Thank you for purchasing this series UPS.

This series UPS is an intelligent, single phase in single phase out, high frequency online

UPS designed by our R&D team who is with years of designing experiences on UPS.

With excellent electrical performance, perfect intelligent monitoring and network functions,

smart appearance, complying with EMC and safety standards, This UPS has become

standard product which meets the world's advanced level.

Read this manual carefully before installation

This manual offers technical support for equipment operator

Technoline

Cavendish blvd, Montreal, QC H4R 2M9 CANADA

www.technoline-ca.com

Edition: January 2020 – version: 1.0

User's Manual

EVO PLUS 1.000 Rack Tower PF 0.9

EVO PLUS 2.000 Rack Tower PF 0.9

EVO PLUS 3.000 Rack Tower PF 0.9

Table of Contents

Need help?

Do you have a question about the EVO PLUS 1.000 PF and is the answer not in the manual?

Questions and answers

Summary of Contents for Technoline EVO PLUS 1.000 PF

Page 1 EMC and safety standards, This UPS has become standard product which meets the world’s advanced level. Read this manual carefully before installation This manual offers technical support for equipment operator Technoline Cavendish blvd, Montreal, QC H4R 2M9 CANADA www.technoline-ca.com Edition: January 2020 – version: 1.0...
Page 2: Table Of Contents
Table of Contents Important Safety Warning ........................2 Transportation ..........................2 Preparation ............................ 2 Installation ............................. 2 Operation............................3 Maintenance, service and faults .................... 3 Symbols used in this guide ...................... 4 Installation and setup ..........................4 Unpack checking .......................... 5 Real panel view ..........................
Page 3: Important Safety Warning
1. Important Safety Warning Important safety instructions – Save these instructions Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully There exists dangerous voltage and high temperature inside the UPS.
Page 4: Operation
 Please use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your computer) to connect the UPS system to the building wiring outlet (shockproof outlet).  Please use only VDE-tested, CE-marked power cables to connect the loads to the UPS system.
Page 5: Symbols Used In This Guide
ground. Before touching, please verify that no voltage is present!  Batteries may cause electric shock and have a high short-circuit current. Please take the precautionary measures specified below and any other measures necessary when working with batteries: －remove wristwatches, rings and other metal objects －use only tools with insulated grips and handles.
Page 6: Unpack Checking
2-1 Unpack checking  Don’t lean the UPS when moving it out from the packaging.  Check the appearance to see if the UPS is damaged or not during the transportation, do not switch on the UPS if any damage found. Please contact the dealer right away.
Page 7 2KVA(S/H): 3KVA(S/H): 1. Output receptacles(10A) 2. Battery Terminal 3. SNMP intelligent slot (option) 4. Network /Fax/Modem Surge Protection(option) 5. RS-232 communication port 6. AC input receptacle 7. Input circuit breaker 8. EPO(option) 9. USB(option) 10. Output receptacle(16A)
Page 8: Installing The Ups
2-3 Installing the UPS  Rackmount installation The Rackmount cabinet comes with all of the hardware required for installation in a standard EIA or JIS seismic Rackmount configuration with square and round mounting holes. The rail assemblies adjust to mount in 19” racks with a distance from front to rear around 70~76 cm (27 to 30 inches) deep.
Page 9 Figure 1 Securing the Rails Select the proper size in the rack for positioning the UPS (see Figure 2). The rail occupies four positions on the front and rear of the rack. Tighten four M5 Umbrella Nuts in the side of rail assembly (see Figure 1). Fix one rail assembly to the front of the rack with one M5×12 pan-head screw and one M5 cage nut.
Page 10 Secure the front of the UPS to the rack using one M5×12 pan-head screws and one M5 cage nuts on each side(see Figure 4).Install the bottom screw on each side through the bottom hole of mounting bracket and the bottom hole of the rail.
Page 11 Figure 5 Extract UPS front cover CAUTION A small amount of arcing may occur when connecting the internal batteries. This is normal and will not harm personnel. Connect the cables quickly and firmly b) Connect the internal battery connector (see Figure6) Connect red to red, Press the connector tightly together to ensure a proper connection.
Page 12 the EBP cable is routed through the knockout on the bottom of the cover. Put the front cover hooks of side with display to the cover port, put another side to the other two ports, then press it until the cover and the chassis are combined tightly. Figure 7 e) If you are installing power management software, connect your computer to one of the communication ports or optional connectivity card.
Page 13 Figure 8 Removing the EBP Front Cover b) On the bottom of the UPS front cover, remove the EBP cable knockout (see Figure Figure 9 Removing the UPS Cable Knockout c) For the bottom (or only) EBP, remove the EBP cable knockout on the top of the EBP front cover.
Page 14 to extend the wiring to the EBP connector on the second EBP. Repeat for any additional EBPs. Verify that the EBP connections are tight and the adequate bend radius and strain relief exist for each cable. Figure 10 Typical EBP Installation g) Replace the EBP front cover.
Page 15 Figure 11 plastic base installation ③If an EBP is needed to be placed in the middle, the assembly of plastic base is similar (Figure 11 ).The difference is that two 1U plastic base extended boards are added in the middle.(as the following shows) （A）...
Page 16 （E）（F） Figure 12 increase EBP plastic base installation  The installation between UPS and EBPS can be referred to Fig.13 Figure 13 The installation for UPS and battery box...
Page 17: Ups Start Up And Turn Off
Figure 14 Long backup external battery connection a) Install the base, then place the RT UPS on the base one by one as Fig.13 shows. b) The cover installation and cable connection of the UPS and EBPS are the same as RT.
Page 18: Configuring Battery Setings
(2) Turn off the UPS by DC without mains power a) Press and hold the OFF key for more than half a second to turn off the UPS. b) When turning off the UPS, it will do self-testing firstly. The LEDs light and go out circularly and orderly until there is no display on the cover.
Page 19: Setup The Ups
LCD control panel introduction （1）LED（from top to bottom: “alarm”, “bypass”, “battery”, “inverter”); （2）On-Line UPS LCD display;（3）Buttons-FUNC button/OFF button/On button. Status Indicator Description The UPS has an active alarm or fault. The UPS is in Bypass mode. The UPS is operating normally on bypass during High Efficiency operation.
Page 20 wires are securely affixed. d) Put the small cover back to the rear panel. Step 3: Communication connection Communication port: To allow for unattended UPS shutdown/start-up and status monitoring, connect the communication cable one end to the USB/RS-232 port and the other to the communication port of your PC.
Page 21: Operations
3. Operations 3-1 Button operation Button Function  Turn on the UPS: Press and hold ON button for at least 2 seconds to turn on the UPS.  Choosing different value: When the UPS enters the setting mode, press this button to choose ON Button the different value what you want.
Page 22: Lcd Display
 Switch to UPS self-test mode: Press and hold this button for 2 seconds to enter UPS self-testing while in AC mode.  Setting mode: Press and hold these buttons in FUNC + OFF Button the same moment for 5 seconds to enter UPS setting mode.
Page 23 Load Environment Temperature Firmware Version & UPS model CODE (Operational status and mode)
Page 24 Alarm Code(Warming Message) All alarm codes are present when abnormal behavior(s) occur(s) Part two: Tower display ●After the UPS turn ON, continue to press the function key for 10 seconds , the LCD screen begin to rotate. ●LCD display with rotation function and after rotating display information content is constant ,the LCD display information only display the direction and pattern of change.
Page 25 Output voltage Load Environment Temperature Firmware Version & UPS model...
Page 26: Ups Setting
CODE (Operational status and mode) Alarm Code(Warming Message) All alarm codes are present when abnormal behavior(s) occur(s) 3-3 UPS setting The UPS has setting functions. This user settings can be done under any kind of UPS working mode. The setting will take effect under certain condition. Below table describes how to set the UPS.
Page 27 Item Settings Content display Mode setting Press Enter button  to change the setting (NOR or ECO or CF). Press UP button ▲ to select the previous setting. Press DOWN button ▼ to select the next setting. Output voltage setting Press Enter button ...
Page 28 EOD voltage setting Press Func button to change the setting(160/167/175/180.) default setting： 175(1.75V /cell) Press UP button ▲ to select the previous setting. Press DOWN ▼ button to select the next setting. Bypass voltage upper limit setting Press Enter button  to change the setting(The bypass voltage upper limit range is 230-264Vac ).
Page 29: Operating Mode Description
BYPASS enable/disable setting Press Enter button to change the setting(ON or OFF). Press UP button ▲ to select the previous setting. Press DOWN button ▼ to save and exit the setup. ； Generator mode setting Press Enter button to change the setting(ON or OFF).
Page 30 The bypass yellow LED is on. Bypass tolerance can be set by Bypass voltage limit setting. Under below conditions, the UPS will transfer to bypass mode: ● BPS on set by user through Mode setting Bypass Mode , and set to ECO Mode. ●...
Page 31: Operational Status And Mode(S)
3-5 Operational Status and Mode(s) item Content Displayed Standby Mode No Output Bypass Mode Utility Mode Battery Mode Battery Self-diagnostics Inverter is starting up ECO Mode EPO Mode Maintenance Bypass Mode Fault Mode Mode Generator 3-6 Alarm or Fault reference code Event log UPS Alarm Warning Buzzer...
Page 32: Troubleshooting
Output Short-circuit Once per second Fault LED blinking Input current limit Once per second Fault LED blinking Bypass over current Once per second BPS LED blinking Overload Once per second INV or BPS LED blinking No battery Once per second Battery LED blinking Battery under voltage Once per second...
Page 33 Alarm code is shown as “34” and Battery voltage is too low or Contact your dealer. battery led blinking the charger is fault. Alarm code is shown as “32” and UPS is overload Remove excess loads from INV or BYPASS led blinking. UPS output.
Page 34 Check the wire RefeR to Wiring connect refer to Diagram wiring Diagram Check the UPS mode(Input voltage Bat voltage) UPS turn on Check sps +12V & Replace power board Battery mode Bat voltage Replace control panel Fan Run normal& Fan issue Replace fan LCD light? Replace control...
Page 35: Storage And Maintenance
5. Storage and Maintenance  Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer. Be sure to deliver the spent battery to a recycling facility or ship it to your dealer in the replacement battery packing material.
Page 36 effective monitoring of the real-timestatus of UPS and timely feedback the statusto monitor when abnormal situation occurs(suchas UPS failure, mains interruption,UPS bypassand ect.). It is installed in the intelligent slotof the UPS. The relay card includes 6 output ports and one input port.Please refer to thefollowing table for detail.
Page 37 Emergency Power-off (EPO) (options) EPO is used to shut down the UPS from a distance. This feature can be used for shutting down the load and the UPS by thermal relay, for instance in the event of room overtemperature. When EPO is activated, the UPS shuts down the output and all its power converters immediately.
Page 38: Specification
7.Specification MODEL 1KVA(S) 1KVA(H) 2KVA(S) 2KVA(H) 3KVA(S) 3KVA(H) PHASE Single phase with ground Capacity (VA/Watts) 1000VA /900W/1000W 2000VA / 1800W/2000W 3000VA / 2700W/3000W INPUT Nominal voltage 208/220/230/240VAC 176Vac±5% @100%-50% load; Low line 110Vac±5% @50%-0% load; transfer Operating 186Vac±5% @100%-50% load; Low line voltage 120Vac±5% @50%-0% load;;...
Page 39 BATTERY depends on depends on depends on the capacity the capacity the capacity Battery Type 12V9AH 12V9AH 12V9AH of external of external of external batteries batteries batteries Numbers Backup time Long run unit depends on the capacity of external batteries Typical recharge 4 hours recover to 90% capacity (Typical) time(standard modle)

This manual is also suitable for:

Evo plus 2.000 Evo plus 3.000
