DF-12L, DF-12L/2
Electric Fryers
This manual contains important information regarding your
Admiral Craft unit. Please read this manual thoroughly prior
to equipment set-up, operation and maintenance. Failure to
comply with regular maintenance guidelines outlined in
this manual may void the warranty. MUST READ!!!
Advertisement
Table of Contents
Summary of Contents for Admiral Craft DF-12L
- Page 1 DF-12L, DF-12L/2 Electric Fryers This manual contains important information regarding your Admiral Craft unit. Please read this manual thoroughly prior to equipment set-up, operation and maintenance. Failure to comply with regular maintenance guidelines outlined in this manual may void the warranty. MUST READ!!!
- Page 2 When transporting the unit, the machine should be handled carefully, and held by the side handles FEATURES These fryers are available in 2 different models. One is a 1-tank fryer (DF-12L); another is a 2-tank fryer (DF-12L/2). The 2-tank fryer is able fry two different kinds of foods at the same time.
- Page 3 CIRCUIT DIAGRAM S1 - Micro-switch SA - Overheat switch EH - Heater element HL 1 - Power-on indicator HL 2 - Heater-on cycling indicator SB - Temperature regulator E - Ground connection NOTE: THE CIRCUITS OF THE TWO FRYERS ARE IDENTICAL. THE DIFFERENCE IS THAT THE TWO TANK FRYER HAS TWO SEPARATE ELECTRICAL UNIT BOXES AND RECEPTICLES.
- Page 4 ACE Electrical Equipment One Year Warranty ACE warrants its equipment against defects in materials and workmanship, subject to the following conditions: This warranty applies to the original owner only, and is not assignable. ACE Electrical Equipment is warranted for one year, effective from the date of purchase by the original owner.
