Battery connection Solar charger check Reflex photocell Connect the battery to the 2 cables that come our of the box. Connect the red cable to the red terminal [+] Connect the black cable to the black terminal [-] Wiring accessories CN3-BT CONTROL UNIT IC17 After connecting the reflex photocell to the...
Page 12
Contact: closed 18.1 MENU “STATUS” Contact: open Contact: deactivated Q1: position motor 1 Q2: position motor 2 (see Par. 9) ERROR OK: no error STP: stop OPN: OPEN command entered FT1: photocell 1 Limit switch C1/Encoder 1 FT2: photocell 2 Limit switch A1/Encoder 2 OC1: obstacle current - motor 1 Limit switch C2...
16. GENERAL SAFETY MAINTENANCE (EVERY 6 MONTHS) This installation manual is intended for qualified personnel. Remove the power supply 230V or batteries to obscure the solar panel The installation, electrical connections and adjustments must be if present. made in compliance with the following European Directives: Clean and grease the levers and chains in the mechanism.
Page 15
EMERGENCY MANOEUVRE IN CASE OF MALFUNCTION OR LACK OF ELECTRICITY Enter the key in the front lid and turn it. Remove the lid by pulling Rotate downwards the black lever. ATTENTION: be sure that no person, animal, object is near the it up as shown in the picture.
