Trademarks

FOXWELL is trademark of Shenzhen Foxwell Technology Co., Ltd.

All other marks are trademarks or registered trademarks of their respective

holders.

Disclaimer

The information, specifications and illustrations in this manual are based on the

latest information available at the time of printing.

Foxwell reserves the right to make changes at any time without notice.

Visit our website at

www.foxwelltech.us

For Technical Assistance, send us email at

support@foxwelltech.com

PTS1000 User's Manual V1.2

Table of Contents

Need help?

Do you have a question about the PTS1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Foxwell PTS1000

Page 1 Disclaimer The information, specifications and illustrations in this manual are based on the latest information available at the time of printing. Foxwell reserves the right to make changes at any time without notice. Visit our website at www.foxwelltech.us For Technical Assistance, send us email at support@foxwelltech.com...
Page 2: One-Year Limited Warranty
FOXWELL. 3 The customer shall bear the cost of shipping the product to FOXWELL. And FOXWELL shall bear the cost of shipping the product back to the customer after the completion of service under this limited warranty.
Page 3 The customer will be billed for any parts or labor charges not covered by this limited warranty. d) FOXWELL will repair the Product under the limited warranty within 30 days after receipt of the product. If FOXWELL cannot perform repairs covered...
Page 4 (the Consumer). This limited warranty gives the Consumer specific legal rights and the Consumer may also have other rights which vary from state to state. PTS1000 User's Manual V1.2...
Page 5: Safety Information
● Fuel, oil vapors, hot steam, hot toxic exhaust gases, acid, refrigerant and other debris produced by a malfunction engine can cause serious injury or death. Do not use the tool in areas where explosive vapor may collect, PTS1000 User's Manual V1.2...
Page 6 And never leave a running engine unattended. ● Do not wear jewelry or loose fitting clothing when working on engine. ● Don't connect or disconnect the equipments while the ignition is on or the engine is running. PTS1000 User's Manual V1.2...
Page 7: Table Of Contents
4.2.2 Clone ID by Activation ...................... 26 4.2.3 Automatic Create ID ......................26 4.3 R ........................27 ELEARN UIDE 5 SETTING ............................28 5.1 L ..........................29 ANGUAGE 5.2 S ID F ........................30 ENSOR ORMAT 5.3 P .........................31 RESSURE 5.4 T ........................32 EMPERATURE PTS1000 User's Manual V1.2...
Page 8 5.5 A ............................33 BOUT 6 UPDATE ............................33 7 HELP ...............................34 PTS1000 User's Manual V1.2...
Page 9: Using This Manual
1.2.3 Note and Important Message Note A NOTE provides helpful information such as additional explanations, tips, and comments. Example: NOTE Test results do not necessarily indicate a faulty component or system. PTS1000 User's Manual V1.2...
Page 10: Introduction
DIYers. 2.1 Startup This product includes two parts, PTS1000 software and PTS1000 tool. The two parts are connected together to complete the TPMS related functions. The specific startup process is as follows.
Page 11: Pts1000 Software
Figure 2-2 Sample PTS1000 Software Icon 1. Double-click the icon to start the software. If the PTS1000 tool is not connected to the computer, the startup interface will be shown as below, prompting the customer to "Connect devices PTS1000 via USB".
Page 12: Accessories
Figure 2-3 Sample PTS1000 Software Startup Interface 2. Connect the device to the computer through the USB cable. After successful connection, the "Car Selection Interface" will appear. Figure 2- 4 Sample Vehicle Selection Interface 2.2 Accessories This section lists the accessories that go with the tool. If you find any of the following items missing from your package, contact your local dealer for assistance.
Page 13: Technical Specifications
Description Operation Temperature 0 to 60°C (32 to 140°F) Storage Temperature -20 to 70°C (-4 to 158°F) Power 9V Li-polymer battery Radio Reception 315MHz and 433 MHz Dimensions 188*38*210mm Weight 0.5KG Table 2- 2 Technical Specification PTS1000 User's Manual V1.2...
Page 14: Vehicle Selection
2. OE selection: select the corresponding vehicle by selecting the sensor brand and OE number; 3. It can switch to the corresponding sales area (the domestic version only has the Chinese area); 4. Reset can clear the selected vehicle information and re-select vehicle; PTS1000 User's Manual V1.2...
Page 15: Manual Selection
"letter navigation bar" under the "query dialog", it will automatically jump to the brand starting with the letter. Figure 3-3 Sample Manual Selection - Brand Selection Interface Figure 3-4 Sample Manual Selection - Model Selection Interface PTS1000 User's Manual V1.2...
Page 16: Oe Selection
Figure 3-6 Sample OE Selection Interface "OE number" is the abbreviation of the original sensor number, which is unique and almost all original sensors will print the OE number, sensor ID and other information on the sensor surface. PTS1000 User's Manual V1.2...
Page 17 Figure 3-7 Sample A Original Sensor Figure 3-8 Sample B Original Sensor PTS1000 User's Manual V1.2...
Page 18 Figure 3-9 Sample C Original Sensor Figure 3-10 Sample D Original Sensor 1. The position marked with 1 is the OE number of the sensor. The OE numbers of the four original sensors above are: PMV-C210, 13598773, QY2001A1, 25920615; PTS1000 User's Manual V1.2...
Page 19: Tpms Function
Figure 4-2, 4-3, 4-4, 4-5, 4-6. Otherwise, the download failure prompt interface will appear and it prompts the customer to unplug the PTS1000 tool.If the model has activated the sensor, the sensor information will be displayed directly after entering, as shown in Figure 4-7;...
Page 20 Figure 4-2 prompts the customer to unplug the PTS1000 tool to activate the vehicle tire pressure sensor; Figure 4-2 Sample Unplug The PTS1000 Tool Figure 4-3 prompts the customer to activate the tire pressure sensor in the order of left front, right front, left rear, right rear, and spare tire (if any);...
Page 21 Figure 4-5 Sample Activation Operation Interface Figure 4-6: After activating all tire sensors, connect the device to the computer, and click Read Activation Data to get the relevant information of the activated sensors. PTS1000 User's Manual V1.2...
Page 22: Activation
After activating all tires, connect the device to the computer again, click the "Read Activation Data" button of the PTS1000 software, and the software will obtain the ID, pressure, temperature, battery state and other related information of the activation sensor.
Page 23: Favorites
Figure 4-8 Sample Favorites Interface 4.2 Programming There are three ways to program sensors, namely Manual create ID, Clone ID by Activation and Automatic create ID. Figure 4-9 Sample Programming Interface When programming, please pay attention to the following points: PTS1000 User's Manual V1.2...
Page 24: Manual Create Id
1. Keep the distance between the sensor to be programmed and the PTS1000 tool at 0~20cm; 2. The distance between other sensors and the PTS1000 tool should be kept more than 100cm; 3. The disassembled old sensor needs to be kept away from the vehicle.
Page 25 Figure 4-12 Sample Manual Create ID-Scanning The Sensor Interface Figure 4-13 Sample Manual Create ID-Programming Interface PTS1000 User's Manual V1.2...
Page 26: Clone Id By Activation
4.2.2 Clone ID by Activation The Clone ID by Activation interface is similar to manual create ID interface. You need to activate the vehicle sensor first, then connect the PTS1000 tool to the computer to obtain the activation data, and finally execute the activation clone function.
Page 27: Relearn Guide
There are two learning methods for this vehicle, namely clone sensor and self-learning. Click > on the right to expand the corresponding learning method. PTS1000 User's Manual V1.2...
Page 28: Setting
Figure 4-20 Sample Relearn Guide Expanding You can complete sensor replacement and matching by referring to the methods provided in the relearn guide. 5 Setting It includes settings for Language, Sensor ID Format, Pressure Unit, Temperature Unit and About. PTS1000 User's Manual V1.2...
Page 29: Language
Figure 5-1 Sample Setting Interface 5.1 Language The language flag is listed in the language setting option, select the corresponding flag, and select Yes in the confirmation interface to set the corresponding language. Figure 5-2 Sample Language Setting Interface PTS1000 User's Manual V1.2...
Page 30: Sensor Id Format
5.2 Sensor ID Format In this selection, you can set the ID format to decimal or hexadecimal. Click the format you want to set, and select Yes in the confirmation interface. Figure 5-4 Sample Sensor ID Format Setting PTS1000 User's Manual V1.2...
Page 31: Pressure Unit
Figure 5-5 Sample Sensor ID Format Setting 5.3 Pressure Unit The pressure unit can be set according to the demand, and Kpa/Psi/Bar can be set respectively. Figure 5-6 Sample Pressure Unit Setting PTS1000 User's Manual V1.2...
Page 32: Temperature Unit
Figure 5-7 Sample Pressure Unit Setting 5.4 Temperature Unit The temperature unit can be set according to the demand, and the facility degree/Fahrenheit can be set respectively. Figure 5-8 Sample Temperature Unit Setting PTS1000 User's Manual V1.2...
Page 33 This function is mainly used to update product-related software such as APP, BOOT, firmware, vehicle software etc.. When have a new version, it will automatically jump to this interface after starting the software to guide customers to complete the upgrade function. PTS1000 User's Manual V1.2...
Page 34 It is mainly used to provide user manual, basic function guide videos, tire pressure learning videos for special vehicles, etc., so that customers can get familiar with the product and learn to use it faster. Figure 7-12 Sample Help Interface PTS1000 User's Manual V1.2...
