2019 Casa Systems, Inc. All rights reserved. DOC-3101-01 Document Revision 01.04.00 October 2019 Printed in United States of America Pebble Installation Guide...
