- Page 1 LL-RP60P LL-RP80P LL-RP60P / LL-RP80P MANUAL...
-
Page 2: Table Of Contents
Assembly of the Connecting Rod to the Compressor ................17 Reassembling the Compressor ........................18 Servicing the Fan ............................20 Shop Our Full Selection at www.ANJONMFG.com ..................21 Warranty & Customer Service Contact Information ................... 23 ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 3: Introduction
This manual is based on the latest products′ information available at the time of creation or last revision. It is believed to be generally accurate and reliable. Please consult customer service representatives at Anjon Manufacturing if detailed information is desired, or whenever there is a question about a given unit’s configuration or performance... -
Page 4: Safety First
DO NOT CONNECT THE UNIT TO A POWER SOURCE! Refer further into this manual for troubleshooting on page 6 to find the possible error. NEVER OPERATE THIS AIR COMPRESSOR WHILE CONNECTED TO AN EXTENSION CORD ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 5: Box Contents
LL-RP80P INTAKE PORT NO PORT HOLE EXHAUST PORT EXHAUST PORT LL-RP60P Install Air Fitting EXHAUST PORT EXHAUST PORT (Not Included) (Exhaust Port opposite of desired NO PORT HOLE INTAKE PORT Pressure Release Valve location) ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 6: Installation Of Lifeline Air Compressor
Check that the supply voltage is correct and verify motor is turning in proper direction. Check plug, cord and switch for damage; the thermal protection function may have been tripped. If the thermal protection function engaged, the motor will restart automatically after cooling-down. ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 7: Maintenance
TIGHTEN HEAD SCREWS BROKEN FAN REPLACE FAN BENT MOTOR SHAFT REPLACE ENTIRE UNIT DAMAGED COMPACITOR REPLACE COMPACITOR LOOSE FITTINGS TIGHTEN FITTINGS INSUFFICIENT INCREASE AIR CIRCULATION VENTALATION IN TO ENCLOSURE ENCLOSURE REPLACE ECCENTRIC WORN BEARINGS BEARING ASSEMBLY ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 8: Exploded Diagram & Service Parts List
LEFT HEAD / RIGHT HEAD O-RING FOR HEAD (HEAD GASKET) HEAD SCREWS VALVE PLATE ASSEMBLY VALVE RESTRAINT VALVE KEEPER STRIP FLAPPER VALVE – INTAKE & EXHAUST VALVE PLATE ASSEMBLY FLAPPER VALVE SCREWS O-RING FOR VALVE PLATE ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 9: Disassemble & Reassemble The Ll-Rp60P / Ll-Rp80P
• Standard Phillips Screwdriver (+) for retainer screws. • Soft & Clean Cloths. *Refer to the service parts list on the exploded diagram for correct replacement part number Compressor Housing Capacitor (LEAD END) Capacitor (LEAD SIDE) ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 10: Component Repair
: If you are replacing the Head [#6*] and O-Ring for Head (head gaskets) [#7*] only, see the assembly instructions on page 19. To replace the Flapper Valves [#12*] and Connecting Rod & Eccentric Assemblies [#1*], continue to pages 10–14. ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 11: Servicing The Valve Plate Assembly (Top-Side)
4. Orient a new Flapper Valve. [#12*] over Port 1. Refer to the figure to orient the location of at the end of the Flapper Valve. [#12*]. Opposite LEAD Side Port 1 Port 1 *Refer to the service parts list on the exploded diagram for correct replacement part number ©2017 Anjon Manufacturing. All Rights Reserved... - Page 12 *Refer to the service parts list on the exploded diagram for correct replacement part number Caution: Do not over-tighten the Flapper Valve Screws [#14*] or it will shear off into the Valve Plate [#13*]! ©2017 Anjon Manufacturing. All Rights Reserved...
-
Page 13: Servicing The Valve Plate Assembly (Bottom-Side)
LEAD Side Observe the location of the Notches [ ] at the end of the Flapper Valve [#12*]. Port 2_ *Refer to the service parts list on the exploded diagram for correct replacement part number ©2017 Anjon Manufacturing. All Rights Reserved... - Page 14 If you are replacing only the Flapper Valve(s) [#12*], see the assembly instructions on pages 10–13. If you are replacing the Piston Cup [#2*], Piston Cup Retainer [#4*], and Cylinder Sleeve [#5]; turn to the Rebuilding Connecting Rod Assemblies Section found on pages 14 – 17. ©2017 Anjon Manufacturing. All Rights Reserved...
-
Page 15: Servicing The Connecting Rod & Eccentric Assemblies
Connecting Rod & Eccentric Wheel Assembly Removal NOTE: ONLY REMOVE ONE CONNECTING ROD ASSEMBLY AT A TIME! 1. Carefully remove the Fan [#16] by pulling it straight off the motor shaft. Do not pull the fan blades! ©2017 Anjon Manufacturing. All Rights Reserved... - Page 16 Eccentric Wheel _Set screw Access Hole 3. Slide the eccentric bearing assembly straight off the shaft. Eccentric Bearing Eccentric Wheel Connecting Rod 4. Slide and rotate the connecting rod and remove it from its housing. ©2017 Anjon Manufacturing. All Rights Reserved...
-
Page 17: Rebuilding Connecting Rod Assemblies
] when you remove the Connecting Rod from the compressor housing. If the Piston Cup [#2 ] is damaged, you must replace it. Attention: To replace the Connecting Rod & Eccentric Wheel and Bearing Assembly continue to page 17. ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 18: Assembly Of The Connecting Rod To The Compressor
Connecting Rod can move without any obstacle impeding its moment, then use an Allen Key (S3) to tighten Connecting Rod screw. *Refer to the service parts list on the exploded diagram for correct replacement part number ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 19: Reassembling The Compressor
Power Leads Note: Make sure that the connecting rod sleeves are seated against the compressor housing. *Refer to the service parts list on the exploded diagram for correct replacement part number ©2017 Anjon Manufacturing. All Rights Reserved... - Page 20 Note: Ensure that O-Rings for Head (head gaskets) [#7*] are aligned in the O-Ring Grooves and are not pinched. *Refer to the service parts list on the exploded diagram for correct replacement part number ©2017 Anjon Manufacturing. All Rights Reserved...
-
Page 21: Servicing The Fan
[#16*] back on the motor shaft, making sure the fan clips face towards compressor as shown. *Refer to the service parts list on the exploded Clip towards Compressor_ diagram for correct replacement part number ©2017 Anjon Manufacturing. All Rights Reserved... -
Page 22: Shop Our Full Selection At Www.anjonmfg.com
Largest online selection of complete, everything-you-need. Choose from our standard kits, semi- custom or full custom potions. Pond Liner Anjon Manufacturing offers the widest range of pond liner materials and sizes. Your trusted source for EPDM, PVC & HDPE liners. Submersible Pond Pumps Complete range of energy efficient small statuary and fountain pumps to high flow 10,000+ GPH large fish pond and waterfall pumps. - Page 23 Beautiful finishing touches that show Build striking formal falls with off your pond & landscape. lighted acrylic & stainless- steel spillways. Seasonal Care & Maintenance Everything you need to prepare & maintain your pond all year long. ©2017 Anjon Manufacturing. All Rights Reserved...
-
Page 24: Warranty & Customer Service Contact Information
24 months from the date of purchase, but not more than 30 months from the date of manufacture. ANJON liability under this warranty shall be limited to repairing or replacing, at ANJON’s discretion, without charge, F.O.B.
