- Page 2 These technical conditions will specify produced sizes and solution of the "Ventilating VBM-V box". This applies to production, design, ordering, supplies, assembly, operation and maintenance. Description................................ Construction..............................Size and weight..............................Installation and placement..........................Basic parameters.............................. Electric elements, connection diagram......................Pressure losses…………………………......................Noise data………………...........................
- Page 3 Combined inlet and outlet ventilation VBM-V box is designed to be used in the DCV (demand controlled ventilation) air- conditioning systems with the possibility of regulation of the inlet and outlet air volume on the basis of actual need of ventilation in a ventilated space of industrial or residential buildings.
- Page 4 1250 1250 1400 Removable lid...
- Page 5 Box is designed for its installation into the wall or ceiling. On its shell, there are supporting rails mounted. Box is fixed to the wall by using 4 oval openings in the bearing rails. It is necessary to use appropriate type of fixing screws (recommended M8 screw size) and anchors with load corresponding to the box weight.
- Page 6 ³ ³ LED diodes for control levels: "Automatic operation" control lamp - TURNED OFF - in red functional only with external sensor TURNED ON - in green Pushbutton for ventilation grades Pushbutton switching TURNED OFF/ON Operational voltage 24V AC/DC, 50/60Hz, max. 1,0VA ■...
- Page 7 – REG 1 space controller – N230-24 connector for VBM-V box – servo drive for LMV-D3 air flow controller – connecting cable of the supply voltage 1x230V/50Hz with EURO plug Real-time clock Increases the set value (in settings menu it increases the pa- PARTY / AUTO / MANUAL OPERATION rameter value) Decreases the set...
- Page 8 Blinking clock symbol means that the time was not set or the remote control was not used for more than 48 hours. should be pushed for more than 2 sec → will be displayed and the actual time and day (SEL 00:00 DAY1 (Mon)) should be pushed shortly →...
- Page 9 VBM-V100 VBM-V125 VBM-V160 V (m to the pipe for VBM-V 100 del.p=100Pa del.p=250Pa V (m 90 100 110 120 130 140 to the pipe for VBM-V 125 del.p=100Pa del.p=250Pa V (m 60 70 80 90 100 110 120 130 140 150 160 170 180 190 to the pipe for VBM-V 160 del.p=100Pa del.p=250Pa...
- Page 10 to the surrounding area for VBM-V 100 del.p=100Pa del.p=250Pa V (m 90 100 110 120 130 140 to the surrounding area for VBM-V 125 del.p=100Pa del.p=250Pa 60 70 80 90 100 110 120 130 140 150 160 170 180 190 V (m to the surrounding area for VBM-V 160 del.p=100Pa...
- Page 11 A procedure for setting the min. and max. air flow depending on the ventilation box size will be performed. Functional test by connecting the external REG1 and REG2 controllers will not be performed for the ventilation box. Controllers are packed separately. Boxes are packed separately in a stretch foil.
