FAUCET INSTALLATION
This faucet comes with all the components needed for installation,
however, some tools and supplies are not included.
• Basin Wrench
• Plumbers Putty
• Adjustable Wrench
• Hex Key (supplied)
• Adjustable Locking Pliers
• Aerator Key (supplied)
Do not use pipe dope on faucet or supply connections. Possible
solenoid contamination could occur, voiding any warranty.
Step 1.
If you are using an 8˝ cover plate, apply the plumbers putty to
plate and mount it to the deck.
8˝ Centers with coverplate
Step 2.
Place plumbers putty on the product and place on the deck.
Single Hole
4˝ Centerset
Step 3.
Secure faucet with mounting hardware. Flush line before
connecting supply to fitting. NOTE: Supply hose not provided.
Step 4.
Connect supply hose to fitting. AC models only: plug
in transformer.
AC MODELS
ONLY
See next page for SSPS intructions.
NOTE:
For hardwire
transformer,
purchase
accessory
242.340.00.1.
© 2012 Chicago Faucet Company
E-Tronic
User Guide
The Chicago Faucet Company
2100 South Clearwater Drive
Des Plaines, IL 60018
Phone: 847/803-5000
Fax: 847/803-5454
Technical: 800/832-8783
www.chicagofaucets.com
957.079.00.0 05/12
®
40
