Summary of Contents for smartmi KQJHQ01ZM
- Page 1 Smartmi Air Purifier User Manual...
- Page 2 Warning READ AND SAVE THESE INSTRUCTIONS · When the power cord is damaged, it must be replaced with a genuine power cord purchased from the manufacturer or after-sales service department. · This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand...
- Page 3 Precautions · Turn off and unplug the purifier before moving it. · The purifier cannot turn on when the fan grille and the filter compartment cover are not installed properly. · Maintain a distance of at least 20 cm between the air inlets and walls or other objects. ·...
-
Page 4: Product Overview
Product Overview Read this manual carefully before use, and retain it for future reference. Note: In this manual, the illustrations of the product and its accessories and the user interface are schematic diagrams for reference only. The actual product may vary from that shown in the schematic diagrams due to product updates and upgrades. Please refer to the actual product. Fan grille OLED display screen... - Page 5 Product Overview Screen display Gesture control module PM2.5 PM2.5 level TVOC status indicator TVOC Temperature ≤60 ℃ Humidity 61—300 301—400 ≥401 Power button / Operation Operation mode mode selection button Auto: Purification rate setting automatically Air quality indicator adjusts depending on IAQ. Green, orange, or red is displayed according to Sleep: Purifier operates in ultra-low noise mode the PM 2.5 level detected.
-
Page 6: Installation
Installation Placing the humidifier at an appropriate place Connecting to power supply To allow the purifier to operate as effectively as Connect power cord to the power port at possible, maintain a suitable distance between its air the bottom of the main unit. Then connect inlet and obstructions such as walls (see figure above). - Page 7 Gesture control operations Note: The gesture control function needs to be turned on in the app, please install app first. Gesture detection range: less than 20 cm. Power button / Operation mode selection button Touch to power on the device. After powering on, gently touch this button to select operation mode;...
- Page 8 Filter status reminder Resetting Wi-Fi If your phone cannot connect to the purifier, press the power operation mode selection and screen wakeup buttons simultaneously, and hold for 5 s. An alert tone Filter installation reminder will indicate that the Wi-Fi has been reset successfully. Filter not detected, or installed Please install a genuine filter...
-
Page 9: Maintenance And Care
Maintenance and care Power off purifier and disconnect it from the power supply before performing the following operations. Cleaning the filter housing To maintain optimal ventilation and purification efficiency, remove any dust on the ventilation holes and housing walls using a vacuum cleaner or soft cloth. -
Page 10: Specifications
Specifications Clean Air Delivery Rate Name Smartmi Air Purifier Rated Voltage 120 V~ 400 m (CADR Particles) Formaldehyde Clean Model KQJHQ01ZM Rated Frequency 60 Hz Air Delivery Rate 60 m (CADR Formaldehyde) Item φ 260 × 535 mm Rated Power... - Page 11 FCC ID:2AP98-KQJHQ01ZM Contains FCC ID : 2AC7Z-ESPWROOM32D This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.
- Page 12 Manufactured by: Beijing Smartmi Electronic Technology Co., Ltd. Address:Room 201-203, Unit 6, Building A, No. 66,Zhufang Road, Qinghe, Haidian District, Beijing V-20201106-Y...
