- Page 1 ® Installation, Operation, & Maintenance Manual RETROFIT II IMPORTANT! TRACTION DRIVE DO NOT DESTROY Gorbel Customer Order No. / Serial No. ® Gorbel Dealer ® Issued: 12/2010 Revised: 07/2022 Date Month Year...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ......................Installation Step 1 - Pre-Assembly ...................... 2 Step 2 - Installation and Drive Assembly Instructions ........... 2-3 Step 3A - Electrification Installation (Standard Drive)............4 Step 3B - Electrification Installation (Variable Frequency Control Drive) ..... 4-5 Step 4 - Limit Switch Installation ................... -
Page 3: Introduction
Thank you for choosing a Gorbel® Retrofit II to solve your material handling needs. The innovative design and heavy-duty construction of a Retrofit II added to an existing jib will provide a superior quality product that will offer years of long term value. All Gorbel® cranes are pre-engineered for powered hoist operation. The hoist weight allowance is 15% of the crane capacity (for example, a crane rated for 1000 pounds allows for a 1000-pound live load plus 150 pounds for the weight of the hoist). -
Page 4: Installation
Read entire manual before installing the Retrofit II. Check packing list to ensure no parts have been lost prior to initiating assembly of the Retrofit II. Tools and materials (by others) typically needed to assemble Retrofit II: • Ladders/man lifts •... - Page 5 STEP 2 - INSTALLATION AND DRIVE ASSEMBLY (CONTINUED) Diagram 2A. Frame Installation. Diagram 2B. Retrofit II. 7/2022...
-
Page 6: Step 3A - Electrification Installation (Standard Drive)
(VARIABLE FREQUENCY CONTROL DRIVE) JIB DRIVE CONTROLLER The drive controller for the jib drive is pre-programmed at Gorbel for single speed, two speed, or three speed operation. For troubleshooting and general information, a brief summary of how the drive controller is designed to be used is included below. No additional programming is required. - Page 7 DRIVE CONTROLLER PROGRAMMING Gorbel pre-programs a number of parameters in the drive controller prior to shipment. The remaining parameters are left at the factory default settings. All parameters are stored on the EPM module. These parameters are as follows:...
-
Page 8: Step 4 - Limit Switch Installation
STEP 4 - LIMIT SWITCH INSTALLATION If applicable, install limit switches per the following instructions and diagram 4A on page 8. The limit switches are designed to shut off the power to the rotation drive motor in a clockwise or counterclockwise direction and are not intended to serve as a spotting function. - Page 9 STEP 4 - LIMIT SWITCH INSTALLATION (CONTINUED) RAMP INSTALLATION: Two rotation limits can be established, one in the clockwise direction and one in the counter- clockwise direction. The lower switch will be the clockwise rotation limit switch and the upper switch will be the counterclockwise rotation limit switch.
- Page 10 STEP 4 - LIMIT SWITCH INSTALLATION (CONTINUED) Over Travel Adjustment Instructions: All cranes will experience some over travel, after power to the drive is shut off, due to inertia of the load acquired during rotation. The amount of over travel is dependent on the application and the size of the jib crane.
-
Page 11: Step 5 - Endstop/Tagline Installation
STEP 5 - ENDSTOP/TAGLINE INSTALLATION Tagline Festoon Installation - Where Applicable (diagram 5A) Bolt tagline bracket and an endstop to end of boom closest to the mast. Reinstall existing hoist/hoist trolley into place (where applicable). Immediately bolt remaining tagline bracket and endstop into place at the front of boom. Torque nuts. -
Page 12: Step 6 - Shut Down Procedures
STEP 6 - SHUT-DOWN INSTRUCTIONS Secure the beam in shut-down position or storage area. Check crane, hoist and hook storage positions to be sure there is no interference with other pieces of equipment that may be operating in the area. If crane is electrified, shut power OFF on pendant and disconnect switch. -
Page 13: Troubleshooting Guide
2. Call factory and ask for Customer Service. If you are experiencing any other problems in the start-up or operation of your Gorbel® crane, please call 1-800-821-0086 and ask for Customer Service. TRUNNION ROLLER REPLACEMENT WARNING Note: Only competent personnel familiar with standard fabrication procedures should be allowed to perform maintenance operations to Gorbel®... -
Page 14: Crane Operator Instructions
ANY SAFETY FEATURES AND MECHANISMS BUILT-IN OR OTHERWISE PROVIDED WITH THE CRANE BY GORBEL ARE REQUIRED FOR THE SAFE OPERATION OF THE CRANE. -
Page 15: Limited Warranty
Cancellations: If it becomes necessary for the purchaser to cancel this order wholly or in part, he shall at once so advise Gorbel in writing. Upon receipt of such written notice all work will stop immediately. If the order entails only stock items, a flat restocking charge of 15% of the purchase price will become due and payable by Purchaser to Gorbel. -
Page 16: Appendix A: Securex Friction Torque Limiter Type C&T Installation
Appendix A: Securex Friction Torque Limiter Type C & T Installation & Maintenance Instructions (Size 30 Thru 280) • Read and follow all instructions carefully. • Disconnect and lock-out power before installation and maintenance. Working on or near energized equipment can result in severe injury or death. •... - Page 17 RUNNING-IN Torque Limiters should be run-in for the most consistent results. To run-in, adjust the Torque Limiter to 25% of the maximum single spring capacity and slip the center member approximately 50 RPM for approximately 4 minutes. TORQUE SETTING PROCEDURES Type 30 ÷...
- Page 18 Type 95 ÷ 170: slip torque is preset by adjustment of 4 or more screws on the nut (B), providing axial load to the disk spring. This system makes the adjustment easy. Apply springs load by loosening the adjusting bolts in approximately 60 degrees steps until no slip is observed under maximum load conditions in normal running mode.
- Page 19 TORQUE CHECKING To check the Torque Limiter for the required slip torque, mount the Torque Limiter on a stub shaft and fasten in a bench vise. Wrap the center member (if a sprocket) with a chain and load the chain with weights until the center member rotates. If the center member is a plate, attach a chain or cable to the center member.
- Page 20 EXTRA NOTES FOR TYPE C ASSEMBLING PROCEDURES: When assembling type C friction torque limiter, make sure that misalignments are within the allowed values indicated below:...
- Page 21 THIS PAGE INTENTIONALLY LEFT BLANK 7/2022...
- Page 22 THIS PAGE INTENTIONALLY LEFT BLANK 7/2022...
- Page 23 THIS PAGE INTENTIONALLY LEFT BLANK 7/2022...
-
Page 24: Maintenance Schedule
This product can expose you to chemicals, including acrylonitrile, (585) 924-6262 Fax: (800) 828-1808 which are known to the State of California to cause cancer. For E-Mail: info@gorbel.com more information go to: http://www.gorbel.com www.P65Warnings.ca.gov © 2010 Gorbel Inc. All Rights Reserved 7/2022...
