- Page 1 Read instruction manual carefully! HONEYBEE Gantry CNC Cutting machine Operator’s Manual (MicroEDGEPro CNC System) Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. June, 2014.
- Page 2 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Preface Dear Customer： Thank you for choosing Honeybee series product. Pls carefully read Operator’s Manual in order to formally use and operate the machine. Pls take care of Operator’s Manual during the Warranty Including Part：...
-
Page 3: Table Of Contents
1.1 Safety Introduction..........................3 1.2 Product standard............................3 Chapter 2 Summary............................. 4 2.1 Product instruction............................4 2.2 Technical condition of Honeybee CNC System..................5 Chapter 3 Operation.............................6 3.1 Operation Interface Introduction......................6 3.1.1 Operating Keyboard Functions Introduction.................. 7 This key is for light choosing, every press will choose different light........8 3.1.2 Button Detail Introduction........................9... -
Page 4: Chapter 1 Safety
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Chapter 1 Safety 1.1 Safety Introduction ·Reading the manual book： Reading and understanding the cutting machine operation and require of user safety. If the buyer has other requirements, please let us know. ·operation safety Check the machine ran before the starting. -
Page 5: Chapter 2 Summary
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Chapter 2 Summary Product instruction HBmicroEDGEpro system is a kind of the multi-axis CNC system; it is designed specially for the shape cutting machine. It is also the new product of metal processing industry. The main aim we design is easy to use, the software which can program make the panel design simple and increase the function. -
Page 6: Technical Condition Of Honeybee Cnc System
Pay attention to keep Integrity of every parts and abid by the Installation book on the spot. 2.2 Technical condition of Honeybee CNC System Storage humidity：- 40℃ ～ 50℃ Working humidity：0 ～ 50℃... -
Page 7: Chapter 3 Operation
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Chapter 3 Operation 3.1 Operation Interface Introduction It composed of 39 keys, it is almost same with the normal home PC, but consider more convenient cutting, some keys position are different with home PC, but the functions are same. Operate keyboard Display... -
Page 8: Operating Keyboard Functions Introduction
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. 3.1.1 Operating Keyboard Functions Introduction Display Indicator Numbers Arrow Functions Start/Stop F1--F8 function is same with home PC, accordance with CNC system F1--F8. Different as below picture:... -
Page 9: This Key Is For Light Choosing, Every Press Will Choose Different Light
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Letter and number keys, if green light, these four keys are arrows Indicator, have three color: Blue, red and green. Every key indicate three blue and red letters, black numbers. If light blue, it indicates blue letters, if light red, red letters, if no light on, indicate numbers. -
Page 10: Button Detail Introduction
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. 3.1.2 Button Detail Introduction Power /power light/running light/cut oxygen/preheat gas/THC/Auto fire/Standby /No.1 /No.2 /No.3 /No.4 torch/ USB Emergency stop Run / Pause / Whole THC/No.1 THC/No.2 THC/No.3 THC/No.4 THC/Speed up or down Torch choosing, alternate work mode, total 4 torches to be chosen. Arrow key for torch lift and drop manual control, instant work mode. - Page 11 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. (GAS)Preheat oxygen key (Yellow), alternate work mode, effective under oxy-fuel cutting. （ CUT ） Cutting oxygen key (Green), alternate work mode, add cutting oxygen manually under oxy-fuel cutting. If cutting oxygen key（ CUT） effective, preheat gas button’s （ GAS） situation cannot changed.
-
Page 12: System Start
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. 3.2 Simple operation 3.2.1 System start Keep the key button ON and open the EMERGENCY BUTTON by the clockwise. Turn on the Main power source and press the Power Button at the right-up corner of Operation box, then start the Hypertherm System. - Page 13 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Choose the OK soft key to exit the Help screen and return to the control screen. The Show Bookmarks soft key opens the navigation pane. On a keyboard, press Ctrl+F to use full text search.
-
Page 14: Operation Process
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Under flame cutting model, press THC, Cutting torch keep the state of automatic height control and the relative direct light is working. The CNC will move the next position to cut when the last cutting piece finished and running signal ended. - Page 15 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Set the Flame cutting model in the Hypertherm CNC system. Choose the cutting torch (1-4) on the cutting operating panel. Key THC turns on the automatic height control enable if there is Arc voltage Height Control device.
-
Page 16: Plasma Cutting Process
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. 3.3.2 Plasma cutting process Set the plasma cutting model in the Hypertherm CNC system. Choose the cutting torch (1-4) on the cutting operating panel. Key THC, turns on the automatic height control enable if there is Arc voltage Height Control device. - Page 17 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd.
-
Page 18: Chapter 4 Detailed Operation Guide
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Chapter 4 Detailed Operation Guide Make the part drawing in Computer Copy the drawing by U-stick and connect the USB socket and then Press F2 , enter into Files Choice. Press F1 to read the cutting files in Files Option Press F2 to save the cutting files in File Option. - Page 19 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. 4-1 reading file The above interface read from Diskette, hard disk, USB or Internet. · Loading Choose Folder by key ↑and↓， New folder , delete folder or image driver by Key “+”and“－”，the Diskette means soft disk,and Shape Library is original folder and can not be deleted in hardware. ·...
-
Page 20: Save File
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. 4-2 Preview the loading file · Preview Using the key ↑and↓ to move the cursor and preview the picture inside the file when you choose the Preview. 4.2 Save file Press F2,enter into Save file interface form the Files interface. -
Page 21: Setting
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Save file · Save to: Choose saving file by using key↑and↓. ·Diskette file name Input the saving file name you want. · Save from: ＋ － Choose the source file by using key↑and↓ and add or delet the folder by using Key ·... -
Page 22: Cutting Type
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. · Kerf Set the cutting kerf value of drawing for accountting the drwging size . Carfully use the cutting kerf value because it will caused of the invalid working. It is possible to look at the cutting kerf by using the spare part item after setting cutting kerf. - Page 23 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Picture 4-6 look at the Sequence Diagram by press key SPACE · Ignition time Lasting effective time of output signal when igniting every time · Low preheat For machine with low preheat function,Output the low preheat signal time before the parameter set the high preheat .
- Page 24 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. ·Rise time of pierce cutting torch Set the lasting effective rise time of cutting torch during the pierce process. · Fall time of pierce cutting torch Set the lasting effective fall time of cutting torch during the pierce process. ·...
- Page 25 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Similarly,there is plasma cutting control logic inside the controller. Use the following parameter to set different cutting logic for different steel plates. The time sequence picture will change accordingly if parameters are changed. Picture 4-8 Press SPACE key to view time sequence ·...
- Page 26 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. system, the parameter should be set zero. Note: torch withdraw must be set OPEN. · Torch Down Time Set the effective time of torch fall signal when cutting begin and finish every time. If use THC control system, the parameter should be set zero.
-
Page 27: Cutting
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. This parameter forces output torch down signal during whole cutting process. It is for fitting different types of torch height controller. · Torch Down During Two Cuttings This parameter forces keeping output torch down signal when idle running among cutting parts. 4.5 Cutting Set cutting mode, speed and kerf, press F9 to begin cutting as the following picutre shows. - Page 28 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Picture 4-10 Manual Cuttng In manual interface, use arrow key to move cutting machine on four directions. The cutting equipment will move continuously if keeping press the key. After release it, machine will stop. If open the Manual Lock function, within the interface, if press manual key first time, the direction key will move forward as the direction.
- Page 29 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Picture 4-11 Set Move Distance · Cutting Distance When manual mode show fast cutting, F2 soft key means cutting distance, input correct cutting distance. After press cut, the machine will use choosing cutting procedure and cutting distance automatically.
- Page 30 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Picture 4-13 Manul Options · Every Axis to Zero Press this key to enter axis back to zero interface. Picture 4-14 Axis to Zero · Change Mode Shift different manual operation mode, including only moving, fast cutting and fast marking. ·...
-
Page 31: Pause
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. 4.6 Pause Can use many ways to restort cutting process when cutting failure. Following is the cuttng pause interface.。 Picture 4-15 Cutting Pause Interface If press Esc, can stop present cutting parts at this moment. ·... -
Page 32: Graphs Nesting
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. to continue cutting. Retrace Picture 4-16 · Move to Pierce Point This button can move torch directly to the pointed pierce point. · Cutting Mode Shift different cutting modes. · Change Speed Shift different running speed, max speed, advance speed, medium speed and low speed. ·... - Page 33 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Picture 4-17 Choose parts to nest Press enter or OK key after choosing and enter parts parameter setting interface, set every parameters of the parts. Picture 4-18 Set parameters of the nesting parts Press enter or OK key again to set nesting parts numbers.
- Page 34 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Picture 4-19 Set nesting parts numbers Enter nest working interface after confirmation. Picture 4-20 Nest working interface The left side of the window is the nesting observe area. Left up side is parts choosing area and left bottom is parts edit area.
- Page 35 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. PREV/NEXT to jump among these three areas. When chose one area, there will have a blue outline border, press arrow and can move choosing parts. · Add Parts This button can add parts to nesting plan at any time, so parts can be obtained from graph library, floppy disk or remote host machine.
-
Page 36: Chapter 5 Care And Maintenance
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Chapter 5 Care and Maintenance CNC cutting machine have to clean and keep in good repair in the round, because it usually work in outside and under bad conditions, and because it can cause a lot of metal dusty. Somebody have to be responsible for smooth, repair and maintenance of machine. -
Page 37: Appendix A Hardware Specification
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. It is necessary to fasten and replace. 3) Check if all drive part has become adrift, and if the gear and rack have inosculated. It is necessary to adjust if the occasion should arise. 4) Check if the operation plate and fastening screw have adrift, the dust inside cabinet will be cleaned by the vacuum and the blower. -
Page 38: Appendix B Performance Characteristic
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Appendix B performance characteristic Digital servo can control all cutting equipment, but SERCOS interface can increase number of motion shaft and number of I/O Using coder of 1000 line /inch , dynamic precision is 0.002 inch (0.051mm) ... -
Page 39: Appendix D Consumables Replacement
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. aperture time. Built-in water-jet cutting control logic can set up abrasive and aperture time In order to the flexible using, it can set up servo plus, speed, observation windows, machine parameter, communication parameter. ... - Page 40 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Consumables life expectancy can be set. The controller will output signal and warn through I/O when the consumables reach life expectancy. Usually this warning signal is connected to indicator or annunciator to remind operator to return consumables. ·...
-
Page 41: Appendix E Spare Parts Options
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Appendix E Spare Parts Options This interface supplies zoom, whirl, mirror image, repeat arrangment and steel plate alignment. Changes will be displayed in the preview windows Appendix 2 Spare parts options Zoom Coefficient Set spare parts zoom rate and change spare parts dimensions. - Page 42 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Controller provides three drawings repeat arrayarrangement: in line, cross, interlink Appendix 3 Inline repeat ·Corner Begining Choose steel corner as arrangement array start point.. · Line Numbers Pointed array lines numbers. · Row Numbers Pointed array row numbers.
- Page 43 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Appendix 4 Cross repeat Exhaust repeat Appendix 5 · X/Y Nesting Distance Designate the minimum distance amony nesting parts, only use for nesting repeat.
- Page 44 Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. · Graph Excursion This function calculate the minimum distance among parts or parts groups automatically, including incoming line /outgoing line, kerf, scrap edge value. This value maybe not the best, but at least it makes the parts don’t overlap. ·...
-
Page 45: Appendix F Oxygen-Propane Auto And Semi-Auto Gas Cutting Regulations（Recommendation
Dalian Huarui Heavy Industry CNC Equipment Co.,Ltd. Appendix F Oxygen-propane auto and semi-auto gas cutting regulations （Recommendation） Nozzle Edge Steel Oxygen Propane Gas cutting trimming thickness pressure pressure speed Use equipment (JP-No width （mm） （MPa） （MPa） （mm/min） （mm） 3—10 0.025 600—700 Auto/Semi-auto 5—20...
