- Page 1 HB 8 US HB 10 US Quick Guide UNDERSEAT AMPLIFIED SUBWOOFER Before operating the unit, please read this manual throughly and retain it for future reference. Any updates are available on harmonycar.it...
- Page 2 Table of Contents Before you start installation Planning your power connections Mounting your unit Control Panel Technical Specifications...
- Page 3 Before you start your installation Control Panel We recommend that a fuse or circuit breaker be placed within 18" of the battery. 1 - Power/Protection Led 2 - Phase Switch (0-180°) /Auto Power-ON 3 - Low-Pass Filter Although you will add a fuse or fuse block near the amplifier it is still a possibility that a (50-150Hz) 4 - Bass Boost (0-12dB) 5 - Input Gain (6-0.15V) 6 - Remote Control Port pinched power wire between the component fuse and the battery could result in a short, 7 - Low Level RCA Inputs 8 - Hi-Level Speaker Inputs 9 - Fuse 10 - Power Connectors...
- Page 4 Technical Specifications Main Features Easy Installation Underseat HB 8 US Power 220 W (Max), 110 W (RMS) HB 10 US Power 260 W (Max), 130 W (RMS) Amplifier Class: Inputs Low Level RCA and High-Level Gain Control Yes, variable Filter Low Pass Bass Boost Yes, variable...
- Page 5 HARMONY is a Brand of APEX Group APEX Europe srl Via della Meccanica 14 - 04011 Aprilia LT - ITALY harmonycar.it / man hb 8.10 us v.1.0...
